S2-9XXX Series Dispensing System IOM Manual Parts Replacement
© 2023 Nordson Corporation 8-49
8.18.3 Panel Mounted Fuses
These glass fuses are located on the front panel of the conveyor/heater module. The fuses protect the
module from damage caused by power surges from the heater tooling.
To remove and replace panel-mounted fuses (Figure 8-39):
1. Perform a service shutdown, see 2.14 Service Shutdown.
2. Open the lower front door.
3. With your fingers, gently push in and turn the fuse holder counterclockwise until the head
of the fuse holder pops out enough to allow you to grasp it.
4. Pull the fuse holder out of its socket.
5. Measure the fuse impedance.
6. If the fuse impedance reads infinity, the fuse is bad.
7. Discard the damaged fuse.
8. Verify that you will be installing the correct replacement fuse and then insert the new fuse
into the fuse holder.
9. With your fingers, simultaneously push and twist the fuse holder clockwise into the socket
until it locks into place.
10. Close the lower front door.
11. Power on the dispensing system, see 4.3 Powering on the Dispensing System.
Figure 8-39 Replacing a Panel-Mounted Fuse
S2-9XXX Series Dispensing System IOM Manual Parts Replacement
8-50 © 2023 Nordson Corporation
8.19 Spare Parts List
This section contains a list of item numbers corresponding to the part description. Review the spare parts
listing Excel file for the item number referencing the part number when ordering replacements parts for
the S2-9XXX Dispensing System. Contact Asymtek Technical Support for questions.
Table 8-6 Spare Parts List
Item Number
Description
1
KIT, T1 S2-900 O-RING CNVYR, 1 STN
INSERT, TOP, O-RING, S-920
ASSY, S-9XX O-RING PULLEY
BELT, ORING, 3 X 1265, ESD
KIT, DISP, STN COMMON PARTS
2
KIT, T1 S2-900 O-RING CNVYR, 2 STN
SCREW, M4 X 0.7 SOCKET FLAT X 12
SCREW, M4 X 0.7, SOCKET X 10
SENSOR, BOARD, LOW PROFILE
INSERT, TOP, O-RING, S-920
ASSY, S-9XX O-RING PULLEY
BELT, ORING, 3 X 1730, ESD
ASSY, STOP PIN, S-9XX
KIT, DISP, STN COMMON PARTS
ASSY, RAIL EXT.SET, O-RING BELT
3
KIT, T1 S2-900 O-RING CNVYR, 3 STN
SCREW, M4 X 0.7 SOCKET FLAT X 12
SCREW, M4 X 0.7, SOCKET X 10
SENSOR, BOARD, LOW PROFILE
INSERT, TOP, O-RING, S-920
ASSY, S-9XX O-RING PULLEY
BELT, ORING, 3 X 2195, ESD
ASSY, STOP PIN, S-9XX
KIT, DISP, STN COMMON PARTS
ASSY, RAIL EXT.SET, O-RING BELT
4
KIT, T1 S2-900 4MM BELT CNVYR, 1 STN
SCREW, M4 X 0.7 SOCKET FLAT X 12
RETAINER, BELT, CMP
BELT, FLAT, 3.6 X 1.4 X 1350, ESD
INSERT, TOP, O-RING, S-920
ASSY, S-9XX 4MM BELT PULLEY
KIT, DISP, STN COMMON PARTS
5
KIT, T1 S2-900 4MM BELT CNVYR, 2 STN
SCREW, M4 X 0.7 SOCKET FLAT X 12
SCREW, M4 X 0.7, SOCKET X 10
SENSOR, BOARD, LOW PROFILE
RETAINER, BELT, CMP
BELT, FLAT 3.6 X 1.4 X 1850, ESD
INSERT, TOP, O-RING, S-920
S2-9XXX Series Dispensing System IOM Manual Parts Replacement
© 2023 Nordson Corporation 8-51
Item Number
Description
ASSY, S-9XX 4MM BELT PULLEY
ASSY, STOP PIN, S-9XX
KIT, DISP, STN COMMON PARTS
ASSY, RAIL EXT.SET, 4MM BELT
6
KIT, T1 S2-900 4MM BELT CNVYR, 3 STN
SCREW, M4 X 0.7 SOCKET FLAT X 12
SCREW, M4 X 0.7, SOCKET X 10
SENSOR, BOARD, LOW PROFILE
RETAINER, BELT, CMP
BELT, FLAT 3.6 X 1.4 X 2340, ESD
INSERT, TOP, O-RING, S-920
ASSY, S-9XX 4MM BELT PULLEY
ASSY, STOP PIN, S-9XX
KIT, DISP, STN COMMON PARTS
ASSY, RAIL EXT.SET, 4MM BELT
7
KIT, T1 S2-900 6MM BELT CNVYR, 1 STN
SCREW, M4 X 0.7 SOCKET FLAT X 12
SCREW, M3 X.05 FLAT
RETAINER, BELT, CMP
INSERT, TOP, FLAT BLT, CHAIN, S920
ASSY, S-9XX 6MM BELT PULLEY
BELT, FLAT, 5.7 X 1.4 X 1350, ESD
KIT, DISP, STN COMMON PARTS
8
KIT, T1 S2-900 6MM BELT CNVYR, 2 STN
SCREW, M4 X 0.7 SOCKET FLAT X 12
SCREW, M4 X 0.7, SOCKET X 10
SCREW, M3 X .05 FLAT
SENSOR, BOARD, LOW PROFILE
RETAINER, BELT, CMP
INSERT, TOP, FLAT BLT, CHAIN, S920
ASSY, S-9XX 6MM BELT PULLEY
BELT, FLAT, 5.7 X 1.4 X 1850
ASSY, STOP PIN, S-9XX
ASSY, RAIL EXT. SET, 6MM BELT
KIT, DISP, STN COMMON PARTS
9
KIT, T1 S2-900 6MM BELT CNVYR, 3 STN
SCREW, M4 X 0.7 SOCKET FLAT X 12
SCREW, M4 X 0.7, SOCKET X 10
SCREW, M3 X .05 FLAT
SENSOR, BOARD, LOW PROFILE
RETAINER, BELT, CMP
INSERT, TOP, FLAT BLT, CHAIN, S920
ASSY, S-9XX 6MM BELT PULLEY
BELT, FLAT, 5.7 X 1.4 X 2350
ASSY, STOP PIN, S-9XX
