8 Parts Replacement

8.1 Overview

This section includes general information for ordering recommended spares and replacement parts for

your dispensing system. This section contains the following topics:

• Parts Ordering Information • Replacing Components Inside the Dispensing

Area Door

• Record Keeping

• Replacing the Conveyer Belts

• Unpacking and Inspecting

Replacement Parts

• Replacing Control Panel Components

• Cleaning and Inspection • Replacing Components Inside the Lower Front

Door

• Removing and Installing the Top

Cover and Components

• Replacing Components Inside the Rear Door

Panel

• Removing and Installing the

Dispense Station Cover

• Replacing Fuses

• Replacing the Dispense Station

Components

• Spare Parts List

• Replacing the Camera Lens and

Mechanical/Tactical Height Sensor

WARNING! Parts replacement should only be performed by a trained service technician.

Asymtek assumes no liability for personal injury or property damage that may

occur as a result of spare parts being replaced by a non-certified technician.

8.2 Safety First

Operation of your dispensing system involves heat, air pressure, electrical power, mechanical devices,

and the use of hazardous materials. Read this manual in its entirety before attempting any system or

component operation. It is essential for all personnel working on or around the dispensing system to fully

understand the hazards, risks, and safety precautions associated with operating the system. When properly

operated and maintained, the dispensing system is safe and reliable. See Section 2 - Safety for additional

information.

WARNING! Perform a service shutdown before replacing parts. Servicing electrical,

pneumatic, or hydraulic components or assemblies that make de-energizing the

whole system impractical, should only be performed by trained personnel. There

should always be a second person present when servicing a system under power.

S2-9XXX Series Dispensing System IOM Manual Parts Replacement

WARNING! DO NOT hot swap connections when working with electrical and pneumatic

power supplies. Turn the main circuit break off before disconnecting the external

power plug from the facility.

8.3 Parts Ordering Information

8.3.1 Placing Your Order

Customers can order spare parts by contacting Asymtek Customer Service. Contact information is listed

in the front of this manual. Spare parts can also be ordered online through our Internet Web Store. To set

up a web store account, send an email to americas.es.cs@nordson.com.

NOTE This section does not include the removal and replacement of dispensing valve

components. Refer to the applicable applicator(s) manual for instructions.

When ordering parts, be prepared to provide the following information:

• Your Company Name

• Billing Address

• Shipping Address

• Part Number and Description

• Purchase Order Number

• Quantity

• Dispensing System Serial Number

(found on back panel)

• Shipping Instructions with Collect Account

Number

8.3.2 Shipping Instructions

When ordering parts, specify which carrier you prefer to use and provide your shipping account number.

If no instructions are received, Asymtek will determine the best shipping method and items will be

shipped prepaid with the shipping charge added to the invoice.

8.4 Warranty

Contact Asymtek Technical Support for any warranty issues pertaining to spare parts. Wear items and

consumables are covered under warranty against manufacturer defect only. Expected lifetimes for these

parts will vary based upon application and use.

Consumable parts are generally considered as parts that are replaced on a frequency of > 1 per calendar

year under expected regular usage. In most cases, these parts are “wetted parts” that make contact with

the dispensed fluid. Wear items are those items that have been identified to have limited life expectancy

(less than 5 years) but are not considered consumables. Wear items are often highly application

dependent, high user-touch, or adjusted parts.

8.5 Credit and Exchanges

Contact Asymtek Customer Service for credit or exchanges of recommended spare parts or refurbished

components (components restored to original specifications but not sold as new).
