ASM ProcessLens Technical data 7 Technical data Transportation and delivery configuration Transport dimensions and weight Length 2340 mm Width 1560 mm Height 1820 mm Weight 1074 kg +/- 20 kg base on the spare order acces…
ASM ProcessLens
Technical data
6
Technical data
Dimensions and ambient conditions for machine operation
Machine dimension
Length along PCB transport direction 1130 mm
Width 1300 mm
Height at a conveyor height of 950 mm 1600 mm
Machine weight 780 kg
Adjustable monitor and keyboard height range 880 - 1140 mm
Floor load 5 kN/m²
Machine ground clearance
(for PCB conveyor height 900 mm) machine height is 1831 mm ± 15 mm
(for PCB conveyor height 930 mm) machine height is 1861 mm ± 15 mm
(for PCB conveyor height 950 mm) machine height is 1881 mm ± 15 mm
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75% (no higher than 45% on average to pre-
vent any possibility of condensation in the machine)
Operating temperature range Between 0°C and 50°C
Operating humidity max. 50% at 40°C
Operating altitude max. up to 1000m sea level
Max. noise emissions 78 dB (A)
ASM ProcessLens
Technical data
7
Technical data
Transportation and delivery configuration
Transport dimensions and weight
Length 2340 mm
Width 1560 mm
Height 1820 mm
Weight 1074 kg
+/- 20 kg base on the spare order accessories
Within Europe, the machine is delivered on a robust wooden pallet. If sent overseas, the machine is packaged
in a wooden crate.
Means of transport
A fork-lift with the following specification will be needed to carry the machine in its crate:
Fork length Min. 1800 mm
Lifting power Min. 3000 kg
Configuration when delivered
●
The lanes of the dual conveyor are set to a width of 210 mm.
●
Both monitors are dismantled.
●
Both indicator lamps are dismantled.
ASM ProcessLens
Technical data
8
Technical data
Center of Gravity
Fig.1: Center of gravity of the ASM ProcessLens solder paste inspection machine
1 550 mm 2 610 mm
3 730 mm
Electrical Ratings
Supply voltage Fuses
Main power supply 1/N/PE
Current rating: 110 V
1)
- 9.1 A, 240 V - 4.2 A, 50/60Hz
2 x 15 A
Power consumption 1 kW
Power supply 100 ~ 240 VAC, Single Phase 50/60 Hz
Short circuit rating of
machine (SCCR)
2)
10 kA
Power connector MENNEKES: 32 A 230 V 2 P+E STRAIGHT
Technical data
1)
110 V~ as an option
2)
With the original mains connection cable. The marked short circuit rating (SCCR) relates to the beginning of
the original mains cable. In the case of customer modifications, the factory-set length of the mains cable to
the machine may not be shortened nor the factory-set conductor cross-section increased, as this would
have a negative impact on the short circuit rating (SCCR).
