5 Product / Component User Manual Line Computer UNIX 5.1 Component Editor Software Version 501.xx 01/99 Issue 5 - 10
User Manual Line Computer UNIX 5 Product / Component
Software Version 501.xx 01/99 Issue 5.1 Component Editor
5 - 9
● Click on editing field "Comment", if required, and enter any comment desired.
● Confirm your entries by choosing OK.
The entry screen is closed, the barcode and filter entries are displayed in the display area.
NOTE
If invalid characters were used for the barcode entry (e.g. a comma), or if other digits than 1 or 0 were
used for entering the filter, or of the length of the barcode does not coincide with the length of the fil-
ter, the faulty field is displayed surrounded by a red frame as soon as the entry is confirmed by pres-
sing the RETURN key. If the RETURN key is not
pressed after each entry, faulty fields will not be
shown in a red frame until the entries are confirmed by choosing "OK". The entries must be corrected
as otherwise the entry screen will not be closed and the barcode cannot be accepted.
- Delete
It is possible to delete a created barcode.
● Select barcode entry from the display area.
● Click on Delete.
The barcode entry is no longer displayed in the display area.
- Change
An existing barcode, the associated filter or comment can be edited.
● Select the barcode entry from the display area.
● Click on Change.
The window for editing the barcode is opened (see Fig. 5.1.2).
● Click on the editing field containing the desired entry and make the change.
● Confirm the changes by choosing OK.
The entry window is closed, the edited data are displayed in the display area.
5 Product / Component User Manual Line Computer UNIX
5.1 Component Editor Software Version 501.xx 01/99 Issue
5 - 10
User Manual Line Computer UNIX
Software Version 501.xx 01/99 Issue
6 - I
Contents
Page
Product / Package Form
6.1 Package Form Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
6.1.1 Starting the Package Form Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
6.1.2 Main Window of Package Form Editor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 3
6.1.2.1 SERVICES Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 8
6.1.2.2 Area for general settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 9
6.1.2.3 Selection Field "Features" (PDC) - "Vision data" Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 10
6.1.2.4 Package Form Editor Command Area - "Vision data" Screen . . . . . . . . . . . . . . . . . . . . . . . 6 - 11
6.1.2.5 Package Form Editor Editing Fields - "Vision data" Screen . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 12
6.1.2.6 View area - "Vision data" Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 16
6.1.2.7 Package Form Editor Command Area - "Handling data" Screen . . . . . . . . . . . . . . . . . . . . . 6 - 18
6.1.2.8 View Area - "Handling Data" Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 23
6.1.2.9 Settings for the "Acceleration" Special Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 24
6.1.2.10 Package Form Editor Selection Fields - "Handling data" Screen. . . . . . . . . . . . . . . . . . . . . 6 - 29
6.1.2.11 Package Form Editor Editing Fields - "Handling data" Screen. . . . . . . . . . . . . . . . . . . . . . . 6 - 31
6.1.3 Package Form Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 33
6.1.3.1 Definition of the Component’s Coordinate System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 33
6.1.3.2 Description of a Package Form of the Type "FDC" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 36
6.1.3.3 Description of a Package Form of the "BGA" Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 45
