6.ﾉｽﾞﾙﾁｪﾝｼﾞ 1-2(QPN) 6.Nozzle change 1-2(QPN) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 1 PPB1120 2 BLOCK ﾌﾞﾛｯｸ 2 PPN1011 2 STOPPER ｽﾄｯﾊﾟ 3 PPN1050 1 KNUCKLE ﾅｯｸﾙ 4 PPN1141 …
IP-
III
E PARTS LIST ver11
6.ノズルチェンジ 1-2(QPN)
6.Nozzle change 1-2(QPN)
6 - 1
6.ノズルチェンジ 1-2(QPN)
6.Nozzle change 1-2(QPN)
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
x8
5
47
38
42
38
47
16
4
46
38
42
15
42
38
48
1
37
49
39
53
17
39
54
56
40
36
37
26
20
2
20
26
48
38
19
39
54
45
51
7
3
32
29
27
28
10
39
55
53
9
59
33
44
41
58
30
35
13
53
52
39
22
23
43
39
54
39
54
53
39
43
11
39
54
8
40
57
6
12
53
39
43
47
38
5
16
42
38
47
4
42
38
46
14
1
37
49
39
53
42
38
48
18
39
54
56
40
37
36
26
20
2
48
38
42
24
21
39
50
25
40
57
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
6.ﾉｽﾞﾙﾁｪﾝｼﾞ 1-2(QPN)
6.Nozzle change 1-2(QPN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 PPB1120 2 BLOCK ﾌﾞﾛｯｸ
2 PPN1011 2 STOPPER ｽﾄｯﾊﾟ
3 PPN1050 1 KNUCKLE ﾅｯｸﾙ
4 PPN1141 2 BKT BKT
5 PPN1150 2 PLATE ﾌﾟﾚｰﾄ
6 PPN1210 1 DUCT ﾀﾞｸﾄ
7 PPN1290 1 SHAFT ｼｬﾌﾄ
8 PPN1303 1 PLATE ﾌﾟﾚｰﾄ
9 PPN1313 1 PLATE, BASE ﾌﾟﾚｰﾄ ﾍﾞｰｽ
10 PPN1320 1 BKT BKT
11 PPN1351 1 BKT BKT
12 PPN1361 1 BKT BKT
13 PPN1410 1 COVER, WIRING ｶﾊﾞｰ 配線
14 PPN1433 1 BKT BKT
15 PPN1444 1 BKT BKT
16 PPN1471 2 BKT, CONNECTING BKT ﾂﾅｷﾞ
17 PPN1500 1 BKT BKT
18 PPN1510 1 BKT BKT
19 PPN1520 1 BKT BKT
20 PPN1530 3 HOLDER ﾎﾙﾀﾞ
21 PPN1540 1 PLATE ﾌﾟﾚｰﾄ
22 PPN1550 1 PLATE ﾌﾟﾚｰﾄ
23 PPN1560 1 BOLT ﾎﾞﾙﾄ
24 PPN1600 1 BKT BKT
25 QPN1690 7 BKT BKT
26 H4203H 3 BEARING ﾍﾞｱﾘﾝｸﾞ 6902ZZ
27 S2097T 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDJ2D16-30-C73
28 S2181A 1 JOINT, KNUCKLE ｼﾞｮｲﾝﾄ ﾅｯｸﾙ I-J016B
29 K5325A 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ M4R-M5-O
30 H1075N 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL PCS-241-M5-D24SP
32 S2182A 1 JOINT, KNUCKLE ｼﾞｮｲﾝﾄ ﾅｯｸﾙ Y-J016B
33 Y3049E 2 UNION ﾕﾆｵﾝ KJL04-M5
35 K5208A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L
36 N4036A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M5X5L
37 N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8
38 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
39 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
40 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
41 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
IP-ⅢE PARTS LIST ver1 1 6 - 2
6.ﾉｽﾞﾙﾁｪﾝｼﾞ 1-2(QPN)
6.Nozzle change 1-2(QPN)
6.ﾉｽﾞﾙﾁｪﾝｼﾞ 1-2(QPN)
6.Nozzle change 1-2(QPN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
42 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
43 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
44 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
45 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
46 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
47 H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L
48 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
49 H5304A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X25L
50 H5303A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X22L
51 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
52 H5301A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18L
53 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
54 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
55 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
56 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
57 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
58 H5279A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X20L
59 Y3049L 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-M5(ｼﾛ)
･
IP-ⅢE PARTS LIST ver1 1 6 - 3
6.ﾉｽﾞﾙﾁｪﾝｼﾞ 1-2(QPN)
6.Nozzle change 1-2(QPN)
