3 2 - 1 3 2 . インコンベアカバー( H E L P S ) ( オプション) ( W Q C ) 3 2 . I n c o n v e y o r C o v e r ( H E L P S ) ( O p t i o n ) ( W Q C ) 3 2 . インコンベアカバー( H E L P S ) ( オプション) I n c o n v e y o r c o v e r ( H E L P S ) ( O p …
31-2
31.インコンベアカバー(オプション) In conveyor cover(Option)(WQC)
CP-642E PARTS LIST ver07
31.インコンベアカバー(オプション)(WQC)
31.In conveyor Cover(Option)(WQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1WQC4440 1 BKT BKT
2AWQC8140 1 DOOR 扉
3WQC4450 2 RAIL ﾚｰﾙ
4AWQC8130 1 DOOR 扉
5WQC4480 1 STOPPER ｽﾄｯﾊﾟ
6WQC4490 1 PLATE ﾌﾟﾚｰﾄ
7WQC4500 1 PLATE ﾌﾟﾚｰﾄ
8WQC4510 1 STOPPER ｽﾄｯﾊﾟ
9WQC4520 1 STOPPER ｽﾄｯﾊﾟ
10WQC4530 1 BKT BKT
11WQC0301 4 BKT, COVER BKT ｶﾊﾞｰ
12IQC6072 8 NUT ﾅｯﾄ
13PPK0260 3 PLATE ﾌﾟﾚｰﾄ
14WQC4620 1 BKT BKT
15WQC4540 1 PLATE, SW ﾌﾟﾚｰﾄ SW
16WQC4550 1 PLATE ﾌﾟﾚｰﾄ
17M1011Z 1
MAGNET CATCH
ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-148
18T5011S 1
HANDLE
取手
TTHA-00425
19A1002A 1 ACTUATOR ｱｸﾁｭｴｰﾀ VAL2
20S3160H 1
SW, MICRO
SW ﾏｲｸﾛ V-15-1B6
21H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L
22H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
23H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
24K5212A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M4X15L
25H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
26H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
27H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
28K5214A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M5X8L
29.
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M5X15L
30K5362A
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M5X15L
31W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
32W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
33W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
34W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
35W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5 ･
32-1
32.インコンベアカバー(HELPS)(オプション)(WQC)
32.In conveyor Cover(HELPS)(Option)(WQC)
32.インコンベアカバー(HELPS)(オプション) In conveyor cover(HELPS)(Option)(WQC)
CP-642E PARTS LIST ver07
x5
5
29
17
31
29
12
11
33
26
32
23
1
28
30
2
13
9
29
14
30
13
27
33
35
25
33
15
3
29
8
16
24
30
13
18
4
3
21
12
33
26
6
7
20
32
10
19
23
32
32-2
32.インコンベアカバー(HELPS)(オプション)(WQC)
32.In conveyor Cover(HELPS)(Option)(WQC)
32.インコンベアカバー(HELPS)(オプション) In conveyor cover(HELPS)(Option)(WQC)
CP-642E PARTS LIST ver07
図番 & ｺｰﾄﾞ番号
Drg.No. & Code No.
番号 個数 備考
No. QTY Remarks
1WQC4560 1 BKT BKT
2AWQC8140 1 DOOR 扉
3WQC4450 2 RAIL ﾚｰﾙ
4AWQC8150 1 DOOR 扉
5WQC4480 1 STOPPER ｽﾄｯﾊﾟ
6WQC4570 1 BKT, SW BKT SW
7WQC4580 1 PLATE, SW ﾌﾟﾚｰﾄ SW
8WQC4510 1 STOPPER ｽﾄｯﾊﾟ
9WQC4520 1 STOPPER ｽﾄｯﾊﾟ
10S3197Z 1
SW, LIMIT
SW, ﾘﾐｯﾄ ZCK-Y07
11WQC0301 4 BKT, COVER BKT ｶﾊﾞｰ
12IQC6072 10 NUT ﾅｯﾄ
13PPK0260 3 PLATE ﾌﾟﾚｰﾄ
14WQC4620 1 BKT BKT
15WQC4600 1 PLATE, SW ﾌﾟﾚｰﾄ SW
16WQC4550 1 PLATE ﾌﾟﾚｰﾄ
17M1011Z 1
MAGNET CATCH
ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-148
18T5011S 1
HANDLE
取手
TTHA-00425
19S3197H 1
SW, LIMIT
SW, ﾘﾐｯﾄ XCK-J5990
20H5296A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X40L
21H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L
23H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
24K5212A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M4X15L
25H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
26H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
27H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
28K5214A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M5X8L
29.
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M5X15L
30K5362A
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M5X15L
31W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
32W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
33W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
35W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5 ･
Description
品名
Rating
規格
