7OM-1603
4-4
Chapter 4 : 1. Outline of Maintenance
Speciedlubricationtools
(1) Vinyl Gloves
Use a pair of vinyl gloves to apply grease or oil by hand.
(2) Hand Grease Gun
Standard
: KH-120
Part No.
: 228A022
Maker
: Yamada Corporation
Note
(a) Use this gun only for DAPHNE EPONEX GREASE No. 1.
(b) Please purchase a hand grease gun or attachments whenever necessary.
Reference
Refer to the attached instruction manuals for the hand grease gun for the usage.
F7D1
(3) Syringe
This syringe can be used for two kinds of greases.
Use the syringes and the nozzles properly.
Two Kinds of Greases
: DAPHNE EPONEX GREASE No. 1
MOLYNOC GREASE AP1
Appearance
1
2
3
4
5
6
7
8
9
10
12
mL
SINGLE USE ONLY
TERUMO
F7D2
228A0171
216M0451
0916D712
No. 49
Length : 145 mm
T7D3
1003-002
7OM-1603
Chapter 4 : 1. Outline of Maintenance
4-51003-002
1.3 Periodic Maintenance Items
The items (inspection, cleaning, lubrication, etc.) that require periodic
maintenance are classied and described based on each individual devices.
Reference
Refer to "2. Maintenance Check List" for the maintenance based on frequency
of use.
Notice
The * marks represent that the items require maintenance only for the
rsttime.
Followthe○-markedmaintenancecycleforthesubsequentuse.
Unit Name
Inspection, Cleaning,
and Lubrication Spots
Work
Cycle of Maintenance
Daily Weekly Monthly
Every 3
month
Every 6
month
Yearly
3.2.1
Pallet
Pallet Inspection
and
Cleaning
○
Rail Inspection
○
Upper Surface Inspection
○
3.2.2
Elevator Unit
Ball Screw Lubrication
○
Frame Lower Surface Inspection
and
Cleaning
○
Linear Guide Lubrication
○
Belt Inspection
○
Elevator Clamp Rod Inspection
○
3.2.3
Magazine Base
Cylinder Connection
Section
Lubrication
○
Magazine Rail Lubrication
○
3.2.4
Magazine
Rack Shutter Fulcrum
Section
Lubrication
○
T7D4
7OM-1603
4-6
Chapter 4 : 1. Outline of Maintenance
Unit Name
Inspection, Cleaning,
and Lubrication Spots
Work
Cycle of Maintenance
Daily Weekly Monthly
Every 3
month
Every 6
month
Yearly
3.2.5
Traverse Cart
Pallet Receiver Inspection
○
Linear Guide Lubrication
○
Elevator Clamper Lubrication
○
Positioning Pin Lubrication
○
Pallet Chuck Lubrication
○
Groove on Feeder Base Cleaning
○
Upper Surface of Feeder
Base
Cleaning
○
Reel Box Cleaning
○
Scrap Box Cleaning
○
3.2.5.1
Cutter Unit
Cutter Box Inside Cleaning
○
Linear Guide Lubrication
○
Flat Ring
Replacement
○
Fluorine Sheet
Replacement
○
Urethane Clamp
Replacement
○
T7D5
