User Manual SIPLACE CA 4 Setting Up and Commissioning
Edition 08/2011 EN 4.5 Setting Up the Placement Machine
301
4.5.11.2 Box-PC Slide In of the CA4 and CA3- Plug In Connectors at the Front
4
Also check the following plug-in connectors:
4
Box PC unit, front
side
(fig. 4.5 - 19
)
Plug
Connection cable NOTE
Plug Cable
X0pr
a
X0pr 03009778 Insert as far as the stop
X1pr
a
X1pr 03009838 Insert as far as the stop
X2pr
a
X2pr 03009755 Insert as far as the stop
X3pr
a
X3pr 03009756 Insert as far as the stop
X0ps
a
X0ps 03009798 Insert as far as the stop
X1ps
a
X1ps 03009818 Insert as far as the stop
X2ps
a
X2ps 03009757 Insert as far as the stop
X3ps
a
X3ps 03009758 Insert as far as the stop
X6pc X6pc 03010478 Insert as far as the stop
X5pv X5pv 03051749 Secure with screws
X6pv X6pv 03051750 Secure with screws
a) This plug is intended for cameras.
Box PC unit, front side
(fig. 4.5 - 19
)
Plug
Plug Cable
X1pa X4rz (box PC rear panel) 03050908-W2
X1pc X4rz (box PC rear panel) 03050908-W1
X4pa X2pv 03051748
X4pc X1pv 03051747
X5pc X5pa 03051756
X7pc X8pd 03051755
X9pd X2rz (box PC rear panel) 03052633-W1
4 Setting Up and Commissioning User Manual SIPLACE CA
4.5 Setting Up the Placement Machine Edition 08/2011 EN
302
4.5.11.3 Box-PC Slide In of the CA4 and CA3- Plug In Connectors at the Rear
4
4
4.5.11.4 Installing the Box PC Unit
Connect the plug-in connectors at the rear of the PC unit (see section 4.5.11.3).
Carefully lift the box PC unit onto the rail in the extension kit.
Make sure that you do not squash any cables.
Push the box PC unit into the extension kit as far as the stop.
Connect the plug-in connectors at the front of the PC unit (see section 4.5.11.2).
Fix the cables to the front panel with cable ties.
Secure the box PC unit with the fillister head screw.
Fasten the ground cable to the door (item 2 in fig. 4.5 - 15, page 293), as shown in fig. 4.5 -
17 on page 297.
Lock the doors.
NOTE 4
In case of CA4- and CA3 machines continue with paragraph 4.5.13
"Install Axis Slide In at the
CA4 and CA3" on page 309.
Box PC unit, rear
side
(fig. 4.5 - 20
)
plugs
Connection cable NOTE
Plug Cable
PE1 Cable ring Grounding cable
Fasten as in fig. 4.5 - 17
, page
297
X1rz X1rz 03051757 Insert as far as the stop
X3rz X3rz 03050907 Insert as far as the stop
X1pd X1pd 03051751 Insert as far as the stop
X2pd X2pd 03051752 Insert as far as the stop
X3pd X3pd 03051753 Insert as far as the stop
X4pd X4pd 03051754 Insert as far as the stop
User Manual SIPLACE CA 4 Setting Up and Commissioning
Edition 08/2011 EN 4.5 Setting Up the Placement Machine
303
4.5.11.5 Fitting the Side Plates
Fasten the ground cable to each side plate (item 6 in fig. 4.5 - 15, page 293), as shown in fig.
4.5 - 17
, page 297.
Fix the side plate to the machine frame with 6 fillister head screws.
Continue with section 4.5.14 "Fitting the Main Fault Indicator", page 311.
