Installation Manual Station Software Version 601.02 SP1 Edition 10/2005 48 of 82 4.5.1.11 Setup page "Power Management Setup" Menu item Note Selection options ACPI Support ACPI version 1.0 is implemented in the…

100%1 / 165
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
47 of 82
Menu item Note Selection options
Use of LED L2
prim./sec. HD: The LED is lit when a primary or
secondary
hard disk is activated
User: The LED can be switched on/off by the
user
(Bit 0 of I/O address 5400H)
prim./sec. HD:
User
IOCHCK-NMI
This option specifies whether the NMI is enabled or
disabled after the boot process.
Enabled
Disabled
On board SRAM size
This sets the size of an address window on the onboard
SRAM. The following settings are possible:
Other settings can be made by the user's application.
Disabled
8 KByte
16 KByte
32 KByte
On board SRAM
base adr.
This value is used to specify the base address of the
SRAM window. This value can only be set if the SRAM is
not disabled. The choice of base address depends on the
window size which has been set.
CC000H
1)
CE000H
2)
D0000H
3)
D2000H
2)
D4000H
1)
D6000H
2)
D8000H
3)
DA000H
2)
DC000H
1)
DE000H
2)
Fanless Operation
When this option is enabled, the module can be operated
without fans. The processor then only operates for 50 % of
the time.
Enabled
Disabled
1) with SRAM size 8/16 KByte 2) with SRAM size 8 KByte 3) with SRAM size 8/16/32 KByte
4) This item is only visible for processors = 866MHz
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
48 of 82
4.5.1.11 Setup page "Power Management Setup"
Menu item Note Selection options
ACPI Support
ACPI version 1.0 is implemented in the BIOS. Statuses S1
and S3 are supported by the hardware of the
CPCI-/SMP16-
CPU076.
Enabled, ACPI is only supported automatically as of Win98.
When installing Win95, ACPI installation must be initiated by
hand.
Disabled means that ACPI is also not supported for an
ACPI-compatible operating system.
Enabled
Disabled
ACPI Suspend Type
Specifies the status in which the computer shuts down in
Suspend Mode using ACPI.
S1 (POS)
S3 (STR)
Power Management
This field is the main switch for the power saving modes.
There are three settings:
Max Saving Switches the computer after a brief time of
inactivity to power saving mode.
Min Saving Works almost exactly in the same
way as Max Saving, but the inactivity time
required for switching is longer.
User Defined Enables the power saving mode options to
be set individually.
User Define
Min Saving
Max Saving
Video Off Method
This sets the way in which the monitor is switched to power
saving mode. There are three options available:
DPMS (Display Power Management) enables the
BIOS to control DPMS-compatible graphics.
Blank Screen Darkens the screen and
should be used with monitors without Power
Management functions.
V/H Sync+Blank darkens the screen by switching
vertical and horizontal
scanning.
Blank Screen
V/H Sync+Blank
DPMS
Video Off In
Suspend
Specifies whether the monitor interface is switched off in
suspend mode (no sync signals)
No
Yes
MODEM Use IRQ
This option determines which IRQ registers the ring tone of
the modem for faxing.
NA
; 3; 4; 5; 7;9; 10; 11
Suspend Mode
The time is set here before the system switches to suspend
mode.
Disabled
;
1 Min; 2 Min;
4 Min; 8 Min;
12 Min; 20 Min;
30 Min; 40 Min;
1 Hour
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
49 of 82
Menu item Note Selection options
HDD Power Down
The time is set here after which the hard disk is switched to
Power Down mode
Disabled
;
1 Min; 2 Min;
3 Min; 4 Min;
5 Min; 6 Min;
7 Min; 8 Min;
9 Min; 10 Min;
11 Min; 12 Min;
13 Min; 14 Min;
15 Min
USB KB Wake-Up
From S3
If disabled is set, the system cannot by woken up from the
S3 state (Suspend to RAM) by a USB keyboard.
Enabled
Disabled
CPU Thermal-
Throttling
If the system begins to throttle due to a thermal overload,
this is the ratio in percent: switch-off time / (switch-off time +
on time). This value is factory set and cannot be changed.
87,5%
Resume by Alarm
If this option is switched on, the computer is retrieved from
power saving mode at the specified date and time. If 0 is
specified as a date, this is done on a daily basis.
Enabled
Disabled
Date (of Month)
Alarm
all values between 0 and
31
0
Time (hh:mm:ss)
Alarm
valid time
0:0:0
Reload Global
Timer Events
Every event of a device listed below resets the global
counter for suspend mode, if this is enabled.
Enabled
Disabled
