Existing Functions

Device Identification

Software Version Description SIPLACE Setup Center 2.3

6.7 Device Identification

Purpose

A Device Identification or identifier (ID) is a unique artificial ID which identifies a device e.g. a machine,

changeover table or feeder. Device identifications help Setup Center to recognize, trace and re-use

packaging units used in connection with these devices.

Function

 Unique Machine IDs Setup Center introduces Machine ID Barcodes (MID) which are installed onto

each X-machine ex factory. Setup Center is able to generate Machine ID Barcodes for other machine

series which can be attached to these machines. The introduction of Machine ID Barcodes also

changes user guidance at the barcode scanner. After the machine BC has been read in, the barcode

scanner displays a menu from which the user selects the desired command.

 Unique Feeder ID for X-Feeders X-feeders are equipped ex factory with a Unique Feeder ID. Once

the feeders are placed on the changeover tables the ID is read out electronically. In this way the

packaging units which are assigned to feeders can be traced via Setup Center and information

between the machine and the docking station can be exchanged automatically. Unlike in the case of

S-feeders, the data relation between packaging unit and feeder during tear down does not get lost.

Setup Center also uses the Unique Feeder ID to recognize the feeder, if Setup Verification or Refill

have been initiated via the component verification button.

6.8 Packaging Unit Reorders

Purpose

Some customers operate a Kanban storage for component supply of the line. This storage site is

supplied via a central storage of the customer which uses Setup Center to calculate the demand for

packaging unit reorders.

Function

After successful setup verification, the packaging unit can be labeled for packaging unit reorders. As a

rule, this will always take place as soon as the line operator removes the last packaging unit of an article

code from the Kanban storage.

ATTENTION:

The line-ID known from Setup Center 2.0 and 2.1 is no longer supported but replaced by the

machine ID. For this reason it is necessary to remove all existing barcode labels for online setup

verification, for example ‚Table Verification’, ,Refill’, ‚Shift Change’, ‚Component Search’ etc.

and to overwrite these with new labels.

Existing Functions

Setup Verification Using Supplier Barcode

26 Software Version Description SIPLACE Setup Center 2.3

6.9 Setup Verification Using Supplier Barcode

Purpose

A supplier barcode is used as barcode alternative for a component which is maintained in the

programming system and is clearly identified in the factory.

Function

 Verification with Component Barcode

The whole scanned barcode containing the barcode fragment "component" is compared with the

supplier barcode of the programming system.

 Verification with the Fragment "Component"

The fragment "Component" is extracted from the scanned barcode and only the barcode fragment

"Component" is compared with the supplier barcode of the programming system.

6.10 Shift Change Verification

Purpose

Shift change verification enables you to perform setup verification without sending the quantity to the

station.

Function

Setup Center supports the printout of a control barcode for „shift change verification“ with the Barcode

Label Wizard. This is printed for each station location. Scanning in the barcode then starts the shift

change verification process for a particular table. Alternatively, shift change verification can also be

selected via the barcode scanner menu, after the machine ID has been scanned in. The track concerned

will only be disabled if a faulty unique barcode is recognized. If a track is recognized, which has no

packaging unit set up; this can then be set or ignored.

6.11 Component Level Indicator

Purpose

The Component Level Indicator (CLI) facilitates the supervision and management of the packaging unit

size at the stations. In connection with Setup Center, the actual packaging unit size of individual

packaging units can be transferred to the component level indicator of the stations.

Function

 This component level data is based on the recorded packaging units. If a packaging unit does not

specify a component level, this data is then taken from SIPLACE Pro.

 Reels run out at the station and need to be refilled. Setup Center can then use the CLI to raise the

component level at the empty track.

 The component level at a particular track can be adjusted to compensate for inaccurate reel

quantities or components lost during splicing.

Existing Functions

Packaging Unit Editor

Software Version Description SIPLACE Setup Center 2.3

6.12 Packaging Unit Editor

Purpose

The Packaging Unit Editor offers the user the option of:

changing the supply quantity of a packaging unit,

changing the component quantity of the individual tape piece,

separating tape pieces from the packaging unit,

deleting tape pieces

Function

Setup Center contains a Packaging Unit Editor which is opened via the GUI. It offers an overview of the

individual spliced tape pieces of a packaging unit. The current supply quantity of the packaging unit, or

the component quantity of a tape piece, can be corrected. To separate a tape piece from the packaging

unit or delete it separately, requires teardown of the packaging unit.

6.13 Setup Center Database

Purpose

Setup Center contains the „Setup Center database“, which stores information about the recorded

components and tables.

Function

This database supports table management and stores information about the location of tables.

Component information and locations are also recorded in the database.

A central database is necessary as soon as the same packaging unit is used for two different lines or it

is moved between the pre-setup area to a line.

Every 7 days a complete backup of the database takes place while a delta data backup is performed

each day.

6.14 User Management

Purpose

Setup Center provides a simple user identification feature, in connection with the barcode scanner.

Function

If this function has been enabled, each barcode scanner user must identify himself with a personal

barcode, before the scanner can be used. The user ID barcodes can be printed out via the Setup Center

Barcode Label Wizard.

6.15 Component Search

Purpose

Together with the barcode scanner, Setup Center can show here a particular component occurs on a

setup.

Function

The system searches the setup for the required component. The scanner displays a list of the feeders

on which the component is included in the setup.
