Spec of AX-3 AX-5 June 2005 LR - 第32页
Circuit board Board material Phenolic/paper (FR2) Glass-Epoxy (FR4) Composite materials IPC 9850 Glass verification panel Optionally: Ceramics Auer carriers Flex foil Board artwork material / Hot Air Solder Leveled (HASL…
Components and packaging
R, C, MELF, SOT, SOD, SO, 0.4 x 0.2mm (01005) to 45x45mm
PLCC, QFP, BGA's,
µ
BGA 's,
SSOP, Odd SMD and round
components
Height Minimum: 0.15mm
Maximum:
24 x 24mm = 6.3mm
24 x 24mm - 45 x 45mm = 4.3mm
10.75mm with restrictions
Lead pitch < 0.4mm (0.016")
Lead width < 0.2mm (0.008")
Min. Bump size / pitch 0.15mm (0.006") / 0.3mm (0.012") for
components up to 12 x 12mm
0.3mm (0.012") / 0.5mm (0.020") for
components > 12 x 12mm
Number of bumps Min: 2, max: 3500
Component pick orientation Multiples of 90 degrees
Component pick offset < 0.5mm w.r.t. tape (IEC286-3)
Weight < 12g
Tape sizes 8-56mm wide (IEC286-3)
Reel diameters Up to 330mm (13") for standard single lane ITF
(optional 15" and 22")
Bulk C 0.6 x 0.3mm up to 2.0 x 1.25mm
Bulk R 1.0 x 0.5mm up to 2.0 x 1.25mm
Melf: 1.5 x 1.0mm, 2.0 x 1.25mm
4.3 Components
and
packaging
Features
29 of 34
Circuit board
Board material Phenolic/paper (FR2)
Glass-Epoxy (FR4)
Composite materials
IPC 9850 Glass verification panel
Optionally:
Ceramics
Auer carriers
Flex foil
Board artwork material / Hot Air Solder Leveled (HASL)
surface finish Bare copper with OSP
Electroless Ni / Immersion AU
Board range min (L x W) 50 x 50mm (L = Board transport direction)
50 x 25mm optional
Board range max (L x W) AX-3 : 475 x 390mm
(L = Board transport direction)
475 x 457mm optional
AX-5 : 515 x 390mm
(L = Board transport direction)
515 x 457mm optional
Y/X ratio < 2.5
Board thickness 0.3 - 6mm. Optional other transport systems are
available like 11 mm for boats
Pre-mounted components Max. 20mm bottomside, max. 6.3mm topside
Warpage (Flatness) Topside: Max. 0.6% of diagonal to max +2mm
Bottomside: Max. -2mm (due to board weight)
Edge clearance 3mm from front and rear edge of board
Board weight < 2 kg
Transport direction Standard left to right
Optional right to left
4.4 Board
specifications
Features
30 of 34
AX-layout
Dimensions and installation requirements
AX-3 AX-5
Maximum height 1905mm (+25 / -0 SMEMA)
(incl. light tower)
Topside standard placement 1290mm (+25 / -0 SMEMA)
robot
Board transport 940mm (+25 / -0 SMEMA)
Ambient temperature 15-35°C functions guaranteed
20-28°C specifications guaranteed
Humidity 20-90%, no dew
Floor flatness < 1%
Power supply 200-480V 3-phase, 47-63Hz,
AX-3: 5 kVA, AX-5: 7 kVA
Air supply 6-8 bar, 150 Nl/min 6-8 bar, 230 Nl/min
(Tape feeding only) (Tape feeding only)
6-8 bar, 185 NI/min 6-8 bar, 290 Nl/min
(Tape & Bulk feeding) (Tape & Bulk feeding)
Width including trolleys 2285mm
Length 2760mm 3720mm
Weight (excl trolleys) <2500kg <3200kg
4.5 Installation
requirements
Figure 18
