Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
72 of 82
SuperIO Device (item not available with Legacy Free)
Menu item Note Selection options Settings Note
Onboard FDC
Controller
Enables the onboard floppy controller Enabled
Disabled
Disabled
Onboard Serial
Port 1
Sets the I/O addresses and IRQs of serial port 1 (COM
A)
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled
3F8/IRQ4
Onboard Serial
Port 2
Sets the I/O addresses and IRQs of serial port 2 (COM
B):
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled
2F8/IRQ3
Onboard Parallel
Port
Sets the I/O addresses and IRQs of the parallel port: 378/IRQ7
3BC/IRQ7
Disabled
Disabled
Parallel Port
Mode
Sets the mode of the parallel port. This option can be set
when disabled is not set for Onboard Parallel Port
Default
SPP
EPP1.7
EPP1.9
ECP
ECP+EPP
Default
ECP Mode Use
DMA
This option can only be set if ECP or ECP+EPP is
selected for Parallel Port Mode.
1
3
1
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
73 of 82
4.7.5 Setup page "IMC Miscellaneous"
Menu item Note Selection options Settings Note
Priority for PCI
Bridge
Assigns a higher priority to the PCI bridge to the CPCI
bus in busmaster operation. This may be needed if high
data transfer rates between the CPCI bus and RAM are
required.
Normal
High
Normal
Boot Delay
This can be used to set a delay during which the BIOS
waits until the operating system has been booted.
Disabled
15 Sec.
30 Sec.
45 Sec.
60 Sec
1:30 Min.
2 Min.
3 Min.
5 Min.
10 Min.
Disabled
Enable CTRL-
C/CTRL-Break
When No is entered, the keystrokes <CTRL-C>/<CTRL-
Break> are trapped by the BIOS and not passed on to
the operating system. The keys can be re-enabled by
entering Yes. This function can also be changed by the
user during live operation. If a software interrupt of 16h is
triggered with AH = 3, AL = 49h and BL = 0, <CTRL-
C>/<CTRL-Break> is permitted, and these key
combinations are suppressed with BL = 1.
Yes
No
Yes
SMP16-Bus
If this option is set to disabled, the SMP16 bus will be
switched to high resistance after the boot process.
Adapters on this bus cannot be accessed.
Enabled
Disabled
Disabled
Menu item not
available with
Legacy Free
SMP16-Clocks
This option can be used to switch off the 8.33 MHz and
14.131 MHz clock cycle of the SMP16 bus. This setting is
only possible when the SMP16 bus is enabled.
Enabled
Disabled
Disabled
Menu item not
available with
Legacy Free
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
74 of 82
Menu item Note Selection options Settings Note
8 Bit I/O
Recovery Time
Number of additional ISA clock cycles between two 8-bit
I/O accesses to the SMP16 bus.
1 ... 16 1
Menu item not
available with
Legacy Free
16 Bit I/O
Recovery Time
Number of additional ISA clock cycles between two 16-bit
I/O accesses to the SMP16 bus.
1 ... 16 1
Menu item not
available with
Legacy Free
Use of LED L1
LAN speed:
The LED is lit when the onboard
LAN is activated and the
transfer speed is 100MB
User:
The LED can be switched on and
off by the user
(Bit 1 of I/O address 5400H)
LAN speed:
User
LAN speed:
Use of LED L2
prim./sec. HD: The LED is lit when a primary or
secondary hard disk is accessed
User: The LED can be switched on/off by
the user
(Bit 0 of I/O address 5400H)
prim./sec. HD:
User
Pri./sec. HD
IOCHCK-NMI
This option specifies whether the NMI is enabled or
disabled after the boot process.
Enabled
Disabled
Disabled
Show Logo at
Boot
Specifies whether the logo (enabled) or POST output
(disabled) is displayed.
Enabled
Disabled
Disabled
