4 Setting Up and Commissioning User Manual SIPLACE CA 4.5 Setting Up the Placement Machine Edition 08/2011 EN 308 4.5.12.5 Fitting the Side Plates  Fasten the ground cab le to each side plate (item 6 in fig. 4.5 - 15 , …

User Manual SIPLACE CA 4 Setting Up and Commissioning

Edition 08/2011 EN 4.5 Setting Up the Placement Machine

307

4.5.12.3 Computer Unit of the CA4 and CA3- Plug In Connectors at the Rear

4.5.12.4 Fitting the Computer Unit

 Connect the plug-in connectors at the rear of the computer unit (see section 4.5.12.3).

 Carefully lift the computer unit onto the rail in the extension kit.

 Make sure that you do not squash any cables.

 Check that the cables to the front are run in the cable guide plate at the side

(item 1 in fig. 4.5 - 21

, page 304).

 Push the computer unit into the extension kit as far as the stop.

 Connect the fan cable to the computer unit cable.

 Connect the plug-in connectors at the front of the computer unit (see section 4.5.12.2).

 Fix the cables to the front panel with cable ties.

 Secure the computer unit with the fillister head screw.

 Fasten the ground cable to the door (item 2 in fig. 4.5 - 15, page 293), as shown in fig. 4.5 -

17 on page 297.

 Lock the doors.

NOTE 4

In case of CA4- and CA3 machine please continue with paragraph 4.5.13

"Install Axis Slide In at

the CA4 and CA3" on page 309.

Computer unit, rear

(fig. 4.5 - 22

)

plugs

Connection cable NOTE

Plug Cable

PE1 Cable ring Grounding cable

Fasten as in fig. 4.5 - 17

, page

297

X27pz X27pz 03003437 W1-W2 Insert as far as the stop

X2pz X2pz 03002966 W1-W5 Fix with screws

X1pz X1pz 03002969 W1-W5 Fix with screws

X62pz X62pz 03002488 Snap into place

PE2 Cable lug Grounding cable Insert as far as the stop

P24 / GND X1 Fan in extension kit Insert as far as the stop

4 Setting Up and Commissioning User Manual SIPLACE CA

4.5 Setting Up the Placement Machine Edition 08/2011 EN

308

4.5.12.5 Fitting the Side Plates

 Fasten the ground cable to each side plate (item 6 in fig. 4.5 - 15, page 293), as shown in fig.

4.5 - 17

, page 297.

 Fix the side plate to the machine frame with 6 fillister head screws.

 Continue with section 4.5.14 "Fitting the Main Fault Indicator", page 311.

User Manual SIPLACE CA 4 Setting Up and Commissioning

Edition 08/2011 EN 4.5 Setting Up the Placement Machine

309

4.5.13 Install Axis Slide In at the CA4 and CA3

4.5.13.1 Axis unit CA4, CA3 (gantries 1 and 4), electrical connection points

Fig. 4.5 - 23 Axis unit CA4, CA3 (gantries 1 and 4), rear side - connect electrical connection points

PlugPlug

Plug
