Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
63 of 82
Menu item Note Selection options Settings Note
Third Boot
Device
Third device from which to boot Floppy; LS120; HDD-0;
SCSI; CDROM; HDD-1;
HDD-2; HDD-3; ZIP100;
USB-FDD; USB-ZIP;
USB-CDROM; USB-
HDD; LAN; Disabled
Disabled
Floppy cannot be
selected with
Legacy Free
Boot Other
Device
If none of the set boot devices were found, a search is
made for all possible devices which can be set as a
boot device in one of the three options above, if this
entry is set to Enabled.
Enabled
Disabled
Enabled
Swap Floppy
Drive
If the drive letters assigned to floppy drives are to be
exchanged, this field must be set to Enabled.
Enabled
Disabled
Disabled Menu item not
available with
Legacy Free
Boot Up
Floppy Seek
If this option is enabled, the BIOS looks for the floppy
drive A once.
Enabled
Disabled
Disabled
Menu item not
available with
Legacy Free
Boot Up
Numlock
Status
The user can enable the NumLock function here
(numbers on the numeric block on the keyboard) when
the system boots.
On
Off
On
Typematic
Rate Setting
When this field has been enabled, the following two
keyboard settings appear.
Enabled
Disabled
Disabled Menu item not
available with
Legacy Free
Typematic
Rate
(Chars/Sec)
This field controls the speed at which the system
registers a key which is pressed and held as a
keystroke.
6; 8; 10; 12; 15; 20; 24;
30
6 Menu item not
available with
Legacy Free
Typematic
Delay (msec)
This field controls the delay before keystrokes begin to
repeat.
250; 500; 750; 1000 250 Menu item not
available with
Legacy Free
Security
Option
This determines when the system requests the
password (password: see PASSWORD SETTING).
System: The password is requested every time the
system boots.
Setup: The password is only requested when you call
the Setup utility.
Setup
System
Setup
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
64 of 82
Menu item Note Selection options Settings Note
APIC Mode
Under Windows 2000 and Windows XP, more
interrupts are available when this option is enabled
Disabled
Enabled
Enabled
MPS Version
Control For OS
1.1
1.4
1.1
OS Select For
DRAM > 64MB
If the system operates under OS/2 with main memory
greater than 64 MB, this option must be set to OS2.
Non-OS2
OS2
Non-OS2
HDD S.M.A.R.T
Capability
SMART (Self Monitoring Analyse and Reporting
Technology) is implemented in modern hard disks. This
technology can detect reading or rotational speed
problems. Data is read with the appropriate software
provided by the hard disk vendor.
Disabled
Enabled
Enabled
Report No FDD
For WIN 95
If this option is set to Yes, no floppy drive will be
registered in Windows 95.
No
Yes
No
C8000-CBFFF
CC000-CFFFF
D0000-D3FFF
D4000-D7FFF
D8000-DBFFF
DC000-DFFFF
Shadow
If this option is enabled, a BIOS extension which is
found in this address range is copied to the same
address in main memory, for the purpose of faster
execution.
Disabled
Enabled
Disabled
Small Logo
(EPA) Show
This specifies whether the EPA logo is displayed in the
top right corner of the monitor when the system is
started
Enabled
Disabled
Disabled
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
65 of 82
4.7.2.1 "CPU Feature" submenu
Menu item Note Selection options Settings Note
CPU
Frequency
Specifying a lower clock frequency and thus
reducing dissipation allows the machine to be used
without a fan at higher ambient temperatures.
Full
1,100MHz
900MHz
600MHz
Full
Thermal
Management
The processor features built-in monitoring of the
core temperature. The selected function is executed
if this threshold is exceeded.
Thermal Monitor 1: If the temperature threshold is
exceeded, the CPU clock speed is switched on and
off at a sampling rate of 50% until the temperature
falls below the threshold.
Thermal Monitor 2: If the temperature threshold is
exceeded, the CPU clock speed is slowed to a
multiple of the FSB (100 MHz). This value is
specified in TM2 Bus Ratio. Additionally, the core
voltage of the CPU is lowered to the value set in
TM2 Bus VID. Both these actions reduce the
dissipation of the CPU. After the temperature falls
below the threshold again, the maximum value of
16X/1.484V is reset.
Disabled: Internal processor monitoring is disabled.
Thermal Monitor 1
Thermal Monitor 2
Disabled
Thermal
Monitor 1
TM2 Bus Ratio
Multiple of the FSB (100 or 133MHz). The CPU
clock speed is reduced to this value if the internal
temperature threshold is exceeded.
6X; 7X; 8X; 9X; 10X; 11X;
12X; 13X; 14X; 15X; 16X
16X at
1.6GHz
11X at
1.1GHz
9X at
900MHz
6X at
600MHz
