Installation Manual Station Software Version 601.02 SP1 Edition 10/2005

40 of 82

Menu item

Note

Selection options

Virus Warning

If the option is enabled, you will receive a warning if a

program wishes to write to the boot sector or the partition

table of the hard disk.

Enabled

Disabled

CPU Internal Cache

This option allows the internal cache to be enabled or

disabled.

Enabled

Disabled

External Cache

You can enable the external cache here. Enabled

Disabled

CPU L2 Cache ECC

Checking

The ECC checking function of the level 2 cache of the CPU

can be set here.

Enabled

Disabled

Quick Power On Self

Test

This field enables the self-test to be speeded up when you

power on the computer (POST), by dispensing with a

second, third and fourth test of the SDRAM. For each test,

the system is tested once completely.

Enabled

Disabled

First Boot Device

First device from which to boot Floppy; LS120; HDD-0;

SCSI; CDROM; HDD-1;

HDD-2; HDD-3; ZIP100;

USB-FDD; USB-ZIP;

USB-CDROM; USB-

HDD; LAN; Disabled

Second Boot Device

Second device from which to boot Floppy; LS120; HDD-0;

SCSI; CDROM; HDD-1;

HDD-2; HDD-3; ZIP100;

USB-FDD; USB-ZIP;

USB-CDROM; USB-

HDD; LAN; Disabled

Third Boot Device

Third device from which to boot

Floppy; LS120; HDD-0;

CDROM; HDD-1; HDD-

2; HDD-3; ZIP100; USB-

FDD; USB-ZIP; USB-

CDROM; USB-HDD;

LAN; Disabled

Other Boot Device

If none of the set boot devices were found, a search is

made for all possible devices which can be set as a boot

device in one of the three options above, if this entry is set

to Enabled.

Enabled

Disabled

Swap Floppy Drive

If the drive letters assigned to floppy drives are to be

exchanged, this field must be set to Enabled.

Enabled

Disabled

Boot Up Floppy

Seek

If this option is enabled, the BIOS looks for the floppy

drive A once

Enabled

Disabled

Boot Up Numlock

Status

The user can enable the NumLock function here (numbers

on the numeric block on the keyboard) when the system

boots.

Off

Enabled caches enhance system performance

Installation Manual Station Software Version 601.02 SP1 Edition 10/2005

41 of 82

Menu item

Note

Selection options

Gate A20 Option

When Fast is set, the keyboard controller switches Gate

A20, otherwise the processor does this.

Normal

Fast

Typematic Rate

Setting

When this field has been enabled, the following two

keyboard settings appear.

Enabled

Disabled

Typematic Rate

(Chars/Sec)

This field controls the speed at which the system registers

a key which is pressed and held as a keystroke.

6; 8; 10; 12; 15; 20; 24;

Typematic Delay

(msec)

This field controls the delay before keystrokes begin to

repeat.

250

; 500; 750; 1000

Security Option

This determines when the system requests the password

(password: see PASSWORD SETTING).

System: The password is requested every time the system

boots.

Setup: The password is only requested when you call the

Setup utility.

Setup

System

APIC Mode

Under Windows 2000 and Windows XP, more interrupts

are available when this option is enabled

Disabled

Enabled

MPS Version

Control For OS

1.1

1.4

OS Select For

DRAM > 64MB

If the system operates under OS/2 with main memory

greater than 64 MB, this option must be set to OS2.

Non-OS2

OS2

HDD S.M.A.R.T

Capability

SMART (Self Monitoring Analyse and Reporting

Technology) is implemented in modern hard disks. This

technology can detect reading or rotational speed

problems. Data is read with the appropriate software.

Enabled

Disabled

Award Preboot

Agent

If this option is Enabled, all video outputs based on INT10

(e.g. all outputs made during the POST), are additionally

output via a serial interface to a connected, VT100-

compatible terminal. Keystrokes which are based on INT16

can also be made on the VT100 keyboard.

If this option is Enabled and no terminal or no VT100-

compatible terminal is connected, the following message

appears when the system is started up

"Award Preboot Agent Installation Failed"

The terminal must be set to the following values:

Transfer rate 19200 Baud

Data Bits 8

Stop Bits 1

Enabled

Disabled

Agent after Boot

If the preboot agent is enabled, this option can be used to

set whether the console is still to be redirected (enabled) at

the beginning of the boot process or to be disabled when

the POST is finished.

Disabled

Enabled

Report No FDD For

WIN 95

If this option is set to Yes, no floppy drive will be registered

in Windows 95.

Yes

Installation Manual Station Software Version 601.02 SP1 Edition 10/2005

42 of 82

Menu item

Note

Selection options

C8000-CBFFF

CC000-CFFFF

D0000-D3FFF

D4000-D7FFF

D8000-DBFFF

DC000-DFFFF

Shadow

If this option is enabled, a BIOS extension which is found

in this address range is copied to the same address in

main memory, for the purpose of faster execution.

Disabled

Enabled

Small Logo (EPA)

Show

This specifies whether the EPA logo is displayed in the top

right corner of the monitor when the system is started

Enabled

Disabled

4.5.1.8 Setup page "Advanced Chipset Features"

In the "Selection options" column, the setting for fail-safe default is indicated in italics and the setting

for optimized default is underlined

Menu item Note Selection options

SDRAM CAS latency

Time

The latency time between a SDRAM read command and

the actual availability of the data is set here.

Auto

SDRAM Cycle Time

Tras/Trc

This option is used to specify the time for which a memory

cell of the SDRAM is kept open in order to access the cells

available in the same line

7/9

5/7

Auto

SDRAM RAS-to-CAS

Delay

The delay between the SDRAM enable command and the

SDRAM read/write command can be changed in this field.

Auto

SDRAM RAS

Precharge Time

The time after a precharge command for a bank until the

bank can be accessed.

Auto

System BIOS

Cacheable

This function enables the system to cache the BIOS area

as well.

Enabled

Disabled

Video BIOS

Cacheable

This function enables the system to cache the VGA-BIOS

area as well.

Enabled

Disabled

Memory Hole At

15M-16M

If this function is enabled, the memory hole from 15 MB

through 16 MB is reserved for ISA expansion boards which

require this setting. Depending on the operating system

used, the memory ceases to be available to the system as

of 15 MB. Expansion boards can only address memories

of up to 16 MB.

Enabled

Disabled

CPU Latency Timer

Enabled

Disabled

Delayed Transaction

When set to Enabled, this option enables the 32-bit write

buffer for PCI access.

Enabled

Disabled
