3.1 No.1 ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(R側)(QPH)
3.1 No.1 placing head(R-side)(QPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
4 QPA0990 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ
7 PPH0180 1 DOG ﾄﾞｯｸﾞ
8 PPH0190 2 DOG ﾄﾞｯｸﾞ
15 PPH0300 1 SHAFT, PULLEY ｼｬﾌﾄ ﾌﾟｰﾘ
25 PPH0450 1 BKT BKT
26 PPH0460 1 PLATE ﾌﾟﾚｰﾄ
27 PPH0500 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
35 QPH1350 1 COVER ｶﾊﾞｰ
36 QPH1340 1 RETAINER 押え
44 PPH0950 1 PULLEY ﾌﾟｰﾘ
48 PPH1020 1 HOLDER, SENSOR ﾎﾙﾀﾞ ｾﾝｻ
49 PPH1040 1 SPACER ｽﾍﾟｰｻ
50 PPH1050 2 BUSHING ﾌﾞｯｼｭ
51 PPH1062 1 BKT BKT
53 QPH1311 1 BLOCK ﾌﾞﾛｯｸ
57 QPH1334 1 BODY 本体
59 PPH1170 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え
60 PPH3010 1 ADAPTER ｱﾀﾞﾌﾟﾀ
61 PPH3021 1 HOUSING ﾊｳｼﾞﾝｸﾞ
62 PPH3040 1 NUT ﾅｯﾄ
63 PPH3060 1 SPRING ｽﾌﾟﾘﾝｸﾞ
64 PPH3070 1 BUSHING ﾌﾞｯｼｭ
65 PPH3080 1 COLLAR ｶﾗｰ
66 PPH3150 1 JOINT ｼﾞｮｲﾝﾄ
69 PPH3200 2 COLLAR ｶﾗｰ
70 PPH3210 1 DOG ﾄﾞｯｸﾞ
71 PPH3230 1 BKT, SENSOR BKT ｾﾝｻ
72 PPZ0330 1 VALVE, SOL ﾊﾞﾙﾌﾞSOL
79 QPH1220 1 BKT, SENSOR BKT ｾﾝｻ
80 QPH1230 1 BKT, SENSOR BKT ｾﾝｻ
81 QPH1240 1 BKT, SENSOR BKT ｾﾝｻ
88 H4485T 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 212P2M6-530
91 S2146A 1 JOINT ｼﾞｮｲﾝﾄ BF4BU-M3
93 H5152H 1 BOLT, ADJUSTING ﾎﾞﾙﾄ ｾﾘ BSF6X16
94 S3090A 1 SW, PROXIMITY SW 近接 E2E-CR8C1
95 S3090H 2 SW, PROXIMITY SW 近接 E2EC-CR8D1
96 S4040X 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX306-W2A
97 S4040Y 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX405-W2A
98 S4040Z 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX406-W2A
IP-ⅢE PARTS LIST ver11 3 - 2
3.1 No.1 ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(R側)(QPH)
3.1 No.1 placing head(R-side)(QPH)
3.1 No.1 ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(R側)(QPH)
3.1 No.1 placing head(R-side)(QPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
100 N2034A 1 NIPPLE, GREASE ﾆｯﾌﾟﾙ ｸﾞﾘｽ GP-AM-6(P=1)
106 Y3061E 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KJS04-M5(ｼﾛ)
109 H3145H 1 PLUG ﾌﾟﾗｸﾞ M-3P
110 K5322Z 1 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ MB4R-M3-O
111 H4144H 2 BEARING ﾍﾞｱﾘﾝｸﾞ MR137ZZS
112 S2157T 1 JOINT ｼﾞｮｲﾝﾄ PAU4
114 N2037A 1 NIPPLE, GREASE ﾆｯﾌﾟﾙ ｸﾞﾘｽ PF1/8X45゜B Type
117 A5161T 1 O RING O ﾘﾝｸﾞ S15
118 A5138A 2 O RING O ﾘﾝｸﾞ S3
119 A5129A 1 O RING O ﾘﾝｸﾞ S4
120 . 1 TUBE ﾁｭｰﾌﾞ SP-4-LB
121 . 2 RING, INSERT ﾘﾝｸﾞ ｲﾝｻｰﾄ WR0425
128 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
129 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
130 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
131 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
134 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
136 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
137 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
140 K5173A 6 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X10L
143 K5203A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X6L
144 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L
146 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
147 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
148 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L
150 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
151 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
152 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
153 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
157 H5278A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X15L
158 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L
159 H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L
161 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L
166 N4018A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X3L
167 . SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X2L
168 N4016A 2 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M2X2L
170 QPA1030 1 RETAINER, WIRING 押え 配線
171 S4015Z 15 SEPARATOR ｾﾊﾟﾚｰﾀ 2020･
172 S40154 15 SEPARATOR ｾﾊﾟﾚｰﾀ 2200.28･
IP-ⅢE PARTS LIST ver11 3 - 3
3.1 No.1 ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(R側)(QPH)
3.1 No.1 placing head(R-side)(QPH)
3.1 No.1 ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(R側)(QPH)
3.1 No.1 placing head(R-side)(QPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
173 QPH1391 1 DOG ﾄﾞｯｸﾞ
174 QPH1421 1 DOG ﾄﾞｯｸﾞ
175 QPH1431 1 COVER ｶﾊﾞｰ
176 QPH1440 1 TUBE ﾁｭｰﾌﾞ
177 QPH1450 1 PLATE ﾌﾟﾚｰﾄ
178 QPH1460 1 BKT, SW BKT SW
179 QPH1480 1 BKT BKT
180 QPH1500 1 BKT BKT
181 QPH1520 1 OIL PAN ｵｲﾙﾊﾟﾝ
182 A1022S 1 ADAPTER ｱﾀﾞﾌﾟﾀ KQ2N06-01S
183 A1022N 1 ADAPTER ｱﾀﾞﾌﾟﾀ KQ2N04-M5
184 Y30827 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2H06-M5
185 H1006M 1 GENERATOR, VACUUM 発生器 真空 VBH12-66P
186 H1121Y 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL SY5120-5MZ-01-F2-X19
187 H3018X 1 FILTER ﾌｨﾙﾀ LF-M5A-Z
188 Y3075A 1 CONNECTOR ｺﾈｸﾀ KQ2U06-00
190 Y3078A 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-01S
191 W1004G 1 WASHER, FLAT ﾜｯｼｬ 平 LR6-0.5
192 H5281A 1 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X25L
194 QPH1540 1 BKT, SENSOR BKT ｾﾝｻ
195 APQH8011 1 JOINT, ROTARY ｼﾞｮｲﾝﾄ ﾛｰﾀﾘ
196 . 2 TUBE ﾁｭｰﾌﾞ No.820 4XO.25
197 S3214L 1 SLEEVE ｽﾘｰﾌﾞ DS-5 ・
IP-ⅢE PARTS LIST ver11 3 - 4
3.1 No.1 ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(R側)(QPH)
3.1 No.1 placing head(R-side)(QPH)
