User Manual SIPLACE CA 3 Technical Data Edition 08/2011 EN 3.1 SIPLACE CA Performance Data 123 Angular accu- racy- C&P20CA C&P12 C&P6 TH TH ± 0.5° (3 ), ± 0.7° (4 ) ± 0.5° (3 ), ± 0.7° (4 ) ± 0.2° (3 …
3 Technical Data User Manual SIPLACE CA
3.1 SIPLACE CA Performance Data Edition 08/2011 EN
122
3
Placement head
types-
– 20 segment Collect&Place CA head (C&P20CA)
– 12 segment Collect&Place CA head (C&P12A)
– 6 segment Collect&Place CA head (C&P6)
– SIPLACE TwinHead (TH)
(only possible in a placement area without SWS).
Number of gan-
tries
CA4: 4 gantries
CA3: 3 gantries
Place-
ment-positions
6,000 / gantry for the Collect&Place heads
2,000 / gantry for the TwinHead
Component
spectrum
a
0,4 mm x 0,2 mm (01005), 0,6 mm x 0,3 mm (0201)
bis 85 mm x 85 mm / 125 mm x 10 mm,
max. 200 mm x 125 mm (with restrictions)
Component
height
C&P20CA: 4 mm
C&P12: 6 mm
C&P6: 8.5 mm
TH: 25 mm
b
(higher heights on request)
Placement
accuracy
(Standard--cri-
teria for SMD)
C&P20CA
C&P12
C&P6
TH
TH
± 41 µm (3), ± 55 µm (4)
± 41 µm (3), ± 55 µm (4)
± 45 µm (3 ), ± 60 µm (4 )
± 26 µm (3), ± 35 µm (4)
± 22 µm (3), ± 30 µm (4)
Component camera, type 41
(6 x 6)
Component camera, type 29
(27 x 27)
Component camera, type 29
(27 x 27)
Component camera, type 33
(55 x 45)
Component camera, type 25
(16 x 16)
Placement
accuracy
(Advanced cri-
teria for SWS)
C&P20CA
C&P12
C&P6
TH
TH
± 25 µm (3), ± 33 µm (4)
± 25 µm (3), ± 33 µm (4)
± 35 µm (3), ± 47 µm (4)
± 26 µm (3), ± 35 µm (4)
± 22 µm (3), ± 30 µm (4)
Component camera, type 41
(6 x 6)
Component camera, type 29
(27 x 27)
Component camera, type 29
(27 x 27)
Component camera, type 33
(55 x 45)
Component camera, type 25
(16 x 16)
User Manual SIPLACE CA 3 Technical Data
Edition 08/2011 EN 3.1 SIPLACE CA Performance Data
123
Angular accu-
racy-
C&P20CA
C&P12
C&P6
TH
TH
± 0.5° (3), ± 0.7° (4)
± 0.5° (3), ± 0.7° (4)
± 0.2° (3), ± 0.3° (4)
± 0.05° (3), ± 0.07° (4)
± 0.05° (3), ± 0.07° (4)
Component camera, type 41
(6 x 6)
Component camera, type 29
(27 x 27)
Component camera, type 29
(27 x 27)
Component camera, type 33
(55 x 45)
Component camera, type 25
(16 x 16)
a) The range of components depends on the selected head configuration.
b) The specified component height for TwinHead might be reduced in placement areas with two gantries and a com-
bination of Collect&Place head and TwinHead.
3 Technical Data User Manual SIPLACE CA
3.2 Component Supply Edition 08/2011 EN
124
3.2 Component Supply
3
The following options apply for each of the 4 locations:
–SWS
a
– Component trolley (X-series)
(with tape reel mount and integrated waste tape bin,
40 locations a 8 mm X-feeder module per component trolley)
– Matrix Tray Changer
b
a) The SWS can only be used at the CA4 on the locations 2 and 4, and at the CA3 only at the location 4.
b) The Matrix Tray Changer can only be used at locations 2 and 4.
Feeder module
types
– X series component trolley> Tapes, waffle pack trays
c
c) It is not possible to combine C&P20CA heads and waffle pack trays.
Supply-capacity
(Component trol-
ley
X-series)
160 tracks Width: 8 mm 8 mm X feeder modules
80 tracks Width: 12 mm 12 mm X feeder modules
52 tracks Width: 16 mm 16 mm X feeder modules
52 tracks Width: 24 mm 24 mm X feeder modules
40 tracks Width: 32 mm 32 mm X feeder modules
32 tracks Width: 44 mm 44 mm X feeder modules
24 tracks Width: 56 mm 56 mm X feeder modules
20 tracks Width: 72 mm 72 mm X feeder modules
16 tracks Width: 88 mm 88 mm X feeder modules
