23 PCB Conveyor Flexible Dual Conveyor Technical Data for the Dual Conveyor S tationary conveyor side Right or lef t PCB dimensions S tandard (length x wid th) "Long Board with stepping" option Dual conveyor in…
22
PCB Conveyor
Flexible Dual Conveyor
Description
As a result of reduced sec-
ondary processing times and
in conjunction with the opti-
mum placement program,
the PCB dual conveyor can
significantly enhance
throughput times. It allows
two PCBs to be carried si-
multaneously (synchronous-
ly) or alternately
(asynchronously) through
the placement machine.
In asynchronous mode, only
one PCB is processed in
each conveyor lane. At the
same time, another PCB in
the second conveyor lane is
moved into the placement
position. This saves the full
conveying time of one PCB,
thus considerably increasing
performance, particularly for
PCBs with a short cycle time.
The placement process
starts as soon as one PCB is
transported into the process-
ing area.
In synchronous mode, two
PCBs are moved into the
placement position at the
same time. They are pro-
cessed as a common panel.
This facilitates the process-
ing of a board upper and un-
derside in one line. The
amount of nonproductive
secondary processing time is
reduced, as two boards are
always transported at the
same time.
Asynchronous transport mode
Synchronous transport mode
23
PCB Conveyor
Flexible Dual Conveyor
Technical Data for the Dual Conveyor
Stationary conveyor side Right or left
PCB dimensions
Standard (length x width)
"Long Board with stepping" option
Dual conveyor in "single conveyor" mode
Standard
"Long Board with stepping" option
50 mm x 50 mm to 450 mm x 216 mm
a
50 mm x 80 mm to 850 mm x 216 mm
50 mm x 50 mm to 450 mm x 450 mm
50 mm x 80 mm to 850 mm
a
x 450 mm
PCB thickness
Standard
0.3 mm to 4.5 mm (± 0.2 mm)
(Standard, thicker on request)
Vacuum accessories on request
Thin boards on carrier
PCB Warpage See page 24
PCB weight
b
Max. 3 kg
Clearance on PCB underside
Standard
Option
25 mm ± 0.2 mm
Max. 40 mm ± 0.2 mm
PCB conveyor height 900 mm ± 15 mm (option)
930 mm ± 15 mm (standard)
950 mm ± 15 mm (SMEMA option)
Type of interface SMEMA / Siemens
Component-free PCB handling edge 3 mm
PCB changeover time < 2.5 s
PCB positioning accuracy ± 0.5 mm
Conveyor mode Synchronous or asynchronous
Components on each conveyor Same or different
PCB width on each conveyor Same or different
Inkspot detection on the PCB Synchronous: Possible (no global inkspot)
Asynchronous: Possible
Virtual ink spot handler Optional
Automatic width adjustment Synchronous: Possible
Asynchronous: Possible
a) 850 mm on request
b) Higher weight on request.
24
PCB Warpage
PCB warpage across the direction of travel
max. 1 % of the PCB diagonal, but not
exceeding 2 mm
PCB warpage during transportation
Fixed clamped edge
Movable clamping device
PCB
Fixed clamped edge
Conveyor belt
PCB transport direction
Front board edge
Front board edge
PCB warpage in direction of travel + PCB thickness < 5.5 mm
Bending up of front board edge max. 2.5 mm
Left conveyor belt
Right conveyor belt
PCB transport direction
