26.PWBCONVEYORCOMPONENTS(6)
1 4
2 7
2 6
1 1
8
7
6
1
1 9
2 0
2 0
2 1
2 2
2 4
1 5
1 6
1 7
2 8
1 8
9
1 0
1 3
1 3
3
2
1 2
4
2 5
2 4
2 3
5
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 401-83552 STOPPER_ASM 1
2 HX-0031400-00 SPIRALTABE (0.3)
3 401-83036 STOPPER_FRAME_650 (1)
4 WP-0431005-SP PLAINWASHER (1)
5 SL-4030891-SC SCREWM3X8 (1)
6 400-00910 STOPPERPIN (1)
7 RE-0200000-K0 E-RING2 (1)
8 WP-0320501-SC WASHERM3 (1)
9 400-00911 STOPERCONNECT (1)
10 PA-1002008-A0 AIRCYLINDER (1)
11 SM-6031402-TN SCREWM3X0.5L=14 (2)
12 SM-1030601-SC SCREWM3X6 (4)
13 PJ-3040405-11 ELBOWUNION (2)
14 SL-6041292-TN SCREWM4L=12 (1)
15 401-83038 NUT_PLATE (1)
16 401-83035 STOPPER (1)
17 401-83066 STOPPER_CHIP_650 (1)
18 SM-1030401-SE SCREWM3L=4 (1)
19 SM-1031201-SC SCREWM3X0.5L=12 (1)
20 E2039-721-000 WASHERA (2)
21 E2038-721-000 STOPPERCOLLAR (1)
22 WP-0330516-SC WASHER3.3X8X0.5 (1)
23 HX-0034400-00 HARNESSPARTS (1)
24 NM-6030001-SC NUTM3X0.5TYPE1 (2)
25 401-56968 STOPPERSENSORASM (1)
26 PC-0124010-00 SPEEDCONTROLLER (2)
27 BT-0400251-EA URETHANETUBEBLUE4X2.5 (0.5)
28 401-83070 BU_PIN_SENSOR_DOG (1)
- -
27.PWBCONVEYORCOMPONENTS(7)
3 2
3
1 7
1
3 3
3 3
3 1
1 6
1 5
3 0
2 5
2 6
1 1
1 1
7
1 9
2 6
2 6
2 5
2 4
2 3
2 2
2 0
2 1
2 6
1 1
1 1
1 0
1 0
2 2
9
7
8
4
2
2 7
1 2
6
2 8
2 7
1 8
1 3
1 2
2 9
1 4
5
