User Manual Line Computer UNIX 13 Production Tools / Set-Up
Software Version 501.xx 01/99 Issue 13.1 Set-Up Editor (Feeder Part and WPC Editors)
13 - 33
For selecting the levels in the WPC Editor the following clicking sequence must be observed:
first click on the level in the "Levels" display area, then
click on the level in the "WPC" display area.
-
Machine options of the feeder list --> Tracks (in the Feeder Part Editor)
The machine options of the feeder list (except for the waffle-pack trays) can be allocated to the tracks
of a feeder part. Only the six tracks identified in green at the upper and lower borders of the feeder
part cannot be occupied by these machine options.
-
Waffle-pack tray --> Waffle-pack tray carrier and manual trays
Waffle-pack trays are set up on waffle-pack tray carriers. A waffle-pack tray carrier can be assigned
any number of waffle-pack trays.
-
Waffle-pack tray/waffle-pack tray carrier --> Level (in the WPC Editor)
For selecting the levels in the WPC Editor the following clicking sequence must be observed:
first click on the level in the "Levels" display area, then
click on the level in the "WPC" display area.
-
Feeder (linear feeder) --> Module
Linear feeders must be set up on a module. The module must be set up before the linear feeders are
assigned to it.
-
Component --> Feeder (in the Feeder Part Editor)
The components are allocated to the feeder divisions individually. An empty division is marked in blue,
an occupied division in green.
-
Component --> Waffle-pack tray (in both editors)
Only one component type can be allocated to a waffle-pack tray. All compartments (divisions) there-
fore contain same type of component. Empty compartments are highlighted in blue, occupied com-
partments in green.
-
Nozzle --> Nozzle Changer location (division)
In addition to the configured nozzles, further nozzles can be defined in the Machine Options Editor.
-
Options of the options list --> Tracks (in the Feeder Part Editor)
The options list is required for the station configuration. The options are permanently allocated to the
tracks. The areas of the feeder part outlined in green can be allocated to the component centering
option on HS180 machines.
13 Production Tools / Set-Up User Manual Line Computer UNIX
13.1 Set-Up Editor (Feeder Part and WPC Editors) Software Version 501.xx 01/99 Issue
13 - 34
-
Delete
When this icon is active, the editor is in the deletion mode. All feeding units and components in the
display area can thus be deleted. Prior to the deletion being carried out, a dialog box is displayed
asking you to confirm the deletion.
NOTE
After the deletion operation is completed, another mode should be activated as otherwise feeding
units and components are likely to be inadvertently deleted.
Click on .
In the display area click on the feeding unit or component you want to delete.
A dialog box is displayed.
Click on
OK
if you want the deletion to be carried out, or
Cancel
if you do not want the deletion to
be executed.
NOTE
If a waffle-pack tray carrier is deleted, all waffle-pack trays set up on it are also deleted.
For the selection of levels in the WPC Editor, the following clicking sequence must be observed:
first click on the level in the "Levels" display area, then
click on the level in the "WPC" display area.
-
Move
When this icon is active, the editor is in the moving mode. All feeding units and components in the dis-
play area can thus be moved.
On a station, the feeding units can be moved within a feeder part, the components can be moved to
different feeders.
In the case of waffle-pack changers, the feeding units and components can be moved between levels.
NOTE
The clicking sequence for moving can be carried out in either direction: either, as described above,
click on the object first and then the target, or click on the target first and then the object.
If an object cannot be moved to the indicated target, a corresponding error message is displayed which
must be acknowledged.
User Manual Line Computer UNIX 13 Production Tools / Set-Up
Software Version 501.xx 01/99 Issue 13.1 Set-Up Editor (Feeder Part and WPC Editors)
13 - 35
Click on .
In the display area, click on the feeding unit or component you want to move.
Click on the new location.
The feeding unit or component is displayed at the new location.
NOTE
For selecting the levels in the WPC Editor, the following clicking sequence must be observed:
first click on the level in the "Levels" display area, then
click on the level in the "WPC" display area.
