RX-7_RX-7R-Rev09 - 第292页

C-16

C-15

C-16

C-17

C5

【RX-7R】搬送部周辺配管図

【RX-7R】Conveyorpipediagram

ｲﾗｽﾄ番号

Ref.No.

品番

PartNumber

Description



品名

個数

Q'ty

備考

Remarks



1 EZ1-492-216-12 SENSORASSY ｾﾝｻASSY(ｸﾗﾝﾌﾟ1) 1  

2 EZ1-492-216-22 SENSORASSY ｾﾝｻASSY(ｸﾗﾝﾌﾟ2) 1  

3 PJ-3050800-03 T-JOINTD=8 ﾁｰｽﾞφ8 1  

4 402-03380 PLUG(KJP-02) ﾌﾟﾗｸﾞ(KJP-02) 4  

5 402-07022 SOLENOIDVALVEASSY_SINGLE ｿﾚﾉｲﾄﾞﾊﾞﾙﾌﾞASSY(ｼﾝｸﾞﾙ) 1  

6 402-07028 SOLENOIDVALVE(ST)ASSY_SINGLE ｿﾚﾉｲﾄﾞﾊﾞﾙﾌﾞ(ST)ASSY(ｼﾝｸﾞﾙ) 1  

7 EZ4-447-052-11 UNION(KQ2H02-M3G)HALF ﾊ-ﾌﾕﾆｵﾝ(KQ2H02-M3G) 16  

8 PJ-3040851-01 ELBOWUNION ｴﾙﾎﾞﾕﾆｵﾝ 2  

9 401-61133 ELBOW_UNION(M-3ALU-2) ｴﾙﾎﾞﾕﾆｵﾝ(M-3ALU-2) 4  

10 EZ4-453-569-01 PLUG(CYP025-08B29449) ﾌﾟﾗｸﾞ(CYP025-08B29449) 6  

11 EZ4-453-817-01 CYLINDER(SMG-L-10-10) ｼﾘﾝﾀﾞ(SMG-L-10-10) 2  

12 EZ4-457-146-31 CONTROLLER(AS1211F-M5-02A) ｽﾋﾟ-ﾄﾞｺﾝﾄﾛ-ﾗ-(AS121 16  

13 EZ4-454-500-01 CYLINDER(CDUJB8-11-DCP6468P) ｼﾘﾝﾀﾞ(CDUJB8-11-DCP6468P) 8  

14 401-58139 VACUUM(VSU-H05-44S) ﾊﾞｷｭｰﾑ(VSU-H05-44S) 2  

15 EZ4-454-545-01 SILENCER(SLW-6S) ｻｲﾚﾝｻ(SLW-6S) 4  

16 EZ4-455-731-01 UNION(KJH02-M3)HALF ﾊ-ﾌﾕﾆｵﾝ(KJH02-M3) 2  

17 EZ4-455-732-01 STRAIGHT(KJH02-04) ｲｹｲｽﾄﾚ-ﾄ(KJH02-04) 4  

18 EZ4-455-733-01 WYE(KJU02-00)UNION ﾕﾆｵﾝﾜｲ(KJU02-00) 16  

19 EZ4-455-734-01 UNION(KJL02-M5)ELBOW ｴﾙﾎﾞﾕﾆｵﾝ(KJL02-M5) 4  

20 401-61132 CYLINDER(CDUJB8-15D-M9NS) ｼﾘﾝﾀﾞ(CDUJB8-15D） 2  

21 PC-0122010-00 SPEEDCONTROLLER ｽﾋﾟ-ﾄﾞｺﾝﾄﾛ-ﾗ- 8  

22 401-61137 STRAIGHT(KQ2H02-00A) ｽﾄﾚｰﾄ(KQ2H02-00A) 4  

23 EZ1-492-216-22 SENSORASSY ｾﾝｻASSY(ｸﾗﾝﾌﾟ2) 1  

24 EZ1-492-216-32 SENSORASSY ｾﾝｻASSY(ｸﾗﾝﾌﾟ3) 1  

25 EZ1-492-216-42 SENSORASSY ｾﾝｻASSY(ｸﾗﾝﾌﾟ4) 1  

26 EZ1-492-217-14 SOLENOIDVALVEASSY ｿﾚﾉｲﾄﾞﾊﾞﾙﾌﾞASSY 1  

27 401-61456 SOLENOIDVALVEASSY(ST) ｿﾚﾉｲﾄﾞﾊﾞﾙﾌﾞASSY(ST) 1  

28 EZ4-447-052-11 UNION(KQ2H02-M3G)HALF ﾊ-ﾌﾕﾆｵﾝ(KQ2H02-M3G) 32  

29 PJ-3040851-01 ELBOWUNION ｴﾙﾎﾞﾕﾆｵﾝ 2  

30 401-61133 ELBOW_UNION(M-3ALU-2) ｴﾙﾎﾞﾕﾆｵﾝ(M-3ALU-2) 4  

31 EZ4-453-569-01 PLUG(CYP025-08B29449) ﾌﾟﾗｸﾞ(CYP025-08B29449) 6  

32 EZ4-453-817-01 CYLINDER(SMG-L-10-10) ｼﾘﾝﾀﾞ(SMG-L-10-10) 2  

33 EZ4-457-146-31 CONTROLLER(AS1211F-M5-02A) ｽﾋﾟ-ﾄﾞｺﾝﾄﾛ-ﾗ-(AS1211F-M5-02A) 24  

34 EZ4-454-500-01 CYLINDER(CDUJB8-11-DCP6468P) ｼﾘﾝﾀﾞ(CDUJB8-11-DCP6468P) 16  

35 401-58139 VACUUM(VSU-H05-44S) ﾊﾞｷｭｰﾑ(VSU-H05-44S) 2  

36 EZ4-454-545-01 SILENCER(SLW-6S) ｻｲﾚﾝｻ(SLW-6S) 4  

37 EZ4-455-731-01 UNION(KJH02-M3)HALF ﾊ-ﾌﾕﾆｵﾝ(KJH02-M3) 2  

38 EZ4-455-732-01 STRAIGHT(KJH02-04) ｲｹｲｽﾄﾚ-ﾄ(KJH02-04) 4  

39 EZ4-455-733-01 WYE(KJU02-00)UNION ﾕﾆｵﾝﾜｲ(KJU02-00) 28  

40 EZ4-455-734-01 UNION(KJL02-M5)ELBOW ｴﾙﾎﾞﾕﾆｵﾝ(KJL02-M5) 8  

41 401-61132 CYLINDER(CDUJB8-15D-M9NS) ｼﾘﾝﾀﾞ(CDUJB8-15D） 2  

42 PC-0122010-00 SPEEDCONTROLLER ｽﾋﾟ-ﾄﾞｺﾝﾄﾛ-ﾗ- 16  

43 401-61137 STRAIGHT(KQ2H02-00A) ｽﾄﾚｰﾄ(KQ2H02-00A) 8  

44 402-02234 CYLINDER(BDAS10X25) ｼﾘﾝﾀﾞ(BDAS10X25) 2  

45 PJ-3050800-03 T-JOINTD=8 ﾁｰｽﾞφ8 1  

46 402-03380 PLUG(KJP-02) ﾌﾟﾗｸﾞ(KJP-02) 4  

47 EZ1-492-216-12 SENSORASSY ｾﾝｻASSY(ｸﾗﾝﾌﾟ1) 1  
