Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
64 of 82
Menu item Note Selection options Settings Note
APIC Mode
Under Windows 2000 and Windows XP, more
interrupts are available when this option is enabled
Disabled
Enabled
Enabled
MPS Version
Control For OS
1.1
1.4
1.1
OS Select For
DRAM > 64MB
If the system operates under OS/2 with main memory
greater than 64 MB, this option must be set to OS2.
Non-OS2
OS2
Non-OS2
HDD S.M.A.R.T
Capability
SMART (Self Monitoring Analyse and Reporting
Technology) is implemented in modern hard disks. This
technology can detect reading or rotational speed
problems. Data is read with the appropriate software
provided by the hard disk vendor.
Disabled
Enabled
Enabled
Report No FDD
For WIN 95
If this option is set to Yes, no floppy drive will be
registered in Windows 95.
No
Yes
No
C8000-CBFFF
CC000-CFFFF
D0000-D3FFF
D4000-D7FFF
D8000-DBFFF
DC000-DFFFF
Shadow
If this option is enabled, a BIOS extension which is
found in this address range is copied to the same
address in main memory, for the purpose of faster
execution.
Disabled
Enabled
Disabled
Small Logo
(EPA) Show
This specifies whether the EPA logo is displayed in the
top right corner of the monitor when the system is
started
Enabled
Disabled
Disabled
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
65 of 82
4.7.2.1 "CPU Feature" submenu
Menu item Note Selection options Settings Note
CPU
Frequency
Specifying a lower clock frequency and thus
reducing dissipation allows the machine to be used
without a fan at higher ambient temperatures.
Full
1,100MHz
900MHz
600MHz
Full
Thermal
Management
The processor features built-in monitoring of the
core temperature. The selected function is executed
if this threshold is exceeded.
Thermal Monitor 1: If the temperature threshold is
exceeded, the CPU clock speed is switched on and
off at a sampling rate of 50% until the temperature
falls below the threshold.
Thermal Monitor 2: If the temperature threshold is
exceeded, the CPU clock speed is slowed to a
multiple of the FSB (100 MHz). This value is
specified in TM2 Bus Ratio. Additionally, the core
voltage of the CPU is lowered to the value set in
TM2 Bus VID. Both these actions reduce the
dissipation of the CPU. After the temperature falls
below the threshold again, the maximum value of
16X/1.484V is reset.
Disabled: Internal processor monitoring is disabled.
Thermal Monitor 1
Thermal Monitor 2
Disabled
Thermal
Monitor 1
TM2 Bus Ratio
Multiple of the FSB (100 or 133MHz). The CPU
clock speed is reduced to this value if the internal
temperature threshold is exceeded.
6X; 7X; 8X; 9X; 10X; 11X;
12X; 13X; 14X; 15X; 16X
16X at
1.6GHz
11X at
1.1GHz
9X at
900MHz
6X at
600MHz
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
66 of 82
4.7.3 Setup page "Advanced Chipset Features"
Menu item Note Selection options Settings Note
DRAM Data
Integrity Mode
If ECC memory modules are fitted, this setting
allows you to specify whether or not ECC is used.
This menu item cannot be changed if ECC memory
modules are not fitted.
Non-ECC
ECC
Non-ECC
MGM Core
Frequency
Specifies the frequency for the FSB, the memory
interface and the graphics controller.
The first entry specifies the FSB. If Auto is
specified, the default value for the processor is
used.
The second entry specifies the frequency of the
memory interface. Max sets the maximum possible
frequency (specified in the SPD of the DDR
SODIMM). If the frequency is changed from 333 to
266/200 or from 266 to 200, a Power On is
necessary after you exit Setup.
The third entry specifies the fixed clock frequency of
the graphics core.
In all other cases, the third and fourth values specify
the upper and lower limit for the graphics core. The
graphics controller switches dynamically within the
specified range depending on the load.
Auto Max 266MHz
400/266/133/200 MHz
400/200/100/200 MHz
400/200/100/233 MHz
400/266/133/267 MHz
400/333/166/250 MHz
Auto Max 400/333MHz
Auto Max
400/333MHz
System BIOS
Cacheable
This function enables the system to cache the BIOS
area as well.
Enabled
Disabled
Enabled
Video BIOS
Cacheable
This function enables the system to cache the VGA-
BIOS area as well.
Enabled
Disabled
Enabled
Memory Hole At
15M-16M
If this function is enabled, the memory hole from 15
MB through 16 MB is reserved for ISA expansion
boards which require this setting. Depending on the
operating system used, the memory ceases to be
available to the system as of 15 MB. Expansion
boards can only address memories of up to 16 MB.
Enabled
Disabled
Disabled
Delayed
Transaction
When set to Enabled, this option enables the 32-bit
write buffer for PCI access.
Enabled
Disabled
Enabled
