Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
70 of 82
Menu item Note Selection options Settings Note
IDE Secondary
Slave PIO
Sets the PIO mode for the slave on the secondary
IDE channel. Higher values mean faster access.
Auto sets the maximum permissible value for the
disk.
Auto; Mode 0;
Mode 1; Mode 2;
Mode 3; Mode 4
Auto
IDE Secondary
Master UDMA
If Auto is set, UDMA mode is enabled for the master
on the secondary IDE channel if it is supported by
the disk.
Auto;
Disabled
Auto
IDE Secondary
Slave UDMA
If Auto is set, UDMA mode is enabled for the slave
on the secondary IDE channel if it is supported by
the disk.
Auto;
Disabled
Auto
UDMA66/100
allowed
In the specification for UDMA66 and UDMA100, an
80-pin cable is required. You can use this option to
also run drives which support these modes with a
short 40-pin cable on the secondary IDE channel.
No;
Yes
No
IDE HDD Block
Mode
This enables the transfer of entire blocks from the
hard disk to the memory instead of individual
sectors.
Enabled
Disabled
Enabled
Delay for HDD
(Secs)
Time the CPU waits before accessing connected
ATA devices (e.g. hard disks, CD ROMs).
0; 1; 2; 3; 4; 5; 6; 7; 8; 9;
10; 11; 12; 13; 14; 15
0 As of BIOS
V1.05c
Onboard Device
Menu item Note Selection options Settings Note
USB Controller
If this setting is disabled, the USB controller is disabled and
no USB devices can be run on the module.
Enabled
Disabled
Enabled
USB 2.0
Controller
If this setting is disabled, the USB 2.0 controller is disabled
and no USB 2.0 devices can be run in USB 2.0 mode on
the module. Such devices are then run as USB 1.1
devices.
Enabled
Disabled
Enabled
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
71 of 82
Menu item Note Selection options Settings Note
USB Keyboard
Support
When this option is switched on, a keyboard is supported
on the USB port even after the boot process.
Enabled
Disabled
Enabled
(Enabled for
Legacy
Free)
USB Mouse
Support
When this option is switched on, a mouse is supported on
the USB port even after the boot process.
Enabled
Disabled
Disabled
(Enabled for
Legacy
Free)
AC 97 Audio
If an AC 97 audio controller is connected to the RPIO, it
can be switched on here
Auto Disabled
AC 97 Modem
If an AC 97 modem controller is connected to the RPIO, it
can be switched on here
Enabled
Disabled
Disabled
Init Display First
This option can be used to specify which graphics adapter
is to be used to output video if a PCI graphics adapter is
integrated in the system in addition to the onboard graphics
adapter. If a graphics adapter is connected to the SMP16
bus, this is always used to output video irrespective of the
setting.
Onboard
PCI Slot
Onboard
Onboard Gigabit
LAN
Disabled disables the onboard LAN controller. Enabled
Disabled
Disabled
Only visible if a
Gigabit LAN is
fitted
Onboard LAN
Disabled disables the onboard LAN controller. Enabled
Disabled
Enabled
Onboard LAN
Boot ROM
In order to boot from the onboard LAN controller, this item
must be enabled.
Enabled
Disabled
Disabled
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
72 of 82
SuperIO Device (item not available with Legacy Free)
Menu item Note Selection options Settings Note
Onboard FDC
Controller
Enables the onboard floppy controller Enabled
Disabled
Disabled
Onboard Serial
Port 1
Sets the I/O addresses and IRQs of serial port 1 (COM
A)
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled
3F8/IRQ4
Onboard Serial
Port 2
Sets the I/O addresses and IRQs of serial port 2 (COM
B):
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled
2F8/IRQ3
Onboard Parallel
Port
Sets the I/O addresses and IRQs of the parallel port: 378/IRQ7
3BC/IRQ7
Disabled
Disabled
Parallel Port
Mode
Sets the mode of the parallel port. This option can be set
when disabled is not set for Onboard Parallel Port
Default
SPP
EPP1.7
EPP1.9
ECP
ECP+EPP
Default
ECP Mode Use
DMA
This option can only be set if ECP or ECP+EPP is
selected for Parallel Port Mode.
1
3
1
