1 Hardware / Software Installati on User Manu al Line Computer UNIX 1.2 Software Install ation Software Version 501.xx 01/99 Issue 1 - 14
User Manual Line Computer UNIX 1 Hardware / Software Installation
Software Version 501.xx 01/99 Issue 1.2 Software Installation
1 - 13
A note is now displayed on the handling regarding OEM software, as well as the steps to be per-
formed following the start of the LC program (consistency check via Data Manager of setups and
line configuration).
● Read the messages and acknowledge them by pressing any key.
After a short time a message is displayed on the screen requesting you to reboot the system.
** Safe to Power Off **
- or -
** Press Any Key to Reboot **
● Remove CD-ROM and press any key on the keyboard.
The computer system reboots.
CAUTION
In the event that the boot diskette (see page 1 - 7) used for the SW installation was not the correct
one, an error message will be displayed during the shutdown process (prior to “Safe to Power Off”).
Upon the subsequent booting of the computer, the following queries have to be answered:
There may be a system dump memory image in the swap device!
Do you want to save a copy of it?
[y/n]
● Enter
n
and press RETURN.
Do you want to remove the dump from the swap device now?
[y/n]
● Enter
y
and press RETURN
.
It is imperative that the two preceding questions be answered as indicated, as otherwise problems
with the operating system are likely to arise.
Okay to check the root filesystem
[y/n]
● Enter
y
and press RETURN
.
After a while, the "Login" dialog box (see chapt. 2, section 2.1.1) appears.
● Type
plr
in the "login" editing field and press the RETURN key.
● Type
plr
in the "Password" editing field and press the RETURN key.
The LC software is started with the selected desktop configuration and language.
ATTENTION !
After any initial installation of the LC software has been carried out, it is mandatory that following
start-up of the line computer the stations be configured with the aid of the Configuration Editor (see
chapt. 12) before proceeding further. Subsequently, the line must be configured with the aid of the Line
Editor (see chapt. 12).
Whenever an Update or Upgrade of the LC software is performed, it is absolutely necessary that
after the software has been started up, all set-ups be checked for consistency using the "Consistency
Checker" (see chapt. 4, section 4.3.4.6).
1 Hardware / Software Installation User Manual Line Computer UNIX
1.2 Software Installation Software Version 501.xx 01/99 Issue
1 - 14
User Manual Line Computer UNIX
Software Version 501.xx 01/99 Issue
2 - I
Contents
Page
General Information on Using
the Program
2.1 Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3
2.1.1 Starting the Line Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 3
2.1.1.1 Working With the Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 6
2.1.1.2 Icons (meaningful symbols) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 7
2.1.1.3 Message Window (Dialog Box) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 8
2.1.2 On-Screen Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 9
2.1.3 Terminating a Working Session on the Line Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 9
2.2 Window System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 11
2.2.1 Window Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 11
2.2.2 Layout of a Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 14
2.2.3 Window Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 16
2.3 Directories / Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 19
2.3.1 Directory Name / File Name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 20
2.4 File Selector Box FSB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 21
2.4.1 Components and Use of FSB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 22
2.5 Menu Bar in the Application Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 25
2.5.1 Functions of the FILE Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 25
2.5.2 Functions of the OPTIONS Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 28
2.5.3 Functions of the HELP Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 29
2.5.3.1 Basic Information on Using the Help Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 30
