CP-842E-02 PART LIST - 第329页
PNEUMATIC CIRCUIT DIAGRAM(PI) 1/3 エアー配管図(PI) 1/3 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考 No. Drg.No. & Code No. QTY Description Rating Materials Remarks 49 K50764 1 CONNECTOR ｺﾈｸﾀ KQ2U06-01S OT 50 Y3067A 2 UNION ﾕﾆｵﾝ KQ2H0…
PNEUMATIC CIRCUIT DIAGRAM(PI) 1/3
エアー配管図(PI) 1/3
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
1 H1059T 1 VALVE, BALL ﾊﾞﾙﾌﾞ ﾎﾞｰﾙ RP-LL-3/8 OT
2 H30297 1 FILTER REGULATOR ﾌｨﾙﾀﾚｷﾞｭﾚｰﾀ AW3000-02-BD OT
3 S4016R 1 SEPARATOR, MIST ｾﾊﾟﾚｰﾀ ﾐｽﾄ AFM3000-02-D OT
4 A1038Y 1 SW, PRESSURE SW ﾌﾟﾚｯｼｬ AP-40Z OT
5 WPL5012 1 CYLINDER ｼﾘﾝﾀﾞ KA25X8.2-813W OT
6 H1077T 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL PCS242-M5-D24-SP OT
7 S1058A 4 SILENCER ｻｲﾚﾝｻ AN120-M5 OT
8 A4063E 1 ELBOW ｴﾙﾎﾞ QMQ6-5M812 OT
9 DCPH0680 16 VALVE, MECHANICAL ﾊﾞﾙﾌﾞ ﾒｶﾆｶﾙ MDV235-ZB OT
10 S3150H 1 SW, PRESSURE SW ﾌﾟﾚｯｼｬ AP-43 OT
11 S1053A 2 SILENCER ｻｲﾚﾝｻ SL-1 OT
13 S31495 1 SW, PRESSURE SW ﾌﾟﾚｯｼｬ AP-41 OT
15 H1062X 1 VALVE, MECHANICAL ﾊﾞﾙﾌﾞ ﾒｶﾆｶﾙ 80-VM133-M5-01 OT
18 K5345D 1 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2211F-01-06S(ｼﾛ) OT
19 H10669 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F15T2-F4-PL3-DC24V OT
20 DGSS0080 3 CYLINDER ｼﾘﾝﾀﾞ CRB-0041WY OT
21 ACSQL0240 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F10M2AJ-24W OT
22 S2210A 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDAS32X15-ZE202B2 OT
23 S22076 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQSB12-25DC-F9NWL OT
24 S2209A 8 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDAS16X15-ZE202B1 OT
26 DGQL0020 1 CYLINDER, RODLESS ｼﾘﾝﾀﾞ ﾛｯﾄﾞﾚｽ ORK16X653-412W OT
27 DGQL0030 1 CYLINDER, RODLESS ｼﾘﾝﾀﾞ ﾛｯﾄﾞﾚｽ ORK16X602-411W OT
28 H1066K 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F10T2-F4-PL3-DC24V OT
30 T1063F 1 DUCT ﾀﾞｸﾄ NPS50 OT
31 ADGQL8010 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F15M2J-9WY OT
32 H5447Z 1 PUMP, VACUUM ﾎﾟﾝﾌﾟ ﾊﾞｷｭｰﾑ KHA750A-306-G1 OT
33 A1038Y 1 SW, PRESSURE SW ﾌﾟﾚｯｼｬ AP-40Z OT
34 S5213A 1 BLOWER, VORTEX 送風器 渦流 2BH1-500-7AH21-G31 OT
36 K5335F 4 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ ASD330F-01-06S(ｼﾛ) OT
37 S1056A 4 SILENCER ｻｲﾚﾝｻ AN101-01 OT
38 K5335A 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ JSU-4 OT
40 H1037E 1 VALVE, MANUAL ﾊﾞﾙﾌﾞ 手動 HV6-6 OT
41 H1006T 1 GENERATOR, VACUUM 発生器 真空 VDBL12P8-06-SA OT
42 K5342D 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-06S(ｼﾛ) OT
43 DCPU0190 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CRB-0006W OT
45 H1081N 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL PCS245-01-D24-SP OT
47 K5347W 5 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2301F-01-06S(ｼﾛ) OT
48 Y3082C 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2V06-01S OT
318
PNEUMATIC CIRCUIT DIAGRAM(PI) 1/3
エアー配管図(PI) 1/3
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
49 K50764 1 CONNECTOR ｺﾈｸﾀ KQ2U06-01S OT
50 Y3067A 2 UNION ﾕﾆｵﾝ KQ2H06-00 OT
52 A4146A 2 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ EL8-PT1/4 OT
53 A4147A 4 ELBOW ｴﾙﾎﾞ EL8-PT1/8 OT
57 K53710 4 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ EC6-PT1/8 OT
58 H3149A 1 PLUG, COUPLER ﾌﾟﾗｸﾞ ｶﾌﾟﾗ 20PM OT
70 H1031F 1 VALVE, PRESSURE REDUCING バルブ 減圧 IR1020-01BG OT
71
Y3078A
2
UNION, ELBOW
ユニオン エルボ
KQ2L06-01S
OT
319
