26.カムボックス ２(YPA)
26.Cam box(YPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 YPA0040 1 BKT BKT
2 YPA0132 1 BKT BKT
3 YPA0261 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
4 YPA0271 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
5 WPA0614 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
6 YPA0281 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
7 H4396T 10 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA2525Z
8 H4302A 18 BEARING, THRUST ﾍﾞｱﾘﾝｸﾞ ｽﾗｽﾄ NTB2542
9 YPA0211 1 COLLAR ｶﾗｰ
10 YPA0190 1 COLLAR ｶﾗｰ
11 YPA0162 1 SHAFT ｼｬﾌﾄ
12 N1046A 4 NUT, A ﾅｯﾄ A AN05
13 W1067A 4 WASHER, A ﾜｯｼｬ A AW05
14 WPA0705 9 PIN ﾋﾟﾝ
15 H4403A 22 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA810Z
16 WPA0691 8 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ
17 R5023T 9 PIN, NEEDLE ﾋﾟﾝ ﾆｰﾄﾞﾙ 4ﾟX15.8
18 WPA1791 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
20 WPA0591 8 PIN ﾋﾟﾝ
21 WPA0954 13 PIN, LOCATING ﾋﾟﾝ 位置決め
22 WPA1161 3 BKT BKT
23 WPA5142 7 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
24 WPA0581 7 PIN ﾋﾟﾝ
25 H4401A 14 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA69Z
26 YPA0031 1 BKT BKT
27 YPA0112 1 BKT BKT
29 YPA0760 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
30 YPA0531 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
31 YPA0241 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
32 YPA0251 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
33 WPA0654 1 CAM, LEVER ｶﾑ ﾚﾊﾞｰ
34 YPA0122 1 BKT BKT
35 YPA0180 1 COLLAR ｶﾗｰ
36 YPA0143 1 SHAFT ｼｬﾌﾄ
37 YPA0170 1 COLLAR ｶﾗｰ
38 YPA0153 1 SHAFT ｼｬﾌﾄ
39 WPA0733 1 SHAFT ｼｬﾌﾄ
CP-65 PARTS LIST ver09
26 - 2
26.カムボックス 2(YPA)
26.Cam box 2(YPA)
26.カムボックス ２(YPA)
26.Cam box(YPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
40 WPA1355 1 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ
41 YPA0431 1 BKT BKT
42 YPA0311 1 BKT BKT
43 YPA0790 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
44 YPA0780 2 SPRING ｽﾌﾟﾘﾝｸﾞ
45 WPA1201 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
46 WPA1721 1 SPRING ｽﾌﾟﾘﾝｸﾞ
47 YPA0602 1 BKT BKT
48 YPA0592 1 BKT BKT
49 S2085H 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ DAD25X40-ZG553A2-3731W
50 WPA1560 2 BKT BKT
51 WPA1570 4 WASHER ﾜｯｼｬ
52 WPA1710 2 PIN ﾋﾟﾝ
53 H31811 2 PLATE, END ﾌﾟﾚｰﾄ ｴﾝﾄﾞ RBR8FN P=1
54 AYPQ9010 1 LEVER ﾚﾊﾞｰ
55 AWPQ9011 1 LEVER ﾚﾊﾞｰ
56 GPH4491 8 ROLLER ﾛｰﾗ
57 H4130E 16 BEARING ﾍﾞｱﾘﾝｸﾞ 608ZZ
58 S1001A 16 CIR-CLIP ｻｰｸﾘｯﾌﾟ RTW22
59 N4038A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M5X10L
60 N4027A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X5L
61 N1089A NUT, HEX ﾅｯﾄ 六角 M8
62 W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
63 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
64 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
65 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
66 W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H
67 W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
68 H5349T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X65L
70 H5343A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X30L
71 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L
72 H5341A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X20L
73 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
74 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
75 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
76 WPA1182 2 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ
77 YPA0340 1 JOINT ｼﾞｮｲﾝﾄ
CP-65 PARTS LIST ver09
26 - 3
26.カムボックス 2(YPA)
26.Cam box 2(YPA)
26.カムボックス ２(YPA)
26.Cam box(YPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
78 WPA1410 1
HOLDER, PIN(For Station 18)
ﾎﾙﾀﾞ ﾋﾟﾝ(18st用)
79 YPA0102 1 BKT BKT
80 WPA1601 4 PIN, LOCATING ﾋﾟﾝ 位置決め
81 A4043A 3 ELBOW ｴﾙﾎﾞ PL6-01(1/8)
82 H3181E 2 PLATE END ﾌﾟﾚｰﾄ ｴﾝﾄﾞ NBWT5
84 WPL0232 2 NUT ﾅｯﾄ
86 W1036T 32 WASHER, THRUST ﾜｯｼｬｽﾗｽﾄ AS2542
87 YPU0211 1 JOINT (For CUTTER) ｼﾞｮｲﾝﾄ (ｶｯﾀ用)
88 YPM0040 1 JOINT (For Station 18) ｼﾞｮｲﾝﾄ (18st用)
89 WPL0433 2 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ
90 S2176B 1 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TS6-01
91 N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8
92 A4042A 7 ELBOW ｴﾙﾎﾞ PL6-M5M
93 WPQ0783 4 HOLDER ﾎﾙﾀﾞ
94 . WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WW-12
95 H4118T 8 BEARING ﾍﾞｱﾘﾝｸﾞ SST-1810DSG
96 WPQ0760 4 COLLAR ｶﾗｰ
97 WPQ0771 4 NUT ﾅｯﾄ
98 WPQ0791 4 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
99 . 4 BEARING, SPHERICAL ﾍﾞｱﾘﾝｸﾞ 球面 NB-5
100 WPQ0850 4 PIN ﾋﾟﾝ
101 WPQ0810 4 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ
102 H2025A 4 PIN, SNAP ﾋﾟﾝ ｽﾅｯﾌﾟ SSP-5
103 K5203A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X6L
104 YPA0200 1 COLLAR ｶﾗｰ
106 YPA0570 4 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
107 WPA1781 4 WASHER, THRUST ﾜｯｼｬ ｽﾗｽﾄ
108 YPA0720 1 BLOCK ﾌﾞﾛｯｸ
109 YPA0740 1 PLATE ﾌﾟﾚｰﾄ
110 H5340A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X15L
111 N4048H SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M6X12L
112 AYPL8010 2 JOINT ｼﾞｮｲﾝﾄ
113 WPA5160 7 PLATE, END ﾌﾟﾚｰﾄ ｴﾝﾄﾞ
114 H2050A 2 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ ﾟ3X15
115 YPA0770 1 ROLLER ﾛｰﾗ
116 H4175A 2 BEARING ﾍﾞｱﾘﾝｸﾞ 6000ZZ
117 S1005H 2 SIR-CLIP ｻｰｸﾘｯﾌﾟ RTW-26
CP-65 PARTS LIST ver09
26 - 4
26.カムボックス 2(YPA)
26.Cam box 2(YPA)
