P-0309-002 - 第57页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 101 210B4501 FRAME 1 1092004200-001 103 213A1614 SHAFT 1 1092004200-003 104 21 1FD760 BRACKET 2 1092004200-004 105 21 1K3654 SUPPORT 1 1092004200-005 106 21 1K3655 SUPPORT…
Fig. C1-2
フレーム部
Frame Section
0912-002
111 1
109
107
116
114
121
145
121
143
117
118
115
110
107
113
108
123
125
126
123
125
126
123
125
126
123
125
126
144
123
125
126
123
125
126
134
134
136
137
133
136
137
136
137
128
129
130
133
136
137
119
101
103
105
104
104
106
139
138
119
119
131
136
131
136
131
136
1
19
131
136
122
120
120
132
136
137
132
136
137
135
136
137
135
136
137
140
141
142
140
141
142
138
139
133
136
137
133
136
137
124
125
127
127
146
Fig. C1
カート部
CART SECTION
UNIT-2
Fig. C1
CART
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
101 210B4501 FRAME 1 1092004200-001
103 213A1614 SHAFT 1
1092004200-003
104 211FD760 BRACKET 2
1092004200-004
105 211K3654 SUPPORT 1
1092004200-005
106 211K3655 SUPPORT 1
1092004200-006
107 211FE029 BRACKET 2
1092004200-007
108 211K3699 SUPPORT 1
1092004200-008
109 211K3700 SUPPORT 1
1092004200-009
110 211AE229 COVER 1
1092004200-010
111 211AE230 COVER 1
1092004200-011
113 211FE225 BRACKET 1
1092004200-013
114 0920E20N BRACKET 1
1092004200-014
115 0920E20J SAFTY COVER 2 1
1092004200-015
116 0920E20H SAFTY COVER 1 1
1092004200-016
117 0920E20P PLATE 1
1092004200-017
118 212A2483 GUIDE 1
1092004200-018
119 226E0069 CASTER 4
1092004200-019
120 226J2295 MECH PARTS(CASTER) 2
1092004200-020
121 226D0122 GRIP 2
1092004200-021
122 223R0111 CHAIN 1
1092004200-022
123 221AA016 ROHS:BOLT_HEX-SCT 18
1092004200-023
124 221AA019 ROHS:BOLT_HEX-SCT 1
1092004200-024
125 221HA004 WASHER 19
1092004200-025
126 221HA104 WASHER 18
1092004200-026
127 221HA302 BW04W 3
1092004200-027
128 221AA028 ROHS:BOLT_HEX-SCT 2
1092004200-028
129 221HA005 WASHER 2
1092004200-029
130 221HA105 WASHER 2
1092004200-030
131 221AA140 ROHS:BOLT,HEX-SCT 16
1092004200-031
132 221AA041 ROHS:BOLT_HEX-SCT 4
1092004200-032
133 221AA042 ROHS:BOLT_HEX-SCT 16
1092004200-033
134 221AA043 ROHS:BOLT_HEX-SCT 8
1092004200-034
135 221AA044 ROHS:BOLT_HEX-SCT 2
1092004200-035
136 221HA006 WASHER 46
1092004200-036
137 221HA106 WASHER 30
1092004200-037
138 221BA030 ROHS:BOLT_HEX 4
1092004200-038
139 221FA011 NUT_HEX 4
1092004200-039
140 221BA032 ROHS:BOLT_HEX 4
1092004200-040
141 221HA007 WASHER 4
1092004200-041
142 221HA107 WASHER 4
1092004200-042
143 0920E20D BALL PLANGERS 1
1092004200-043
144 221FA012 NUT_HEX 1
1092004200-044
145 0929E00K DOOR_SW_ACTUATOR 1
1092004200-045
146 221AA017 ROHS:BOLT_HEX-SCT 2
1092004200-046
Fig. C1
0912-002
Fig. C1-2
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
UNIT-2
Fig. C1
CART
Fig. C1-3
リールホルダ
Reel Holder
0912-002
203
209
209
208
207
213
202
205
204
203
233
210
201
206
206
218
224
225
215
216
217
218
224
225
226
235
234
236
237
221
222
223
219
224
225
219
224
225
220
212
214
See Fig C1-2
Key No.101
Fig. C1
カート部
CART SECTION
UNIT-2
Fig. C1
CART
