P-0309-002 - 第249页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE Fig. F1 0912-002 Fig. F1-3 201 0914B90B MONITOR_BASE_F 1 1091301200-001 202 21 1AE232 COVER 1 1091301200-002 203 4U210136 UNIT_DISPLA Y 1 1091301200-003 204 21 1AD957 COVE…
0912-002
207
208
211
215
216
217
213
211
212
213
213
204
203
210
214
202
209
201
A
211
DETAIL ”A”
241
256
250
250
256
256
258
261
258
258
256
256
249
250
257
258
261
249
253
254
255
259
258
250
256
248
256
257
257
256
242
243
244
245
247
246
256
251
254
252
254
218
260
Fig. F1-3
パネル、スイッチ
Panel, Switch
Fig. F1
パネル、中央フレーム部
Panel, Frame SECTION
UNIT-5
Fig. F1
PANEL
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. F1
0912-002
Fig. F1-3
201 0914B90B MONITOR_BASE_F 1 1091301200-001
202 211AE232 COVER 1 1091301200-002
203 4U210136 UNIT_DISPLAY 1 1091301200-003
204 211AD957 COVER 1 1091301200-004
207 211AD970 COVER 1 1091301200-007
208 211AD969 COVER 1 1091301200-008
209 211AE094 COVER 1 1091301200-009
210 221AA100 ROHS_HEX-SCT 4 1091301200-010
211 221DA202 MACHINE_SCREW 4 1091301200-011
212 221DA217 RO_MACHIN_SCREW 4 1091301200-012
213 221DA207 MACHINE_SCREW 10 1091301200-013
214 221DA138 MACHINE_SCREW 2 1091301200-014
215 221FA007 NUT_HEX 4 1091301200-015
216 221HA004 WASHER 4 1091301200-016
217 221HA104 WASHER 4 1091301200-017
218 0914B90D MONITOR ANDER C 1 1091301200-018
241 0913B201 S_MONITOR_PANEL 1 1091301202-001
242 4S1B0085 SWITCH_BUTTON 1 1091301202-002
243 4T400003 DISPLAY_ELEMENT 1 1091301202-003
244 23H20029 ACCESSORY_SW 1 1091301202-004
245 4S1B0032 SWITCH_BUTTON 1 1091301202-005
246 4S1B0012 SWITCH_BUTTON 1 1091301202-006
247 23H20003 ACCESSORY_SW 1 1091301202-007
248 4S1B0180 SWITCH_BUTTON 1 1091301202-008
249 9W310121 CORD 1 1091301202-009
250 9W310122 CORD 1 1091301202-010
251 23K10437 CASE_CONN 1 1091301202-011
252 23K10434 CASE_CONN 1 1091301202-012
253 23K10406 CASE_CONN 1 1091301202-013
254 4J300175 CAB_JOINTTERMIN 17 1091301202-014
255 0914B907 TERMINAL 6 1091301202-015
256 23N20103 TUBE_WIRING 25 1091301202-016
257 23N20117 TUBE_WIRING 10 1091301202-017
258 23N30737 ACCESS_WIRING(M 5 1091301202-018
259 23N20115 TUBE_WIRING 6 1091301202-019
260 6P452703 NAME_PLATE 1 1091301202-020
261 23N30011 ACCESSORY_WRING 2 1091301202-021
UNIT-5
Fig. F1
PANEL
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
MEMO
