11.Y軸ﾃｰﾌﾞﾙ 3(QPT) 11.Y axis table 3(QPT) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 1 PPT0186 1 BKT(R) BKT(R) 2 PPT0194 1 BKT(L) BKT(L) 3 PPT0212 1 BKT, MOTOR BKT ﾓｰﾀ 4 PPT02…
IP-
III
E PARTS LIST ver11
11.Y軸テーブル 3(QPT)
11.Y axis table 3(QPT)
11 - 1
11.Y軸テーブル 3(QPT)
11.Y axis table 3(QPT)
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
x7
A
A
31
59
69
75
13
2
61
65
11
22
32
45
54
38
61
65
68
59
44
59
70
46
56
56
51
56
75
42
15
21
27
12
26
53
35
80
69
74
28
72
23
74
28
72
36
34
50
8
73
50
47
20
81
67
59
49
48
55
19
61
63
20
81
47
50
3
50
7
18
81
38
65
61
54
1
45
13
75
31
59
69
11
61
65
32
22
51
41
56
75
42
43
59
69
78
79
72
40
17
61
65
9
50
71
50
10
18
38
5
60
62
55
196
58
64
49
48
59
67
61
63
30
59
68
29
59
68
76
77
60
62
38
4
61
63
51
28
72
35
74
12
33
28
72
51
53
23
13
75
69
74
36
80
25
46
56
21
16
56
24
17
61
65
39
59
69
59
69
57
14
81
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
11.Y軸ﾃｰﾌﾞﾙ 3(QPT)
11.Y axis table 3(QPT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 PPT0186 1 BKT(R) BKT(R)
2 PPT0194 1 BKT(L) BKT(L)
3 PPT0212 1 BKT, MOTOR BKT ﾓｰﾀ
4 PPT0263 1 BKT(L) BKT(L)
5 PPT0274 1 BKT(R) BKT(R)
6 PPT0283 1 MOTOR ﾓｰﾀ
7 PPT0410 1 SHAFT ｼｬﾌﾄ
8 PPT0421 1 HOUSING ﾊｳｼﾞﾝｸﾞ
9 PPT0431 1 HOUSING ﾊｳｼﾞﾝｸﾞ
10 PPT0441 1 COLLAR ｶﾗｰ
11 PPT0511 2 COVER 蓋
12 PPT0521 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
13 PPT0540 6 STOPPER ｽﾄｯﾊﾟ
14 QPT1851 1 COVER 蓋
15 PPT0680 1 PULLEY ﾌﾟｰﾘ
16 PPT0690 1 PULLEY ﾌﾟｰﾘ
17 PPT0821 2 RAIL ﾚｰﾙ
18 PPT0830 2 GEAR ｷﾞﾔ
19 PPT0840 2 GEAR ｷﾞﾔ
20 PPT0850 2 GEAR ｷﾞﾔ
21 PPT0864 2 BELT, RUBBER ﾍﾞﾙﾄ ﾗﾊﾞｰ
22 PPT1090 2 SPRING ｽﾌﾟﾘﾝｸﾞ
23 PPT1122 2 RETAINER, RAIL 押え ﾚｰﾙ
24 PPT1191 1 PLATE ﾌﾟﾚｰﾄ
25 PPT1200 1 PLATE ﾌﾟﾚｰﾄ
26 PPT1213 1 PLATE ﾌﾟﾚｰﾄ
27 PPT1221 1 PLATE ﾌﾟﾚｰﾄ
28 PPT1232 4 GUIDE ｶﾞｲﾄﾞ
29 PPT1240 1 BKT BKT
30 PPT1251 1 BKT BKT
31 PPT1262 2 BKT BKT
32 PPT1302 2 LEVER ﾚﾊﾞｰ
33 PPT1336 1 PLATE ﾌﾟﾚｰﾄ
34 PPT1346 1 PLATE ﾌﾟﾚｰﾄ
35 PPT1381 2 GUIDE ｶﾞｲﾄﾞ
36 PPT1391 2 GUIDE ｶﾞｲﾄﾞ
38 PPT1531 4 PIN, ECCENTRIC ﾋﾟﾝ 偏心
39 QPT1840 1 DUCT ﾀﾞｸﾄ
40 PPT1642 1 PLATE ﾌﾟﾚｰﾄ
IP-ⅢE PARTS LIST ver11 11 - 2
11.Y軸ﾃｰﾌﾞﾙ 3(QPT)
11.Y axis table 3(QPT)
11.Y軸ﾃｰﾌﾞﾙ 3(QPT)
11.Y axis table 3(QPT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
41 PPT1652 1 PLATE ﾌﾟﾚｰﾄ
42 PPT1681 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ
43 QPT1790 1 BKT BKT
44 QPT1800 1 BKT BKT
45 IPB0640 2 PIN ﾋﾟﾝ
46 MQC1290 2 PULLEY ﾌﾟｰﾘ
47 NPT0540 2 COLLAR ｶﾗｰ
48 H4007H 2 HEAD, GEAR ﾍｯﾄﾞ ｷﾞﾔ 2GN-36K
49 M5017H 2 MOTOR, INDUCTION ﾓｰﾀ ｲﾝﾀﾞｸｼｮﾝ 2IK6RGN-A-KI
50 H4112A 6 BEARING ﾍﾞｱﾘﾝｸﾞ LF-1260ZZ
51 S3020T 4 SPRING ｽﾌﾟﾘﾝｸﾞ WF5-30
53 K5260A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X8L
54 N4029A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X8L
55 N4015A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X4L
56 K5357M
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X6L
57 . SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X5L
58 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
59 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
60 W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
61 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
62 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
63 H5305A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X30L
64 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
65 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12LHRC34-44
67 H5296C BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X45L
68 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
69 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
70 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
71 H5278A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X15L
72 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L
73 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
74 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L
75 N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8
76 Y30828 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQ2H06-M6
77 N2034A 1 NIPPLE, GREASE ﾆｯﾌﾟﾙ ｸﾞﾘｽ GP-AM6(P=1.0) For pressure control
78 QPT1890 1 PLATE, FIXED ﾌﾟﾚｰﾄ 固定
79 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
80 QPT3171 2 NUT ﾅｯﾄ ･
81 N4028A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X6L
