CP-65 PARTS LIST ver09
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
1 - 1
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
R012-007
M012-013
φ1.3
φ1.81
φ10.0
φ3.75
53
54
52
11
12
10
R012-010
φ1.0
5
6
4
R012-013
φ1.3
8
9
7
φ0.71
2
3
1
14
15
13
R012-018
φ2.5
R016-025
17
18
16
φ3.75
R016-037
20
21
19
φ2.5
R020-025
23
24
22
φ2.5
M020-025
26
27
25
R020-037 B029-100
29
30
28
φ5.0
32
33
31
S020-050
φ7.0
41
42
40
S022-070
φ5.0
38
39
37
B022-050
φ5.0
35
36
34
S022-050
44
45
43
B022-070
47
48
46
S029-070
50
51
49
B029-070
φ7.0
φ7.0
φ7.0
x1.5
φ20
φ12
φ12
□29
φ12
φ12
φ12
φ16
φ16
φ20
φ20
□20
□22
□22
□22
□22
□29
□29
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
55
56
57
φ0.41
R012-004
φ12
58
59
60
φ0.41
φ8
R008-004
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 AWPH9514 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-007
2 AWPH9011 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-007
3 WPH8291 20 SEAL ｼｰﾙ R012-007
4 AWPH9524 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-010
5 AWPH9021 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-010
6 WPH8301 20 SEAL ｼｰﾙ R012-010
7 AWPH9534 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-013
8 AWPH9031 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-013
9 WPH8311 20 SEAL ｼｰﾙ R012-013
10 AWPH9545 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY M012-013
11 AWPH9088 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 M012-013
12 WPH8311 20 SEAL ｼｰﾙ M012-013
13 AWPH9554 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-018
14 AWPH9077 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-018
15 WPH8320 20 SEAL ｼｰﾙ R012-018
16 AWPH9563 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R016-025
17 AWPH9125 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R016-025
18 WPH8201 20 SEAL ｼｰﾙ R016-025
19 AWPH9572 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R016-037
20 AWPH9134 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R016-037
21 WPH8211 20 SEAL ｼｰﾙ R016-037
22 AWPH9583 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R020-025
23 AWPH9041 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R020-025
24 WPH8081 20 SEAL ｼｰﾙ R020-025
25 AWPH9593 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY M020-025
26 AWPH9098 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 M020-025
27 WPH8081 20 SEAL ｼｰﾙ M020-025
28 AWPH9602 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R020-037
29 AWPH9050 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R020-037
30 WPH8121 20 SEAL ｼｰﾙ R020-037
31 AWPH9612 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S020-050
32 AWPH9069 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 S020-050
33 WPH8101 20 SEAL ｼｰﾙ S020-050
34 AWPH9662 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S022-050
35 AWPH9153 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 S022-050
36 WPH8231 20 SEAL ｼｰﾙ S022-050
37 AWPH9672 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B022-050
CP-65 PARTS LIST ver09
1 - 2
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
38 AWPH9153 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 B022-050
39 WPH8221 20 SEAL ｼｰﾙ B022-050
40 AWPH9682 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S022-070
41 AWPH9163 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 S022-070
42 WPH8181 20 SEAL ｼｰﾙ S022-070
43 AWPH9694 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B022-070
44 AWPH9175 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 B022-070
45 WPH8171 20 SEAL ｼｰﾙ B022-070
46 AYPH9510 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S29-070
47 AYPH9020 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 S29-070
48 YPH8060 20 SEAL ｼｰﾙ S29-070
49 AYPH9520 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B29-070
50 AYPH9140 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 B29-070
51 YPH8580 20 SEAL ｼｰﾙ B29-070
52 AYPH9530 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B29-100
53 AYPH9130 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 B29-100
54 YPH8570 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B29-100
55 AWPH9702 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R12-004
56 AWPH9181 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R12-004
57 WPH8331 20 SEAL ｼｰﾙ R12-004
58 AWPH9710 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R008-004
59 AWPH9190 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R008-004
60 WPH8380 20 SEAL ｼｰﾙ R008-004 ･
