Station Software Version 712.1 (R19-1) / Installation Manual 05/2019 Edition
18
---
CPPSZD
1)
Z-bottom, CPP head
---
WPCAXI
2)
WPC5 feed axis and lift axis
---
WPCHNG
2)
WPC5 / WPC6
---
DLMHED
3)
C&P12 head
---
GATWAY
CAN sensor gateway
Table 4-2: Names of the subsystems
1)
as of 702.xx
2)
as of 703.xx
3)
as of 705.03
Station Software Version 712.1 (R19-1) / Installation Manual 05/2019 Edition
19
4.2 Hardware Components of SIPLACE Series X, X S, SX, DX, CA and
TX
4.2.1 Station Computer
Name
SIMATIC BoxPC 627B
CPU / clock frequency
Core 2 Duo T7400 / 2.16 GHz
RAM
2 GB
Harddisk
HDD
Serial interfaces
1
USB interfaces
Yes
Network
2x 100 MBit
Table 4-3: Station computer hardware SIPLACE X-, SX- and DX-series
Name
SIMATIC BoxPC 827B
CPU / clock frequency
Core 2 Duo T7400 / 2.16 GHz
RAM
2 GB
Harddisk
HDD
Internal DVD drive
Yes
Serial interfaces
1
USB interfaces
Yes
Network
2x 100 MBit
Table 4-4: Station computer hardware SIPLACE X-, SX- and DX-series
Name
SIMATIC BoxPC 627C
CPU / clock frequency
Intel® Celeron® P4505 / 1.87 GHz
RAM
2 GB
Harddisk
HDD
Serial interfaces
1
USB interfaces
Yes
Network
2x 100 MBit
Table 4-5: Station computer hardware SIPLACE X-, X S-, SX-, DX-series
Station Software Version 712.1 (R19-1) / Installation Manual 05/2019 Edition
20
Name
SIMATIC BoxPC 827C
CPU / clock frequency
Intel® Core
(TM)
i3 / 2.13 GHz
RAM
2 GB
Harddisk
HDD
Serial interfaces
1
USB interfaces
Yes
Network
2x 100 MBit
Table 4-6: Station computer hardware SIPLACE X-, X S-, SX-, DX- and CA-series
Name
SIMATIC BoxPC 627D/827D
CPU / clock frequency
Intel® Core(TM) i3 / 2,40 GHz
Exchange PC for 60x:
Intel® Celeron® G1820TE / 2,20 GHz
RAM
4 GB
Harddisk
SSD
Serial interfaces
1
USB interfaces
Yes
Network
2x 1000 MBit
Table 4-7: Station computer hardware SIPLACE X- and CA-series
Name
iBase ABP 402-A
CPU / clock frequency
Intel® Celeron® CPU 1020E / 2,2 GHz
RAM
4 GB
Harddisk
SSD (SX-series), HDD (E by SIPLACE)
Serial interfaces
2
USB interfaces
Yes
Network
2x 1000 MBit
Table 4-8: Station computer hardware SIPLACE SX-series, E by SIPLACE
Name
SIMATIC MicroBox 427D
CPU / clock frequency
Intel® Core
(TM)
/ 1,6 GHz
RAM
4 GB
Harddisk
SSD
Serial interfaces
1
USB interfaces
Yes
Network
2x 1000 Mbit
Table 4-9: Station computer hardware SIPLACE X-Series S, TX- and CA-series
