User Manual SIPLACE CA 4 Setting Up and Commissioning Edition 08/2011 EN 4.3 Delivery Configuration and Transpo rtation of SWS 255 4.3.2 T ransporting the SWS in the T ransportation Crate 4.3.2.1 Services As a service AS…
4 Setting Up and Commissioning User Manual SIPLACE CA
4.3 Delivery Configuration and Transportation of SWS Edition 08/2011 EN
254
4.3 Delivery Configuration and Transportation of SWS
4.3.1 Transportation Packaging
Within Europe the SWS is transported on a wooden pallet and is wrapped in plastic foil. Outside
Europe, the machine is supplied in a wooden crate mounted on a stable wooden pallet.
4.3.1.1 Dimensions of Transportation Packaging
The dimension of the wooden transport crate are as follows:
Length 1700 mm
Width 1250 mm
Height 1600 mm
4
4
Fig. 4.3 - 1 Transport crate for SWS - dimensions in millimeters
4.3.1.2 Weight of machine when ready for delivery
The following table contains the weight of the SWS when ready for delivery.
4
fork-lift attachment
point
Machine Dispatch within Europe Dispatch overseas
SWS 390 kg 473 kg
User Manual SIPLACE CA 4 Setting Up and Commissioning
Edition 08/2011 EN 4.3 Delivery Configuration and Transportation of SWS
255
4.3.2 Transporting the SWS in the Transportation Crate
4.3.2.1 Services
As a service ASM Assembly Systems GmbH & Co.KG offers you the complete integration of ma-
chines of the CA-series into the production line. With our extensive expertise and by using the right
tools and equipment, we can ensure that the installation process runs smoothly and efficiently.
However, this will require you to clarify the infrastructure aspects in advance and make any nec-
essary changes at your production facility.
Please note that the safest way to transport the placement machine is always in the transport crate
- or at the very least on the pallet. This will prevent serious damage to the machine caused by the
feet colliding with obstacles, for example.
4.3.2.2 Safety Instructions
WARNING 4
– The applicable accident prevention regulations concerning the transportation of heavy goods
must be followed.
– If you do not use the transportation equipment specified in section 4.3.2.3
to transport the
SWS, you will risk that the machine tips overs.
– In particular, you should wear safety boots to minimize the risk of crushing your feet.
4.3.2.3 Transportation Equipment
To transport the SWS on the wooden pallet or in the transport crate, use a fork-lift truck with the
following specifications:
Fork length: min. 1800 mm
Carrying power: min. 1500 kg
Clear width between forks: min. 420 mm 4
4 Setting Up and Commissioning User Manual SIPLACE CA
4.3 Delivery Configuration and Transportation of SWS Edition 08/2011 EN
256
4.3.3 Transporting the SWS without Transportation Crate or Pallet
4.3.3.1 Safety Instructions
WARNING 4
The applicable accident prevention regulations concerning the transportation of heavy goods
must be followed.
In particular, you should wear safety boots to minimize the risk of crushing your feet.
– Before transporting the machine, read this section through carefully, to avoid damaging the
SWS.
4.3.3.2 Transportation Equipment
To transport the SWS, use a fork-lift truck or an appropriate hand-lift with the following specifica-
tions:
4
NOTE 4
The necessary width of the fork lift presents a critical measure. You should absolutely make sure
that the hand-lift used meets the required specifications.
Fork length Min. 1600 mm
Lifting power Min. 1500 kg
Outer fork width Min. 450 mm
Max. 520 mm
