A-193
A50
【共通】RF フィーダ用一括交換台車-2
【COMMON】ReplacingoverallchangertruckforRFfeeder-2
ｲﾗｽﾄ番号
Ref.No.
品番
PartNumber
Description
品名
個数
Q'ty
備考
Remarks
54 SM-6030602-TN SCREWM3X6 ﾛｯｶｸｱﾅﾎﾞﾙﾄM3X6 (4)
55 400-62594 CHEESEUNION ﾁｰｽﾞﾕﾆｵﾝ (1)
56 EZ4-000-207-02 PIN(2)LOCATE ﾛｹ-ﾄﾋﾟﾝ(2) (2)
57 SM-6041402-TN SCREWM4X0.7L=14 ﾛｯｶｸｱﾅﾎﾞﾙﾄM4X0.7L=14 (2)
58 HX-0029400-00 FIXEDBASE ｺﾃｲﾍﾞｰｽ (2)
59 SM-4040601-SC SCREWM4X0.7L=6 ﾅﾍﾞｺﾈｼﾞM4X0.7L=6 (2)
60 SL-6040892-TN SCREWM4L=8 座金付き六角穴ﾎﾞﾙﾄM4L=8 (2)
61 401-73473 BLOWER_UNIT ﾌﾞﾛﾜﾕﾆｯﾄ (1)
62 401-73470 BAR_NOZZLE ﾊﾞｰﾉｽﾞﾙ (1)
63 PJ-0203000-01 PLUG ﾌﾟﾗｸﾞ (1)
64 PJ-0320399-01 BARBJOINT ﾊﾞｰﾌﾞﾂｷﾞﾃ (1)
65 SM-3030552-TN SCREWM3L=5 ﾏﾙﾈｼﾞM3L=5 (2)
66 PJ-3010400-01 REDUCER ﾚｼﾞﾕ-ｻ (1)
67 PJ-3010200-01 REDUCER ﾚﾃﾞｭｰｻ (1)
68 BT-0200121-EB URETHANETUBEBLACK2X1.2 ﾎﾟﾘｳﾚﾀﾝﾁｭｰﾌﾞｸﾛ2X1.2 (0)
69 PC-0122010-00 SPEEDCONTROLLER ｽﾋﾟｰﾄﾞｺﾝﾄﾛｰﾗ (1)
70 401-73471 TUBE_GUIDE ﾁｭｰﾌﾞｶﾞｲﾄﾞ (1)
71 SM-3030552-TN SCREWM3L=5 ﾏﾙﾈｼﾞM3L=5 (2)
72 EA-9500B00-00 CABLEBAND ｹﾂｿｸﾊﾞﾝﾄﾞ60 (2)
73 HX-0015000-00 CABLECLAMP ｹｰﾌﾞﾙｸﾘｯﾌﾟ (1)
74 SM-6040802-TN SCREW ﾛﾂｶｸｱﾅﾎﾞﾙﾄM4X0.7L=8 (1)
75 401-69718 TABLE_BASE_L_ASM ﾃｰﾌﾞﾙﾍﾞｰｽ L ｸﾐ 1
76 401-69719 SLIDE_BLOCK_L_ASM ｽﾗｲﾄﾞﾌﾞﾛｯｸ L ｸﾐ (1)
77 401-67545 SLIDE_BLOCK_L_K ｽﾗｲﾄﾞﾌﾞﾛｯｸ LK (1)
78 EZ4-113-107-01 FOLLOWER(CF8VB)CAM ｶﾑﾌｵﾛｱ(CF8VB) (2)
79 SM-6051602-TN SCREW ﾛｯｶｸｱﾅﾎﾞﾙﾄ (4)
80 401-69720 FEEDER_PCB_UNIT ﾌｨｰﾀﾞｷﾊﾞﾝﾕﾆｯﾄ (1)
81 401-67570 FD_PCB_BASE FD ｷﾊﾞﾝﾍﾞｰｽ (1)
82 401-69473 BANKIDPCB(RF)ASM ﾊﾞﾝｸ ID 基板(RF)組 (1)
83 SL-4850591-SC SCREWM2.5L=5 座金付きなべ小ねじM2.5L=5 (4)
84 HX-0070600-0A MOUNTBASE ﾏｳﾝﾄﾍﾞｰｽ (2)
85 401-67569 FD_PCB_COVER FD ｷﾊﾞﾝｶﾊﾞｰ (1)
86 SL-4030681-SC SCREWM3L=6 座金付きなべ小ねじM3L=6 (4)
87 SL-6040692-TN SCREWM4L=6 座金付き六角穴ﾎﾞﾙﾄM4L=6 (2)
88 401-67575 DISPOSAL_DUCT_BR ﾊｲｷﾀﾞｸﾄ BR (1)
89 SL-6040892-TN SCREWM4L=8 座金付き六角穴ﾎﾞﾙﾄM4L=8 (2)
90 SM-6050802-TN SCREW ﾛｯｶｸｱﾅﾎﾞﾙﾄ (1)
91 SM-6040802-TN SCREWM4X0.7L=8 ﾛｯｶｸｱﾅﾎﾞﾙﾄM4X0.7L=8 (1)
92 401-69748 STOPPER_PLATE ｽﾄｯﾊﾟﾌﾟﾚｰﾄ (1)
93 SM-6030602-TN SCREWM3X6 ﾛｯｶｸｱﾅﾎﾞﾙﾄM3X6 (1)
94 HX-0070600-0A MOUNTBASE ﾏｳﾝﾄﾍﾞｰｽ (3)
95 EZ4-453-803-01 CUSHIONCUTTERUNIT ｶﾂﾀ-ﾕﾆﾂﾄｸﾂｼﾖﾝ (1)
96 401-67568 TABLE_BASE_L ﾃｰﾌﾞﾙﾍﾞｰｽ L (1)
97 401-69721 TABLE_BASE_R_ASM ﾃｰﾌﾞﾙﾍﾞｰｽ R ｸﾐ 1
98 401-67567 TABLE_BASE_R ﾃｰﾌﾞﾙﾍﾞｰｽ R (1)
99 401-69722 SLIDE_BLOCK_R_ASM ｽﾗｲﾄﾞﾌﾞﾛｯｸ R ｸﾐ (1)
100 401-67544 SLIDE_BLOCK_R_K ｽﾗｲﾄﾞﾌﾞﾛｯｸ RK (1)
101 EZ4-113-107-01 FOLLOWER(CF8VB)CAM ｶﾑﾌｵﾛｱ(CF8VB) (2)
102 SM-6051602-TN SCREW ﾛｯｶｸｱﾅﾎﾞﾙﾄ (4)
103 401-69723 TROLLEY_SENSOR_ASM ﾄﾛﾘｾﾝｻｸﾐ (1)
104 401-67571 TROLLEY_SENSOR_BR ﾄﾛﾘｰｾﾝｻﾌﾞﾗｹｯﾄ (1)
105 EZ4-149-845-01 ACTUATOR(D40A-A1)SWITCH ﾄﾞｱｽｲﾂﾁｱｸﾁﾕｴ-ﾀ(D40A-A1) (1)
106 SM-6040802-TN SCREWM4X0.7L=8 ﾛｯｶｸｱﾅﾎﾞﾙﾄM4X0.7L=8 (2)
A-194
A50
【共通】RF フィーダ用一括交換台車-2
【COMMON】ReplacingoverallchangertruckforRFfeeder-2
ｲﾗｽﾄ番号
Ref.No.
品番
PartNumber
Description
品名
個数
Q'ty
備考
Remarks
107 SL-6040892-TN SCREWM4L=8 座金付き六角穴ﾎﾞﾙﾄM4L=8 (2)
108 401-67575 DISPOSAL_DUCT_BR ﾊｲｷﾀﾞｸﾄ BR (1)
109 SL-6040892-TN SCREWM4L=8 座金付き六角穴ﾎﾞﾙﾄM4L=8 (2)
110 HX-0015000-00 CABLECLAMP ｹｰﾌﾞﾙｸﾘｯﾌﾟ (1)
111 SM-6040602-TN SCREW ﾛｯｶｸｱﾅﾎﾞﾙﾄ (2)
112 SM-6050802-TN SCREW ﾛｯｶｸｱﾅﾎﾞﾙﾄ (1)
113 SM-6040802-TN SCREWM4X0.7L=8 ﾛｯｶｸｱﾅﾎﾞﾙﾄM4X0.7L=8 (1)
114 401-69748 STOPPER_PLATE ｽﾄｯﾊﾟﾌﾟﾚｰﾄ (1)
115 SM-6030602-TN SCREWM3X6 ﾛｯｶｸｱﾅﾎﾞﾙﾄM3X6 (1)
116 HX-0070600-0A MOUNTBASE ﾏｳﾝﾄﾍﾞｰｽ (3)
117 EZ4-453-803-01 CUSHIONCUTTERUNIT ｶﾂﾀ-ﾕﾆﾂﾄｸﾂｼﾖﾝ (1)
118 BT-0600400-EC URETHANETUBEBLUE6X4 ﾎﾟﾘｳﾚﾀﾝﾁｭｰﾌﾞ青6X4 (0.36)
119 SM-6051202-TN SCREWM5X0.8L=12 ﾛｯｶｸｱﾅﾎﾞﾙﾄM5X0.8L=12 3
120 401-69724 REGULATION_BAR_U_ASM ﾚｷﾞｭﾚｰｼｮﾝﾊﾞｰ U ｸﾐ 1
121 401-71523 RB_SUPPORT_R RB ｻﾎﾟｰﾄ R (1)
122 401-71524 RB_SUPPORT_L RB ｻﾎﾟｰﾄ L (1)
123 401-67574 REGULATION_BAR_U ﾚｷﾞｭﾚｰｼｮﾝﾊﾞｰ U (1)
124 SL-6040892-TN SCREWM4L=8 座金付き六角穴ﾎﾞﾙﾄM4L=8 (4)
125 401-67564 POSITION_LABEL_K ﾎﾟｼﾞｼｮﾝﾗﾍﾞﾙ_K (1)
126 401-73037 PROHIBIT_SEAL_M ｶｼﾞｭｳｷﾝｼｼｰﾙ M (2)
127 SL-6061292-TN SCREWM6L=12 座金付き六角穴ﾎﾞﾙﾄM6L=12 4
128 401-69725 SHOOT_UNIT_K ｼｭｰﾄﾕﾆｯﾄ K 1
129 401-67560 SHOOT_K_B ｼｭｰﾄ K_B (1)
130 401-67562 TAPE_GUIDE_PLATE_KB ﾃｰﾌﾟｶﾞｲﾄﾞﾌﾟﾚｰﾄ KB (1)
131 401-67561 TAPE_GUIDE_FIX_PLATE ﾃｰﾌﾟｶﾞｲﾄﾞﾌｨｸｽﾌﾟﾚｰﾄ (1)
132 401-67563 SPONGE_SHOOT ｽﾎﾟﾝｼﾞｼｭｰﾄ (1)
133 WP-0320501-SC WASHERM3 ﾋﾗｻﾞｶﾞﾈM3 (4)
134 WS-0310002-KN SPRINGWASHERM3 ﾊﾞﾈｻﾞｶﾞﾈM3 (4)
135 NM-6030003-SC NUTM3X0.5TYPE3 六角ﾅｯﾄM3X0.53 種 (4)
136 CM-3002000-04 FINGERINJURYCAUTIONLABEL(50) 指怪我注意ｼｰﾙ(50) (1)
137 SM-3041252-TN SCREWM4L=12 丸ねじM4L=12 4
138 401-43537 SUPPORT_BAR ｻﾎﾟｰﾄﾊﾞｰ 1
139 SL-6040892-TN SCREWM4L=8 座金付き六角穴ﾎﾞﾙﾄM4L=8 2
140 401-67565 STAND_COVER_TOP ｽﾀﾝﾄﾞｶﾊﾞｰﾄｯﾌﾟ 1
141 CM-3002000-04 FINGERINJURYCAUTIONLABEL(50) 指怪我注意ｼｰﾙ(50) 1
142 401-67566 SCREW_M4_L8 M4 ｻﾗﾈｼﾞｺｱﾀﾏ 4
143 401-67576 DISPOSAL_DUCT ﾊｲｷﾀﾞｸﾄ 1
144 401-67593 SPONGE_FRONT ｽﾎﾟﾝｼﾞﾌﾛﾝﾄ 1
145 401-67594 SPONGE_SIDE ｽﾎﾟﾝｼﾞｻｲﾄﾞ 2
146 SL-6030692-TN SCREWM3L=6 座金付き六角穴ﾎﾞﾙﾄM3L=6 4
147 401-73042 FAN_UNIT ﾌｧﾝﾕﾆｯﾄ 1
148 401-73038 FAN_BASE ﾌｧﾝﾍﾞｰｽ (1)
149 401-73039 FAN_COVER ﾌｧﾝｶﾊﾞｰ (1)
150 SL-4030691-SC SCREWM3L=6 座金付きなべ小ねじM3L=6 (12)
151 401-72514 TROLLYFANASM ﾄﾛﾘｰﾌｧﾝ組 (2)
152 400-93509 X_FAN40_GUARD ﾌｧﾝｶﾞｰﾄﾞ 40 (2)
153 SL-4032591-SC SCREWM3L=25 座金付きなべ小ねじM3L=25 (4)
154 401-73040 FAN_BASE_BR ﾌｧﾝﾍﾞｰｽ BR (2)
155 SL-6030692-TN SCREWM3L=6 座金付き六角穴ﾎﾞﾙﾄM3L=6 (4)
156 401-73037 PROHIBIT_SEAL_M ｶｼﾞｭｳｷﾝｼｼｰﾙ M (1)
157 SL-6040892-TN SCREWM4L=8 座金付き六角穴ﾎﾞﾙﾄM4L=8 4
158 SM-6051202-TN SCREWM5X0.8L=12 ﾛｯｶｸｱﾅﾎﾞﾙﾄM5X0.8L=12 3
159 401-71520 BANK_BASE_K_AP_ASSY ﾊﾞﾝｸﾍﾞｰｽ K_AP_ｱｯｼｰ 1
401-67526 の応急対応用
A-195
A50
【共通】RF フィーダ用一括交換台車-2
【COMMON】ReplacingoverallchangertruckforRFfeeder-2
ｲﾗｽﾄ番号
Ref.No.
品番
PartNumber
Description
品名
個数
Q'ty
備考
Remarks
160 401-71516 BANK_BASE_K_AP ﾊﾞﾝｸﾍﾞｰｽ_K_AP (1)
161 401-71517 BANK_PLATE ﾊﾞﾝｸﾌﾟﾚｰﾄ (2)
162 401-71518 BANK_SHIM_03 ﾊﾞﾝｸｼﾑ 03 (2)
163 401-71519 BANK_SHIM_01 ﾊﾞﾝｸｼﾑ 01 (6)
164 401-28154 LOW_HEAD_SCREW_M4 低頭ねじ M4 (8)
