9 Production Tools / Feeders User Manual Line Computer UNIX
9.1 Feeder Editor Software Version 501.xx 01/99 Issue
9 - 18
Editing feeder data:
● Click on editing field Name and enter FD_VS020 for the name of the customer-specific type.
● Click on editing field X and enter 0.010.
● Click on editing field Y and enter 0.010.
● Click on editing field Z and enter 0.
● Click on editing field Angle and enter 0.
● Click on editing field Vibrat. time and enter 250.
NOTE
To be able to immediately detect any invalid entries, the RETURN key should be pressed after each
entry. If the current entry is incorrect, the corresponding editing field will be surrounded by a red
frame.
● Click on OK for the data to be accepted. The sub-editor "Feeder data" is closed.
The name of the created customer-specific type is displayed in the selection field "Placeable
feeders".
3. Allocating the customer-specific type "FD_VSO20" to the left feeder part of the machine type
"HS180"
● Activate icon in the command area (if the Feeder Editor is still in the "selection mode").
● In the display area, click on the left feeder part of the machine type HS180 ("S_HS180").
The selected area is highlighted.
● Select the entry FD_VSO20 for the customer-specific type "FD_VSO20" in the selection field
"Placeable feeders".
In the "Feeder" selection field, the following entry for feeder, machine type and machine side is dis-
played:
FD_VSO20 S_HS180 L
4. Allocating 9.5mm-linear feeders to the feeder parts of the machine type "HS180"
● In the display area, click on the "complete" machine type "S_HS180" (see Fig. 9.1.2).
The selected machine type is highlighted.
● Select entry FD~S_LIN_95 for 9.5mm-linear feeders in the selection field "Placeable feeders".
In the "Feeder" selection field, the following entry for feeder and machine type (under the entry for
the 8mm-tape feeder) is displayed:
FD~S_LIN_95 S_HS180
User Manual Line Computer UNIX 9 Production Tools / Feeders
Software Version 501.xx 01/99 Issue 9.1 Feeder Editor
9 - 19
5. Allocating 8mm-tape feeders, electr., to the left feeder part of machine type "SIPLACE80S"
● In the display area, click on the left feeder part of the machine type SIPLACE80S ("S_S P_80S").
The selected area is highlighted.
● Select entry FD~S_G_8 for 8mm-tape feeders in the selection field "Placeable feeders".
In the "Feeder" selection field, the following entry for feeder, machine type and machine side is
displayed:
FD~S_G_8 S_SIP_80S L
6. Allocating 12mm-tape feeders to the feeder parts of machine type "SIPLACE80S"
● In the display area, click on the "complete" machine type "S_S P_80S" (see Fig. 9.1.2).
The selected machine type is highlighted.
● Select entry FD~S_G_12 for 12mm-tape feeders in the selection field "Placeable feeders".
In the "Feeder" selection field, the following entry for feeder and machine type under the entry for
the 8mm-tape feeder is displayed:
FD~S_G_12 S_SIP_80S
Saving the allocations made
● Select menu option FILE --> Save.
The current data are saved to the set-up info file ".ri".
9.1.4.1 Editing Customer-Specific Types
To edit data of customer-specific types, proceed as follows:
● Activate icon or icon in the command area.
● Select the customer-specific feeder type you wish to edit from the selection field "Placeable
feeders" by double-clicking.
The sub-editor containing the data of the selected customer-specific type is opened (see, for
example, Fig. 9.1.3).
● Click on the editing field containing the value to be edited and delete the displayed value using
the DELETE key.
● Enter the new value.
● Proceed in the same manner to make further changes that may be required.
● Click on the Select. button if a different carrier for the customer-specific type of a waffle-pack tray
is to be specified.
NOTE
Refer to section 9.1.4 from page 9 - 15 onwards, for a description of how to proceed further.
● Click on OK for the edited data to be accepted.
The sub-editor is closed.
9 Production Tools / Feeders User Manual Line Computer UNIX
9.1 Feeder Editor Software Version 501.xx 01/99 Issue
9 - 20
9.1.4.2 Copying Customer-Specific Types
Customer-specific types can be copied by proceeding as follows:
● Activate icon or icon in the command area.
● Select the customer-specific type you wish to copy from the selection field "Placeable feeders"
by double-clicking.
The sub-editor containing the data of the selected customer-specific feeder is opened (see, for
example, Fig. 9.1.4) .
● In the "Name" editing field, delete the characters contained therein by means of the DELETE key
and enter a name for the new customer-specific type.
● Click on OK for the data to be accepted.
The sub-editor is closed and the name of the copied customer-specific type is displayed in the
selection field "Placeable feeders".
9.1.4.3 Terminating the Feeder Editor Session
● Select the menu option FILE --> Quit.
The main window of the Feeder Editor is closed.
NOTE
If modified data have not been saved yet, a warning message is displayed in a dialog box which
must be acknowledged (see chapt. 2, section 2.5).
● Click on Yes to save the data prior to exiting.
The Feeder Editor is closed and the modified data are automatically saved.
● Click on No if you do not wish to save the modified data.
The Feeder Editor is closed without the edited data being saved.
