IP- III E P ARTS LIST ver1 1 4 3 . 2 . エアー配管図( Q P Z ) 4 3 . 2 . P n e u m a t i c c i r c u i t d i a g r a m ( Q P Z ) 4 3 - 4 4 3 . 2 . エアー配管図( Q P Z ) 4 3 . 2 . P n e u m a t i c c i r c u i t d i a g r a m ( Q P Z )…

100%1 / 295
43.1.ｴｱｰ配管図
43.1.Pneumatic circuit
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
69 A4033A 1 ELBOW ｴﾙﾎﾞ GPL-61
70 Y30742 4 UNION ﾕﾆｵﾝ KQ2U04-00
71 PPT1470 1 TERMINAL ﾀｰﾐﾅﾙ
72 Y3034W 1 UNION ﾕﾆｵﾝ KJT06-M5(ｼﾛ)
73 Y3049L 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-M5(ｼﾛ)
75 . 1 PLUG ﾌﾟﾗｸﾞ GC-C4-1/8
76 Y3078A 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-01S
77 A4067T 4 ELBOW ｴﾙﾎﾞ M-5ALHU-4
78 PPT0402 1 TERMINAL ﾀｰﾐﾅﾙ
79 PQC0750 1 CYLINDER ｼﾘﾝﾀﾞ
80 S21271 2 CYLINDER ｼﾘﾝﾀﾞ JDAS12X35-CS4HB1-1311W
81 Y3049G 4 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL04-M5(ｼﾛ)
82 Y3079N 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5
83 Y3023A 1 UNION ﾕﾆｵﾝ PE 6
84 H1066H 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL A040-4E1-25-75-PSL-DC24V
87 K5077A 4 CONNECTOR ｺﾈｸﾀ M-5J
88 K5075A 2 CONNECTOR ｺﾈｸﾀ KQU06-00
96 Y3023T 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ PEG10-08
97 Y3040T 2 UNION ﾕﾆｵﾝ KQR04-06
98 H3021Z 1 FILTER ﾌｨﾙﾀ DMP100-10
99 Y3041Z 1 UNION ﾕﾆｵﾝ KQT08-00
100 Y3056T 2 UNION ﾕﾆｵﾝ KQT06-08
101 Y3062C 2 UNION ﾕﾆｵﾝ KJS06-01S(ｼﾛ)
102 . 1 JOINT ｼﾞｮｲﾝﾄ TS8-01
103 S1053N 1 SILENCER ｻｲﾚﾝｻ KM-22
105 . 1 PLUG ﾌﾟﾗｸﾞ 1/8.
106 H1066T 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F1Y110-4ME2-81-DC24V
107 . 3 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F1W110-4E1-DC24V
108 . 1 JOINT ｼﾞｮｲﾝﾄ TS8-01
109 . 2 UNION ﾕﾆｵﾝ TL4-01
120 K2027R 1 KEY ｷｰ C1000-50
121 . 1 PRESSURE GAUGE 圧力計 G46-7-02
122 K1086T 1 COUPLER ｶﾌﾟﾗ 30PM
･
IP-ⅢE PARTS LIST ver11 43 - 3
43.1.ｴｱｰ配管図
43.1.Pneumatic circuit diagram
IP-
III
E PARTS LIST ver11
43.2.エアー配管図(QPZ)
43.2.Pneumatic circuit diagram(QPZ)
43 - 4
43.2.エアー配管図(QPZ)
43.2.Pneumatic circuit diagram(QPZ)
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
x3
R
P
P
R
B
B
P
R
B
R
B
P
ロボットベースの中
ロボットベースの中
φ6
φ6
φ6
φ6
φ6
φ6
φ6
φ6
φ6
φ6
φ6
φ10
φ6
φ4
φ4
φ4
φ4
φ10
φ8
真空破壊
NGパーツ回収
(QPG)
MFU クランプ
(QPB)
第1ステーション 第2ステーション
装着ヘッド(X2)
(QPH)
装着ヘッド(X1)
(QPH)
SP-4-LB
真空破壊
SP-4-LB
φ4
φ8
φ8
R2 R1P
S1 S2
B A
R2 R1P
S1 S2
B A
ケーブルベア
φ4φ4
φ6φ6
φ6
φ6φ6
Placing head(X1) Placing head(X2)
Vacuum cut
6195
95
53
94
91
93
90
92
89
60
8897
118
58
19
H1
H1
H1
H1
Vacuum cut
6195
95
53
94
91
93
90
92
89
60
19
15
58
9788
H2
H2
H2
H2
Flexible track
100
100
96
49
Inside robot base
MFU clamp Reject parts recovery
No.1 staition
No.2 staition
1
1
1 1
20
20
20
20
20
2020
20
B3
B2
B1
B2
B1
B4
B3
B4
8686
8686
Inside robot bnse
110
B3
B4
B1
B2
G1
24
G1
67
15
118 119
122
119
122
9
112
109108
111
112
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
43.2.ｴｱｰ配管図
43.2.Pneumatic circuit diagram
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 S2126T 4 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ MDUB50-15DM-A73
9 PPZ0122 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL
15 PPZ0331 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL
19 K5322Z 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ MB4R-M3-0
20 K5343C 8 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-02-06S(ｼﾛ)
24 H2101T 1 TWEEZERS, AIR ﾋﾟﾝｾｯﾄ ｴｱｰ VTB-W-SET
49 K50767 2 CONNECTOR ｺﾈｸﾀ KQ2U08-10
50 Y3069H 2 UNION ﾕﾆｵﾝ KQ2R06-08
53 S2157T 2 JOINT ｼﾞｮｲﾝﾄ PAU04
58 S2146A 2 JOINT ｼﾞｮｲﾝﾄ BF4BU-M3
60 Y3078A 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-01S
61 Y3061E 2 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KJS04-M5(ｼﾛ)
67 Y3034Z 1 UNION ﾕﾆｵﾝ KQE04-00
86 Y3023A 4 UNION ﾕﾆｵﾝ PE6
88 K5075A 2 CONNECTOR ｺﾈｸﾀ KQU06-00
89 H1121Y 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL SY5120-5MNZ-01-F2X19
90 H1006M 2 GENERATOR, VACUUM 発生器 真空 VBH12-66P
91 H3018X 2 FILTER ﾌｨﾙﾀ LF-M5A-Z
92 A1022L 2 ADAPTER ｱﾀﾞﾌﾟﾀ KQN06-01S
93 Y3056A 2 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQH06-M5
94 A1022F 2 ADAPTER ｱﾀﾞﾌﾟﾀ KQN04-M5
95 R2037A 4 RING, INSERT ﾘﾝｸﾞ ｲﾝｻｰﾄ WR0425
96 Y3023T 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ PEG10-08
97 Y3040T 2 UNION ﾕﾆｵﾝ KQR04-06
100 Y3056T 2 UNION ﾕﾆｵﾝ KQT06-08
108 . 1 JOINT ｼﾞｮｲﾝﾄ TS8-01
109 . 2 UNION ﾕﾆｵﾝ TL4-01
110 S1053N 1 SILENCER ｻｲﾚﾝｻ KM-22
111 H3130A 1 PLUG ﾌﾟﾗｸﾞ 1/4.
112 H1066T 2 VALVE, SOL ﾊﾞﾙﾌﾞ SOL F1Y110-4ME2-81-DC24V
118 H3117T 2 PLUG ﾌﾟﾗｸﾞ P-M3
119 H3118A 2 PLUG ﾌﾟﾗｸﾞ P-M5
122 A3033A 2 PLUG 埋栓 PT1/4
･
IP-ⅢE PARTS LIST ver11 43 - 5
43.2.ｴｱｰ配管図
43.2.Pneumatic circuit diagram
