8 SQUEEGEE MODULE 8.2 ELECTRICAL SCHEMATIC TECHNICAL REFERENCE MANUAL DEK TQ 04/2021 129 8.2 ELECTRICAL SCHEMATIC M M Front Squeegee M TR 28 Rear Squeegee M TR 29 Extended Power Module E PM 2-1 Extended Power Module E PM…
8 SQUEEGEE MODULE
8.1 OVERVIEW
128 TECHNICAL REFERENCE MANUAL DEK TQ 04/2021
To prevent a collision with the drip tray,a short drip tray (360mm) should be used in conjunction
with a stencil size of 6320mm
(24.409") or less.
The drip tray retracted sensor is used by software to check that the pneumatic actuator has retrac-
ted the drip tray fully before lowering the squeegees.
The rubber bumper stop prevents a collision with the stencil load mechanism when retracting.
8 SQUEEGEE MODULE
8.2 ELECTRICAL SCHEMATIC
TECHNICAL REFERENCE MANUAL DEK TQ 04/2021 129
8.2 ELECTRICAL SCHEMATIC
M
M
Front
Squeegee
MTR28
Rear
Squeegee
MTR29
Extended Power Module
EPM2-1
Extended Power Module
EPM2-2
Machine Controller
Controller Power Module
(CPM)
J4 EPM2PL15EPM2PL13
Fibre
Optic
Links
Ribbon Cables
SIO Link
Cables
EPM2PL16EPM2PL14
4SK10
4SK11
J4
ESIO-4
ESIO-5
ESIO-3
ESIO-3: Breakout A
ADC/DAC
Board 5
Conditioning Board
IO1
IO2
IO4 IO5
3ASK2
M73PL5
5PL3
M73SK1
Front
Squeegee
4SE8
Rear
Squeegee
4SE9
Home
Sensor
Home
Sensor
3ASK23
3ASK24
3ASK13
3ASK14
Squeegee
Load Cell
5SE1
M73PL4
M73PL2
Connector for break-off
temperature and humidity board
5PL6
°C
%RH
8 SQUEEGEE MODULE
8.2 ELECTRICAL SCHEMATIC
130 TECHNICAL REFERENCE MANUAL DEK TQ 04/2021
Machine Controller
Controller Power Module
(CPM)
Fibre Optic Links
SIO
Link
Cables
Drip Tray
Cylinder In
4SE13
Drip Tray
Cylinder Out
4SE14
ESIO-4
ESIO-5
IO3
IO4
4PL22
4PL23
Sensor
Sensor
Drip Tray
5SOL5
IO2
Squeegee Drip Tray
Machine Controller
Controller Power Module
(CPM)
Fibre Optic Links
SIO Link
Cable
ESIO-5
Paste Roll
Height Monitor
5SE5
5PL85PL2
ADC/DAC
Board 5
ADC/
DAC
IO4
Paste Roll Height Monitor
