Safe-8
Safety Precautions
7OM-1603
3. Alert Indications in Instruction Manual
1102-003
Alert Indications described as "
CAUTION
"
Alert Description Related Items
Because the magazine is heavy, take care handling it when it is moved.
Otherwise, you might injure your arm or waist.
"3.4" in
"Chapter 1"
Residual voltages may remain behind for a few minutes in the
internal devices of the machine after power interception.
Before performing maintenance work, wait until the charge lamps of
the dc power supply and the servo amplier go "OFF" in 10 minutes
or more after the power breaker is set to "OFF.
"1.1" in
"Chapter 4"
After the maintenance work, be sure to attach the cover back in
place.
"3.2.2" and
"3.2.5" in
"Chapter 4"
Safe-9
Safety Precautions
7OM-1603
4. Alert Labels
0908-001
4. Alert Labels
The alert labels (described below) are used for this machine.
Please read the instructions on each label carefully and check the contents, observing the
actual object.
Be sure to follow the instructions for safety purposes.
These labels should be kept clean and easily legible at a far safe distance.
When a label has deteriorated and become illegible, contact our service department for
the replacement with a new one.
Location of Alert Labels
The alert labels are afxed on dangerous and caution-required areas.
Refer to "Alert Labels and Description" for details.
Safe-10
Safety Precautions
7OM-1603
4. Alert Labels
1102-003
Elevator Section
66
66
A
Sectional View A-A'
A'
(1-2)
(4)
(6)
(5)
(2)
(1-1)(3)
DANGER
High Voltage Area!
Avoid electric shock.
WARNING
Otherwise, an injury will result due
to breakage of the machine.
Stepping on Machine
Prohibited!
WARNING
Otherwise, an injury will resul t due
to breakage of the machine.
Stepping on Ma chine
Prohibited!
WARNING
Trained Personnel Only!
Electric Shock or Hazardous Area
WARNING
Trained Personnel Only!
Electric Shock or Hazardous Area
DANGER
High Voltage Area!
Avoid electric shock.
WARNING
Moving Mechanisms!
WARNING
Moving Mechanisms!
WARNING
Moving Mechanisms!
WARNING
Keep the door closed during
operation.
Otherwise, part of your body may be trapped
in the moving mechanisms, causing an injury.
Do not keep the door open during operation.
WARNING
Keep the door closed during
operation.
Otherwise, part of your body may be trapped
in the moving mechanisms, causing an injury.
Do not keep the door open during operation.
WARNING
Keep the door closed during
operation.
Otherwise, part of your body may be trapped
in the moving mechanisms, causing an injury.
Do not keep the door open during operation.
WARNING
Keep the door closed during
operation.
Otherwise, part of your body may be trapped
in the moving mechanisms, causing an injury.
Do not keep the door open during operation.
WARNING
Prevent fingers
being pinched.
WARNING
Prevent fing ers
being p inche d.
(7)
Be Careful because the
machine might down.
Be Careful because the
machine might down.
