User Manual Line Computer UNIX Software Version 501.xx 01/99 Issue 9 - II
User Manual Line Computer UNIX
Software Version 501.xx 01/99 Issue
9 - I
Contents
Page
Production Tools / Feeders
9.1 Feeder Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 1
9.1.1 Allocation Possibilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 2
9.1.2 Starting the Feeder Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 3
9.1.3 Main Window of the Feeder Editor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 4
9.1.3.1 SERVICES Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 7
9.1.3.2 Selection Area "Package Form/Component" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 9
9.1.3.3 Setting Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 11
9.1.3.4 Command Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 12
9.1.4 Creating Allocations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 13
9.1.4.1 Editing Customer-Specific Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 19
9.1.4.2 Copying Customer-Specific Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 20
9.1.4.3 Terminating the Feeder Editor Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 20
User Manual Line Computer UNIX
Software Version 501.xx 01/99 Issue
9 - II
User Manual Line Computer UNIX 9 Production Tools / Feeders
Software Version 501.xx 01/99 Issue 9.1 Feeder Editor
9 - 1
9 Production Tools / Feeders
9.1 Feeder Editor
The following allocations are defined by means of the Feeder Editor:
The feeding equipment (feeder/waffle-pack tray) to be used to supply a specific package form or component
and the type of machine on which the feeder is to be set up. It is possible to specify a different feeder or
waffle-pack tray for each machine type.
NOTE
Predefined feeders or "customer-specific types" can be selected for the allocations. The so-called
"customer-specific types" are feeder or waffle-pack tray types created by the user with the aid of the
Feeder Editor whose data deviate from the standard values (see section 9.1.4).
The allocations specified in the Feeder Editor are stored in the ".ri" set-up info file in the Master data/RI-
Bibliothek. For optimization purposes it is mandatory that the ".ri"-file be always
available. The optimization
function evaluates the data from the ".ri"-file and determines where a given package form or component is
to be set up. When so doing, allocations of components have a higher weighting than allocations of package
forms, and special allocations (e.g. to a customer-specific type) carry a higher weight than general
allocations.
