3-C 軽 量 多機能 ヘッド Light Weight Multi-Functional Head パーツレイアウト Kit No. キット品 番 Kit Name キット名称 KXFX03YJA00 ｾｸｼｮﾝNo. PARTS LAYOUT Section No. S19
Ref
No.
Remarks
R
1
Q't
y
3-B
軽
量
多機能
ヘッド
Light Weight Multi-Functional Head
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
KXFX03YJA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
NUT
3
1 KXFB0APSA00
HOLDER
3
2 N210017657AB
RING
3
3 KXFB0APTB00
HOLDER
3
4 KXFB0APUB00
CYLINDER
3
5 KXFB0APVA00
PISTON
3
6 KXFB0ATVA00
COLLAR
3
7 KXFB0ATXA00
CLAMP
9
8 KXFB00L1A02
FILTER
6
9 N610009394AA
RING
3
10 KXFB0ATYA00
ARM
3
11 KXFB00HMA02
PIECE
3
12 KXFB029SA00
RING
3
13 KXFB0ATZA00
SCREW
3
14 KXFB06HWA00
DOG
3
15 N210026984AA
BEARING
6
16 KXF0AL1AA00 6803ZZ
C-RING
6
17 KXF0A74AA00 STW-9
PACKING
24
18 KXF05YHAA00 MYA-6
JOINT
3
19 KXF02T7AA00 M-5H-4
DIAPHRAGM
3
20 KXF0DZHVA00 DM2-13-13-T2.NN501(DDA)
BALL-SPLINE
3
21 N510015534AA TL6CSMS+66LPM(11590322X021)
SPRING
6
22 N210076717AA
BEARING
12
23 KXF0DZXDA00 F-679
JOINT
6
24 KXF02T4AA00 M-5AU-6
SHIM
9
25 KXF0E253A00 SEO-9-12-0.3-SUS
SPRING
12
26 KXF0E07FA00 SP(DA KXF0E07FA00)
FASTENER
6
27 KXF0DKMAA00 BX2.5-8(DA 0DKMA)
TUBE
3
28 KXF0DS4AA00 Silicon tube 8607 D6XD3(120mm)
BOLT
18
29 N510017251AA
Hexagon socket head cap screw M2.6X6-10.9 A2J (Trivalent)
BOLT
3
30 N510017258AA
Hexagon socket head cap screw M2X5-10.9 A2J (Trivalent)
BOLT
12
31 N510017249AA
Hexagon socket head cap screw M2.6X12-10.9 A2J (Trivalent)
O-RING
3
32 KXF0DJ1AA00 1022 1 type A
JOINT
3
33 KXF09ZNAA00 M-5HLH-6
S18
3-C
軽
量
多機能
ヘッド
Light Weight Multi-Functional Head
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
KXFX03YJA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
S19
Ref
No.
Remarks
R
1
Q't
y
3-C
軽
量
多機能
ヘッド
Light Weight Multi-Functional Head
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
KXFX03YJA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
1
1 N210042810AA
HOUSING
1
2 KXFB0AU9A00
JOINT
3
3 KXFB0APXA00
PLATE
1
4 N210010129AA
FLANGE
3
5 KXFB0AQBA01
PLATE
3
6 N210016068AA
BLOCK
1
7 N210042811AA
JOINT
3
8 KXFB0APZA00
PLATE
3
9 KXFB02J4A00
BRACKET
1
10 N210007814AA
PLATE
1
11 N210007693AA
BRACKET
1
12 N210026981AA
PLATE
1
13 KXFB0AUBA00
STOPPER
5
14 KXFB0AQ7A00
PLATE
1
15 N210026979AA
MOTOR
3
16 N510042739AA P50BA2003BCS4C
PIN
16
17 KXF09WMAA00 MS4-8
LOCK-NUT
3
18 KXF062CAA00 WBK06L-01
BEARING
3
19 KXF0DJSAA00 70M6DF/GMP5
BALL-SCREW
3
20 N510010686AA BLK0812S-3GT+127LCp3R(B)(31612397K020)
LINEAR-WAY
3
21 KXF0CWZAA01 LWHD12C1R117E398(DDA)
JOINT
3
22 KXF0CX0AA00 IN-233-797(DDA)
WASHER
3
23 KXF0CUXAA00 WASB10-6-2
PIN
5
24 KXF0CXSAA00 1017003-30008
CLAMP
1
25 KXF0DUTAA00 CKS-07-L
CAMERA
1
26 N510002507AA
S
CS8620i-20
LENS
1
27 KXF0DUWAA00 NF45E(DDA)
LED-LAMP-UNIT
1
28 N510028496AA
S
LED-TK
BOLT
2
29 N510017311AA
Hexagon socket head cap screw M3X14-10.9 A2J (Trivalent)
