2.1 Safety Instructions
DANGER
There is a risk for personnel and equipment if the safety instructions are not followed!
Please observe the safety instructions in the relevant User Manual when carrying out work on
the machine. 2
2.1.1 Conventions for the Use of Hazard Symbols
This User Manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk:
DANGER
as used in this manual means that death, severe injury or considerable damage to equipment
will occur if the danger instructions are not followed. 2
WARNING
as used in this manual means that death, severe injury or considerable damage to equipment
may occur if the warning instructions are not followed. 2
CAUTION
as used in this manual means that slight injury or damage to equipment may occur if the caution
instructions are not followed. 2
2 Operational Safety User Manual SIPLACE CA
2.1 Safety Instructions Edition 08/2011 EN
34
NOTE
as used in this manual provides information on the product or indicates a part of the manual that
requires particular attention. 2
2.1.2 Qualified Personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and preventive maintenance of automatic placement systems and add-on devices and
are suitably qualified, e.g.
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify
electrical circuits and system components in accordance with normal safety standards.
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
– have received first aid training.
2.1.3 Correct Usage
This product must only be used for the intended application described in the catalogues and tech-
nical descriptions, i.e. to place SMD components and bare dies from a wafer and only in combi-
nation with external devices and components recommended or approved by ASM Assembly
Systems GmbH & Co.KG. Use for a different or extended purpose is not prescribed.
ASM Assembly Systems GmbH & Co.accepts no liability for any damages that may result from
improper use and assumes no warranty for the error free and correct functioning of the compo-
nents.
Use as prescribed also includes compliance with all the instructions in the user manual.
For the product to operate correctly and reliably, it must have been transported, stored, erected
and assembled correctly and must be operated and maintained with care.
User Manual SIPLACE CA 2 Operational Safety
Edition 08/2011 EN 2.1 Safety Instructions
35
2.1.4 Non-Prescribed Usage
Failure to use the product as prescribed can result in both danger to life and limb and material
damage. For this reason any use that is not prescribed is not allowed. ASM Assembly Systems
GmbH & Co.accepts no liability for any damages that may result from improper use and assumes
no warranty for the error free and correct functioning of the components.
Failure to use the placement machine as prescribed includes, for example
– operation of the placement machine with safety equipment deactivated or removed.
– placement of components that do not meet the permitted specification.
– use of component feeder modules that have not been approved.
– use of unauthorized accessories and additional modules.
– use of the placement machine by unqualified personnel.
– operation of the placement machine without the hand guard (dummy feeder module) if not
every location is occupied with a feeder module or if a waffle-pack tray holder is used.
– unclear assignment of electrical connection cables to each machine and the installed options
(e. g. SWS, Productivity Lift).
– the simultaneous presence of more than one person when refilling a component trolley loca-
tion.
2.1.5 Important Notes on Operational Safety
The following points MUST be observed in order to maintain operational safety:
2.1.5.1 General
The operational safety of the placement machine can only be guaranteed by prescribed us-
age of the machine and observance of the user/service manuals.
Always follow any safety regulations specific to your country.
Make sure that the warning labels are always clearly identifiable and always easily readable.
Replace any damaged warning or notice labels. Replace any labels that are missing.
The machine key for releasing the covers on the machine must be kept in a safe place where
it is only accessible to qualified personnel.
NOTE
The machine owner, and only the machine owner, is responsible for the safekeeping of the
machine key and for ensuring that it is handed over to authorized persons. 2
