User Manual SIPLACE CA 2 Operational Safety Edition 08/2011 EN 2.7 Safety Instructions for Operating the SWS 79 2.7 Safety Instructions for Operating the SWS 2.7.1 Safety Instructions for Working at the W afer T able WA …
2 Operational Safety User Manual SIPLACE CA
2.6 Safety Instructions for Operating the Placement Machine Edition 08/2011 EN
78
CAUTION
HIGH TEMPERATURES 2
The housing of the star motor and the handle on the placement head may become very hot dur-
ing continuous operation and in ambient temperature in excess of 22 °C. Be careful when touch-
ing the parts.
2.6.12 High Temperatures on the X Feeder Modules in Continuous Operation
2
Fig. 2.6 - 9 High temperatures on the X feeder modules in continuous operation
(1) Temperature label [03031926-01]
(2) Stepping motor
CAUTION
HIGH TEMPERATURES 2
The stepping motors can become very hot during continuous operation and in an ambient tem-
perature in excess of 22 °C. Be careful when touching the motors.
User Manual SIPLACE CA 2 Operational Safety
Edition 08/2011 EN 2.7 Safety Instructions for Operating the SWS
79
2.7 Safety Instructions for Operating the SWS
2.7.1 Safety Instructions for Working at the Wafer Table
WARNING 2
RISK OF CRUSHING HANDS
Never reach your hands into the gap of the magazine lift in the direction of the wafer table. There
is a risk of being crushed by the gantry or the wafer table.
2.7.2 Safety Instructions for Changing the Wafer Magazines
WARNING 2
HEAVY WAFER MAGAZINE
A full wafer magazine can weigh up to 25 kg. Handle the wafer magazine carefully. Enlist the
help of a second person, if necessary.
CAUTION 2
Make sure that nothing protrudes from the magazine lift.
Make sure, that only the intended wafer magazine is placed properly on the magazine liftplate.
If not handled correctly damage on the wafer magazine i.e. of the magazine lift can not be
excluded.
2 Operational Safety User Manual SIPLACE CA
2.7 Safety Instructions for Operating the SWS Edition 08/2011 EN
80
2.7.3 Safety Instructions for Closing the Protective Cover
WARNING
RISK OF CRUSHING HANDS WHEN CLOSING THE PROTECTIVE HOOD
Always hold the grab recess provided when opening or closing the sliding door.
When closing, do not reach into the gap between the cover or sliding door and the machine
housing. This area is marked with a yellow and black warning strip.
– The sliding door of the SWS can be opened during operation to change the wafer magazine
- the SWS continues to operate. Opening the door only deactivates the magazine lift.
– Opening the cover hood sets the SWS into EMERGENCY OFF state.
2.7.4 Safety Instructions on the Linear Dipping Unit (LDU)
DANGER 2
HAZARDOUS SUBSTANCES (FLUX)
The flux used for the Linear Dipping Unit poses a hazard to health!
Always observe the safety data sheet provided with the flux (Material Safety Datasheet - MSDS)
and make sure that all prescribed measures are fulfilled.
When filling and cleaning the LDU, plus when disposing of the flux, wear the prescribed pro-
tective clothing (e.g. breathing protection, gloves, goggles).
