© 2023 Nordson Corporation 1-1

1 Introduction

1.1 Overview

The Spectrum II S2-9XXX Series is a high-volume, in-line dispensing system that delivers high speed

and accuracy for today’s most demanding semiconductor package and Printed Circuit Board (PCB)

assembly.

This manual is intended primarily as a reference for specially trained process engineers and service

technicians. However, others unfamiliar with Asymtek products may also find this manual useful as a

general introduction to the system. This section covers the following topics:

• Training

• Supported Applications

• Supported Dispensing Fluids

• Feature Description

• S2-9XXX Series Overview

• System Illustrations

1.2 System Description

The dispensing system provides exceptional dispensing accuracy, repeatability, and is ideal for high-

volume manufacturing. The dispensing system dispenses precise small dots and consistent thin lines,

coats and underfills in hard-to-reach areas, has a small footprint that maximizes floor-space, and increases

throughput. The dispensing system performs with a wide range of fluids, processes, and substrates and

easily integrates with jets and valves from Asymtek.

The system utilizes Asymtek’s Fluidmove software, the same industry-proven software package used on

all Asymtek dispensing systems. Complete recipes written on one machine can be copied to other

Asymtek dispensing systems within the factory and around the world. Unique, automated set-up software

prompts users at the beginning of production runs, making it easy to set up and begin dispensing with less

operator interaction.

1.3 Safety First

Operation of your dispensing system involves heat, air pressure, electrical power, mechanical devices,

and the use of hazardous materials. Read this manual in its entirety before attempting any system or

component operation. It is essential for all personnel working on or around the dispensing system to fully

understand the hazards, risks, and safety precautions associated with operating the system. When properly

operated and maintained, the dispensing system is safe and reliable. See Section 2 - Safety for additional

information.

WARNING! Consult the Safety Data Sheet (SDS) for all fluids used with the dispensing

system. The SDS provides material usage instructions, disposal instructions, and

safety precautions.

S2-9XXX Series Dispensing System IOM Manual Introduction

1-2 © 2023 Nordson Corporation

1.4 Training

Training is available both on-site and at regional support centers depending on the need. Contact your

local service organization. Contact information is listed at the front of this manual.

1.5 Supported Dispensing Fluids

The dispensing system is designed for dispensing the following materials. Contact Asymtek for materials

not listed.

• Flip Chip & Chip Scale Package (CSP) Underfill materials

• Dam and Fill Encapsulation materials

• LED Encapsulation materials (silicon based)

• Lid Seal materials

• Reagent dispense materials

• Silicones

WARNING! Consult the Safety Data Sheet (SDS) for all fluids used with the dispensing

system. The SDS provides material usage instructions, disposal instructions, and

safety precautions.
