63
Optional Features
Available options DX1 DX2 Notes
Flexible dual conveyor X X
SpeedStar C&P20 X X In the two gantry area, only available in
combination with a second SpeedStar
Reconfiguration kit for SpeedStar X X
Stationary component camera, type 33, 55 x 45
digital
X X For the TwinStar
TwinStar X X
12 segment Collect&Place head X X
High-Force Head X X
Reconfiguration kit for TwinStar or High-Force
head
XX
Stationary component camera, type 25, 16 x 16
digital
X X Only for TwinStar or high force head
Vision teaching station X X
Nozzle changers X X Depending on the placement head
Nozzle changer, row 2 X X Depending on the placement head
Sensor for the component reject bin X X
DX-Wechseltisch 60 X X
Smart Feeder X, 12 mm and 16 mm X X All X feeder modules can be used without
restrictions on the SIPLACE DX.
X feeder modules, 8 mm to 88 mm X X
X feeder module, 2x8 mm X X
Splice point recognition for X feeder modules X X
Linear Dip Module LDU X X X Not in combination with SpeedStar
Support for an additional tape reel,
SIPLACE DX
XX
64
Optional Features
Available options DX1 DX2 Notes
Feeder module adapter for the X-series X X Linear vibratory feeders, type 3 can be set
up on the SIPLACE DX1/DX2 tables with
this adapter.
110/208 V conversion kit X X
Vacuum pump
a
a) Available on request.
X X Not for the TwinStar or High-Force head or
the 12 segment Collect&Place head.
Vacuum pumpinstallation kit
a
XX
WPC5/WPC6 X X In SIPLACE DX1 only at location 1.
Not in combination with the SpeedStar and
12 segment Collect&Place head.
Applies to the TwinStar on the side of the
WPC5/WPC6 in placement area with 2
gantries.
DX table30 X X At WPC5/WPC6 in respective location.
DX-Wechseltisch 30 At WPC5/WPC6 in respective location.
External presetup location
a
XX
Dummy feeder module X X
“Long Board” option (LBO) for single convey-
ors
X X The "Long Board" option facilitates the
placement of boards which are longer than
the specified length.
Whispering Down the Line (WDTL) X X
2-part signal lamp X X
65
Languages
Other languages can be realized on request.
Documentation
package
SIPLACE
Pro 10.0
OIS 10.0 Station software
706
German X X X X
English X X X X
French X X X X
Italian X X X X
Spanish X X X X
Portuguese X X X X
Hungarian X X X X
Czech X X X X
Russian X
a
a) On request.
X
a
X
a
X
a
Turkish X
a
X
a
X
a
X
a
Polish X
a
X
a
X
a
X
Estonian X X
a
X
a
X
a
Finnish X
a
–– –
Swedish X – – –
Danish X – – –
Dutch X
a
–– –
Korean X X X X
Chinese X X X X
Japanese X X X X
