Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
74 of 82
Menu item Note Selection options Settings Note
8 Bit I/O
Recovery Time
Number of additional ISA clock cycles between two 8-bit
I/O accesses to the SMP16 bus.
1 ... 16 1
Menu item not
available with
Legacy Free
16 Bit I/O
Recovery Time
Number of additional ISA clock cycles between two 16-bit
I/O accesses to the SMP16 bus.
1 ... 16 1
Menu item not
available with
Legacy Free
Use of LED L1
LAN speed:
The LED is lit when the onboard
LAN is activated and the
transfer speed is 100MB
User:
The LED can be switched on and
off by the user
(Bit 1 of I/O address 5400H)
LAN speed:
User
LAN speed:
Use of LED L2
prim./sec. HD: The LED is lit when a primary or
secondary hard disk is accessed
User: The LED can be switched on/off by
the user
(Bit 0 of I/O address 5400H)
prim./sec. HD:
User
Pri./sec. HD
IOCHCK-NMI
This option specifies whether the NMI is enabled or
disabled after the boot process.
Enabled
Disabled
Disabled
Show Logo at
Boot
Specifies whether the logo (enabled) or POST output
(disabled) is displayed.
Enabled
Disabled
Disabled
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
75 of 82
4.7.6 Setup page "Power Management Setup"
Menu item Note Selection options Settings Note
ACPI Function
ACPI version 1.0 is implemented in the BIOS. Statuses
S1 and S3 are supported by the hardware.
Enabled, ACPI is only supported automatically as of
Win98. When installing Win95, ACPI installation must be
initiated by hand.
Disabled means that ACPI is also not supported for an
ACPI-compatible operating system.
Enabled
Disabled
Enabled
Power
Management
This field is the main switch for the power saving modes.
There are three settings:
Max Saving Switches the computer to
power saving mode after a brief
time of inactivity.
Min Saving Works almost exactly in the
same way as Max Saving, but the
inactivity time required for switching
is longer.
User Defined Enables the power saving
mode options to be set individually.
User Define
Min Saving
Max Saving
User Define
Installation Manual Station Software Version 601.02 SP1 Edition 10/2005
76 of 82
Menu item Note Selection options Settings Note
Video Off
Method
This sets the way in which the monitor is switched to
power saving mode. There are three options available:
DPMS (Display Power Management)
enables the BIOS to control
DPMS-capable graphics cards.
Blank Screen Darkens the screen and
should be used with monitors
without Power Management
functions.
V/H Sync+Blank Darkens the screen by switching
off the vertical and horizontal
synchronization.
Blank Screen
V/H Sync+Blank
DPMS
DPMS
Video Off In
Suspend
Specifies whether the monitor interface is switched off in
suspend mode (no sync signals)
No
Yes
Yes
MODEM Use IRQ
This option determines which IRQ registers the ring tone
of the modem for faxing.
NA; 3; 4; 5; 7;9; 10;
11
NA
Suspend Mode
The time is set here before the system switches to
suspend mode.
Disabled;
1 Min; 2 Min;
4 Min; 8 Min;
12 Min; 20 Min;
30 Min; 40 Min;
1 Hour
Disabled
HDD Power
Down
The time is set here after which the hard disk is switched
to Power Down mode
Disabled;
1 Min; 2 Min;
3 Min; 4 Min;
5 Min; 6 Min;
7 Min; 8 Min;
9 Min; 10 Min;
11 Min; 12 Min;
13 Min; 14 Min;
15 Min
Disabled
