6 Component and Die Handling User Manual SIPLACE CA 6.3 Used Tape Channel SIPLACE X Series Edition 08/2011 EN 412 6.3 Used T a pe Channel SIPLACE X Series 6 Fig. 6.3 - 1 Used tape channel for the component trolley dockin…
User Manual SIPLACE CA 6 Component and Die Handling
Edition 08/2011 EN 6.2 Component Trolley, SIPLACE X-Series
411
6.2.7.2 Maximum Tape Reel Diameter in Relation to the PCB Conveyor Height
6
Note: 6
X-series component trolleys do not generally need spindles. However, if the "Time-out" error
message occurs increasingly on the X feeder module, we recommend that you do use spindles.
Without mount for the
additional tape reel
With mount for the
additional tape reel
PCB Transport
Height of the
Component Trolley
Tape reel diameter Tape reel diameter
without spindle with spindle
830 mm 17" 15" < 15"
900 mm 19" 17" 15"
930 mm 19" 19" 17"
950 mm 19" 19" 19"
6 Component and Die Handling User Manual SIPLACE CA
6.3 Used Tape Channel SIPLACE X Series Edition 08/2011 EN
412
6.3 Used Tape Channel SIPLACE X Series
6
Fig. 6.3 - 1 Used tape channel for the component trolley docking unit from the SIPLACE X-series
Depending on the PCB conveyor height, the length of the waste tape channel can be set so that
the pieces of tape are diverted directly into the waste tape bin of the component trolley.
NOTE 6
The used tape channel for the X series can only be installed on the component trolley docking
unit of X series machines (see fig. 5.12 - 3, page 370).
User Manual SIPLACE CA 6 Component and Die Handling
Edition 08/2011 EN 6.4 Used Tape Cannel - CO Trolley Docking Unit, SIPLACE X-Series
413
6.4 Used Tape Cannel - CO Trolley Docking Unit,
SIPLACE X-Series
6.4.1 Partition Plate for Tape Pocket Heights up to 12 mm
In the standard version, the used tape channel can guide component tapes with a maximum
pocket height of 12 mm to the pneumatic tape cutter.
6
Fig. 6.4 - 1 Used tape channel, SIPLACE X-series
(1) Inlet slot for used tape
(2) Outlet slot for the used tape above the pneumatic tape cutter
(3) Dividing plate for tapes < 12 mm (can be removed for tapes > 12 mm)
(4) DIN 93384 screw - M4x20, 2x
