- - 44. REPLACINGOVERA LLCHANGERT RUCKCOMPONENTS(2 ) 2 2 4 4 3 3 5 5 6 7 8 8 9 9 1 0 1 1 1 1 1 3 1 4 1 5 1 5 1 5 1 5 1 6 1 6 1 7 1 7 1 8 1 9 1 9 2 0 2 1 2 1 2 2 2 2 2 3 2 5 2 5 2 6 2 6 2 7 2 7 2 8 2 8 2 9 2 9 3 0 …

- -

REF.NO NOTE PARTNO DESCRIPTION Qty

1 401-69473 BANKIDPCB(RF)ASM 1

2 401-83119 E_BANK_BASE_R 1

3 PH-0600120-C0 PARALLELPINTYPEB6X12 4

4 EZ-4453564-01 PLUGTAPERSCREW 1

5 E2602-721-000 BANKLOCATEBUSHA 2

6 E2732-721-000 BANKGUIDEROLLER 2

7 E5721-729-000 LABEL 2

8 PH-0300080-U0 PARALLELPINTYPEB3X8 8

9 401-67554 CLAMP_BLOCK 4

10 SM-6041602-TN SCREWM4X16 12

11 PH-0300080-U0 PARALLELPINTYPEB3X8 10

#01

401-67530 GUIDE_RAIL 4

13 SM-3041052-TN SCREWM4L=10 24

14 E2609-721-000 BANKLOCATEPINA 1

15 WP-0841601-SC WASHERM8 1

16 WS-0820002-KN SPRINGWASHERM8 1

17 NM-6080003-SC NUTM8X1.25TYPE3 1

18 E2610-721-000 BANKLOCATEPINB 1

19 WP-0841601-SC WASHERM8 1

20 WS-0820002-KN SPRINGWASHERM8 1

21 NM-6080003-SC NUTM8X1.25TYPE3 1

22 401-83200 POSITIONING_PLATE 1

23 PH-0300080-U0 PARALLELPINTYPEB3X8 2

24 SL-6041692-TN SCREWM4L=16 13

25 401-83142 MARK_STAND 2

26 E2505-729-0A0 MARKASM. 2

27 E2601-725-000 MARK (1)

28 E2505-729-000 MARKBASE (1)

29 SL-6041292-TN SCREWM4L=12 4

30 SL-6052092-TN SCREWM5L=20 4

31 401-83176 CAN_CONNECTOR_BR 1

32 401-82051 CONNECTOR_BIND 112

33 SL-6051292-TN SCREWM5L=12 4

34 401-83148 BANK_PLATE_L 1

35 SL-6082092-TN SCREWM8L=20 1

36 400-94723 TOROLLEY_COV_BR 1

37 SL-6061092-TN SCREWM6L=10 2

38 401-83150 BANK_PLATE_R 1

39 SL-6082092-TN SCREWM8L=20 1

40 400-94723 TOROLLEY_COV_BR 1

41 SL-6061092-TN SCREWM6L=10 2

42 HX-0029400-00 FIXEDBASE 2

43 SM-4040601-SC SCREWM4X0.7L=6 2

44 401-83151 T_SAFETY_COVER_BR 2

45 SL-6040892-TN SCREWM4L=8 6

46 401-83194 TROLLEY_SAFETY_COVER_L 1

47 SL-6040892-TN SCREWM4L=8 4

48 401-88175 TROLLEY_SAFETY_COVER_R 1

49 SL-6040892-TN SCREWM4L=8 4

50 401-83154 REGULATION_BAR_RS 1

51 SL-6040892-TN SCREWM4L=8 4

52 401-88174 REGULATION_BAR_B 1

53 SL-6061292-TN SCREWM6L=12 4

54 401-83162 BANK_PCB_SUPPORT_BRACKET 2

55 SM-6101602-TP SCREWM10L=16 4

56 WP-1052001-SC WASHER10 4

57 401-83163 BANK_PCB_BASE 2

58 HX-0029400-00 FIXEDBASE 8

59 SM-4040601-SC SCREWM4X0.7L=6 8

60 HX-0070600-00 MOUNTBASE 2

61 SM-0040601-SC SCREWM4X0.7L=6 12

62 SL-4030681-SC SCREWM3L=6 18

63 401-83164 FD_PCB_BASE 1

64 SL-4850591-SC SCREWM2.5L=5 4

65 401-83165 CABLE_HOLDER 1

66 HX-0029400-00 FIXEDBASE 3

67 SM-4040601-SC SCREWM4X0.7L=6 3

68 SL-6040892-TN SCREWM4L=8 2

69 401-83166 BANK_PCB_COVER 1

70 SL-6040892-TN SCREWM4L=8 4

71 400-93977 5PORT_SOLENOID_VALVE 1

72 PJ-3010852-01 HALFUNION8XR1/4 2

73 PJ-3040852-01 ELBOWUNION8XPT1/4 1

74 401-83168 KQ2T06-08A 2

75 SL-6040892-TN SCREWM4L=8 2

76 PX-0551040-00 SILENCER 2

77 HX-0029400-00 FIXEDBASE 11

78 SL-4030681-SC SCREWM3L=6 11

79 BT-0600400-EC URETHANETUBEBLUE6X4 2

80 BT-0800501-EA URETHANETUBEBLUE8X5 2

81 SM-6051402-TN SCREWM5L=14 1

82 SM-6054002-TN SCREWM5X0.8L=40 1

83 NM-6050001-SC NUTM5X0.8TYPE1 3

84 401-10316 SPACER 3

#02

401-83208 GUIDE_RAIL_R 4

86 401-83783 ELECBANKL-SIDEPCBASM 1

87 401-83784 ELECBANKR-SIDEPCBASM 1

88 401-84971 POSITION_LAVEL_56 3

89 401-83203 BANK_CONNECTOR_A_BR 1

90 SM-4040601-SC SCREWM4X0.7L=6 3

91 HX-0029400-00 FIXEDBASE 3

92 SL-6051292-TN BOLT 3

- -

44.REPLACINGOVERALLCHANGERTRUCKCOMPONENTS(2)

1 0

1 1

1 3

1 4

1 5

1 6

1 7

1 8

1 9

2 0

2 1

2 2

2 3

2 5

2 6

2 7

2 8

2 9

3 0

3 2

3 3

3 1

3 4

3 5

3 6

3 7

3 1

3 8

3 9

3 3

3 8

3 9

4 0

4 1

4 2

4 3

4 0

4 1

4 2

4 3

4 4

4 5

4 6

4 7

4 8

5 0

4 9

5 1

5 2 5 4

1 0

5 2 5 4

5 5 5 8

5 9

6 0

6 1

6 3

6 4

6 5

6 6

6 7

6 9

7 1

7 2

7 3

7 4

7 5

6 2

2 4

7 7

7 8

8 0 8 3

7 6

7 9

8 1

8 2

2 4

1 2

6 8

7 0

- -

REF.NO NOTE PARTNO DESCRIPTION Qty

1 401-83608 CUTTER_ASM 1

2 401-83210 LINER_WAY (2)

3 SM-6052002-TN SCREW (10)

4 401-83189 EDGE_BASE_SIDE (2)

5 SL-6043092-TN SCREWM4L=30 (6)

6 401-86283 UPPER_EDGE_BASE (1)

7 401-86284 BRUSH_B (1)

8 SL-6041242-TN SCREWM4L=12 (4)

9 PS-0300162-KH SPRINGPIN3X16 (2)

10 401-83183 GUIDE_SLOPE (2)

11 SL-6043092-TN SCREWM4L=30 (2)

12 PH-0300104-S0 PARALLELPINTYPEB3X10 (2)

13 401-85336 UPPER_EDGE (1)

14 SM-6040602-TN SCREW (12)

15 SB-7080002-00 BEARING (4)

16 401-83126 HOLD_SHAFT (2)

17 RE-0600000-K0 E-RING6 (2)

18 401-83127 HOLD_PLATE (1)

19 SM-1040852-TP DISHSCREW (2)

20 401-83128 SPRING_PLATE (1)

21 SL-6040892-TN SCREWM4L=8 (2)

22 401-83129 PUSHER_STOP_PLATE (2)

23 401-83181 SLIDE_BASE (1)

24 SL-6051692-TN SCREWM5L=16 (11)

25 SL-6051092-TN SCREWM5L=10 (4)

26 SM-6051402-TN SCREWM5L=14 (2)

27 NM-6050001-SC NUTM5X0.8TYPE1 (2)

28 401-83131 PUSHER_SPRRING_R (2)

29 401-82493 LOWER_EDGE (2)

30 SL-6051092-TN SCREWM5L=10 (10)

31 401-83133 MDUB50-45DZ (2)

32 PC-0152030-00 SPEEDCONTROLLER (4)

33 SM-6084002-TN SCREWM8L=40 (4)

34 401-83134 CYLINDER_SUPPORT_BLOCK (1)

35 SM-6086002-TN SCREW (4)

36 401-83201 CONNECTION_BLOCK (2)

37 SM-6064502-TP SCREWM6L=45 (4)

38 WS-0610002-KN SPRINGWASHERM6 (4)

39 WP-0641601-SC WASHERM6 (4)

40 401-83136 WASHER (4)

41 401-83137 COLLAR (2)

42 401-83138 SLIDE_SPACER (2)

43 SM-6103552-TP SCREWM10L=35 (2)

44 401-83140 COVER_LOWER_EDGE (2)

45 SL-6051092-TN SCREWM5L=10 (4)

46 401-85337 SHOOT_A (1)

47 SL-6040892-TN SCREWM4L=8 (4)

48 401-85335 TAPE_GUIDE_PLATE (1)

49 401-83146 COVER_CUTTER (1)

50 SL-6040892-TN SCREWM4L=8 (2)

51 SM-3040652-TN SCREWM4L=6 (2)

52 401-83186 SHIM_T100 (4)

53 401-83187 SHIM_T40 (8)

54 401-83188 SHIM_T20 (10)

55 401-86289 SHIM_B_T20 (8)

56 401-86290 SHIM_B_T40 (8)

57 401-86291 SHIM_B_T100 (4)

58 401-86292 SHIM_B_T200 (2)

59 401-86606 FELT_CUSHION_A (2)

60 401-86640 FELT_SUPPORT (1)

61 SM-0040601-SC SCREWM4X0.7L=6 (2)

62 401-86216 COOLING_PIPE_ASM (1)

63 401-86217 COOLING_PIPE (1)

64 PJ-3040400-01 QUICKPIPEJOINTELBOW (2)

65 HX-0015000-0A CABLECLAMP (3)

66 SL-4041291-SC SCREWM4L=12 (3)

67 401-29113 NZL-UPSVCABLEASM (1)

68 PC-0105190-00 SPEEDCONTROLLER (1)

69 EZ-4447053-11 UNION(KQ2H06-M5N)HALF (1)

70 SM-8050602-TP SCREWM5L=6 (3)

71 SL-4041691-SC SCREWM4L=16 (2)

72 PJ-3050800-01 DIFFERENTDIAMETERUNIONT (1)

73 BT-0600400-EC URETHANETUBEBLUE6X4 (0.1)

74 BT-0400251-EA URETHANETUBEBLUE4X2.5 (2)

75 PJ-3080400-06 UNIONY (1)

76 401-86607 UPPER_EDGE_SUPPORT_ROLLER 1

77 401-86608 ROLLER_BASE 1

78 PH-0400162-C0 PARALLELPINTYPEB4X16 1

79 SM-8030302-TP SCREWM3X3 2

#01

401-86610 SPACER_R 1

81 SM-6043002-TN SCREW 2

82 400-92716 TAPECUTTERDANGERLABEL 1

#02

401-86609 SPACER_F 1
