P-0309-002 - 第58页
Fig. C1-3 リールホルダ Reel Holder 0912-002 203 209 209 208 207 213 202 205 204 203 233 210 201 206 206 218 224 225 215 216 217 218 224 225 226 235 234 236 237 221 222 223 219 224 225 219 224 225 220 212 214 See Fig C1-2 Key N…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
101 210B4501 FRAME 1 1092004200-001
103 213A1614 SHAFT 1
1092004200-003
104 211FD760 BRACKET 2
1092004200-004
105 211K3654 SUPPORT 1
1092004200-005
106 211K3655 SUPPORT 1
1092004200-006
107 211FE029 BRACKET 2
1092004200-007
108 211K3699 SUPPORT 1
1092004200-008
109 211K3700 SUPPORT 1
1092004200-009
110 211AE229 COVER 1
1092004200-010
111 211AE230 COVER 1
1092004200-011
113 211FE225 BRACKET 1
1092004200-013
114 0920E20N BRACKET 1
1092004200-014
115 0920E20J SAFTY COVER 2 1
1092004200-015
116 0920E20H SAFTY COVER 1 1
1092004200-016
117 0920E20P PLATE 1
1092004200-017
118 212A2483 GUIDE 1
1092004200-018
119 226E0069 CASTER 4
1092004200-019
120 226J2295 MECH PARTS(CASTER) 2
1092004200-020
121 226D0122 GRIP 2
1092004200-021
122 223R0111 CHAIN 1
1092004200-022
123 221AA016 ROHS:BOLT_HEX-SCT 18
1092004200-023
124 221AA019 ROHS:BOLT_HEX-SCT 1
1092004200-024
125 221HA004 WASHER 19
1092004200-025
126 221HA104 WASHER 18
1092004200-026
127 221HA302 BW04W 3
1092004200-027
128 221AA028 ROHS:BOLT_HEX-SCT 2
1092004200-028
129 221HA005 WASHER 2
1092004200-029
130 221HA105 WASHER 2
1092004200-030
131 221AA140 ROHS:BOLT,HEX-SCT 16
1092004200-031
132 221AA041 ROHS:BOLT_HEX-SCT 4
1092004200-032
133 221AA042 ROHS:BOLT_HEX-SCT 16
1092004200-033
134 221AA043 ROHS:BOLT_HEX-SCT 8
1092004200-034
135 221AA044 ROHS:BOLT_HEX-SCT 2
1092004200-035
136 221HA006 WASHER 46
1092004200-036
137 221HA106 WASHER 30
1092004200-037
138 221BA030 ROHS:BOLT_HEX 4
1092004200-038
139 221FA011 NUT_HEX 4
1092004200-039
140 221BA032 ROHS:BOLT_HEX 4
1092004200-040
141 221HA007 WASHER 4
1092004200-041
142 221HA107 WASHER 4
1092004200-042
143 0920E20D BALL PLANGERS 1
1092004200-043
144 221FA012 NUT_HEX 1
1092004200-044
145 0929E00K DOOR_SW_ACTUATOR 1
1092004200-045
146 221AA017 ROHS:BOLT_HEX-SCT 2
1092004200-046
Fig. C1
0912-002
Fig. C1-2
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
UNIT-2
Fig. C1
CART
Fig. C1-3
リールホルダ
Reel Holder
0912-002
203
209
209
208
207
213
202
205
204
203
233
210
201
206
206
218
224
225
215
216
217
218
224
225
226
235
234
236
237
221
222
223
219
224
225
219
224
225
220
212
214
See Fig C1-2
Key No.101
Fig. C1
カート部
CART SECTION
UNIT-2
Fig. C1
CART
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
201 211B1554 BOX 1 1092004201-001
202 211DE982 PLATE 29
1092004201-002
203 0920E20K LEVER 1 28
1092004201-003
204 213A1627 SHAFT 1
1092004201-004
205 211K3701 SUPPORT 1
1092004201-005
206 216A1625 COLLAR 2
1092004201-006
207 212A2735 GUIDE 1
1092004201-007
208 211DE544 PLATE 1
1092004201-008
209 0920E20L LEVER 2 2
1092004201-009
210 211DE552 PLATE 1
1092004201-010
212 211DF010 PLATE 1
1092004201-012
213 0920E20G HINGE(SH-51C 2
1092004201-013
214 221DA203 MACHINE SCREW 8
1092004201-014
215 221FA005 NUT_HEX 8
1092004201-015
216 221HA103 WASHER 8
1092004201-016
217 221HA003 WASHER 8
1092004201-017
218 221AA028 ROHS:BOLT_HEX-SCT 10
1092004201-018
219 221AA029 ROHS:BOLT_HEX-SCT 2
1092004201-019
220 221DA209 MACHINE SCREW 4
1092004201-020
221 221FA007 NUT_HEX 4
1092004201-021
222 221HA004 WASHER 4
1092004201-022
223 221HA104 WASHER 4
1092004201-023
224 221HA005 WASHER 12
1092004201-024
225 221HA105 WASHER 12
1092004201-025
226 221DA212 MACHINE SCREW 1
1092004201-026
233 226J2650 MECH_PARTS 1
1092004202-003
234 221AA016 ROHS:BOLT_HEX-SCT 4
1092004202-004
235 221DA207 MACHINE SCREW 2
1092004202-005
236 221HA004 WASHER 4
1092004202-006
237 221HA104 WASHER 4
1092004202-007
Fig. C1
0912-002
Fig. C1-3
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
UNIT-2
Fig. C1
CART
