User Manual SIPLACE CA 4 Setting Up and Commissioning
Edition 08/2011 EN 4.5 Setting Up the Placement Machine
319
4.5.19 Removing the Corrosion Protection from the Guide Rails
The placement machine is treated with a corrosion protection agent before delivery.
CAUTION 4
– You should therefore remove the corrosion protection from all the axes and bearings when
you traverse the machine axes for the first time during commissioning.
– Grease all the axes and bearings with the grease described in the maintenance instructions.
If the corrosion protection agent is mixed with the bearing grease on the axes this can greatly re-
duce the service life of the bearings and guide rails.
CAUTION 4
Do not allow any alcohol to enter the guide carriages when you clean the guide rails and scale
rods. Alcohol will damage the bearing grease in the guide carriages.
4 Setting Up and Commissioning User Manual SIPLACE CA
4.6 Installing the SWS Edition 08/2011 EN
320
4.6 Installing the SWS
CAUTION 4
Before installing the SWS, make sure that the placement machine has been completely assem-
bled. (See section 4.5)
4.6.1 Warning Instructions
DANGER 4
Only ASM-technicians or certified persons may set up and start up the SWS.
Always follow the applicable accident prevention regulations.
During assembly or installation never lie down under the SWS. All assemblies and parts can
be fitted from above. If you still need to perform assembly work to the underside of the SWS,
take appropriate measures to secure the machine first. The fork-lift truck alone is not a suit-
able support!
Make sure that the gantries are positioned over the PCB conveyor area so that you do not
restrict your head movement during assembly, thus excluding the risk of injury.
You require two people to install the SWS:
– One person carries out the required assembly work.
– The other person monitors the stability of the lifted SWS during assembly.
Wear special safety boots to protect your feet.
Note:
Please note that the installation of an SWS is possible for: 4
– CA4 placement machine all locations (on the left-hand side for 1 and 3, on the right-hand side
for 2 and 4)
User Manual SIPLACE CA 4 Setting Up and Commissioning
Edition 08/2011 EN 4.6 Installing the SWS
321
4.6.2 Tools and Equipment
You will need the following tools and equipment to install the SWS:
– Standard tool
– Torque wrench
– Fork-lift truck/hand lift (see section 4.3
), support bars
– Screwed feet
4.6.3 Installing the SWS in the Placement Machine
4.6.3.1 Position Fork Lift Truck
Position the fork-lift truck lengthwise under the SWS and open the forks until the contact sur-
faces of the SWS lie evenly on the forks. The magazine lift module must face the fork-lift truck.
WARNING 4
Before lifting the SWS, observe the following points to avoid causing irreversible damage to the
SWS:
– When lifting the SWS, make sure that the forks are loaded evenly. A firm support surface be-
tween the fork and the SWS prevents the SWS from tipping over when lifted. We recommend
that a second person monitors the lifting of the SWS and ensures that this does not tip over
to one side when lifted by the fork-lift truck.
4.6.3.2 Inserting the SWS in the Placement Machine
Note: 4
Before inserting the SWS, make sure that the CAN Bus connection X1x5 and X1x6, the com-
pressed air connection and the FFI communication interface W11 on the SWS are accessible.
