42 Mechanical Drawings 158310 Issue 1 Reset Swit ch Assembly REMOVE ALL BURRS & SHARP EDGES 12345 12345 A B C D A B C D PROJECTION C COPYRIGHT 2000 A 3 DRAWING NUMBER BOM NUMBER SCALE DESCRIPTION DESIGNER APPROVED DA…

100%1 / 110
Mechanical Drawings 41
157816 Issue 3 Screen Depth Adjuster, ASM
54321
A
B
CC
B
A
12345
67
8
9 10
11 12
13
6
7
8
9
10 11
12
13
D
E
F
G
H
I
D
E
F
G
H
I
PROJECTION
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2000
BOM NUMBER
A
A
A
ITEM PART NO. DESCRIPTION QTY.
1
157814 SCALE, METRIC 1
2
156275 HAND WHEEL 1
3
156278 SPACER BUSH 1
4
156284 POINTER 2
5
156889 GUIDE TUBE 1
6
156890 BEARING BLOCK 1
7
156891 GUIDE STRIP 1
8
156893 DRIVE SHAFT 1
9
157815 SCALE, IMPERIAL 1
10
161087 SPRING PLUNGER (M4 x 2.5 BALL) 1
11
165904 SCREW^SCRN ADJ^3/8 STUB ACME 1
12
165913 STOP^SCRN ADJ^3/8 STUB ACME 1
13
700001 SCREW M3X5 PAN.HD SLTD MC ST.ST 2
14
700100 SCREW M3X6 CAP HD ST.ST 1
15
700425 SCREW M3X5 CSK.SLTD.M/C ST.ST 4
16
700518 NUT M8 NI-LOCK 985 1
17
700601 WASHER M3 PLAIN FORM A ST.ST 2
18
700609 WASHER M3 CRINKLE BE/CU 2
19
700763 PIN 2DIA X 10LG SPR(GROVERLOCK) 1
20
701012 SCREW M3X12 PAN POZI TRI TAP (ST/ZINC/CLR) 2
21
B0059 BEARING DGBB SSL1680ZZ 1
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:1
R PIATEK
SCREEN DEPTH ADJUSTER, ASM
157816
SH 1
OF 1
A
0
ITEM PART NO. DESCRIPTION QTY.
1
157814 SCALE, METRIC 1
2
156275 HAND WHEEL 1
3
156278 SPACER BUSH 1
4
156284 POINTER 2
5
156889 GUIDE TUBE 1
6
156890 BEARING BLOCK 1
7
156891 GUIDE STRIP 1
8
156893 DRIVE SHAFT 1
9
157815 SCALE, IMPERIAL 1
10
161087 SPRING PLUNGER (M4 x 2.5 BALL) 1
11
165904 SCREW^SCRN ADJ^3/8 STUB ACME 1
12
165913 STOP^SCRN ADJ^3/8 STUB ACME 1
13
700001 SCREW M3X5 PAN.HD SLTD MC ST.ST 2
14
700100 SCREW M3X6 CAP HD ST.ST 1
15
700425 SCREW M3X5 CSK.SLTD.M/C ST.ST 4
16
700518 NUT M8 NI-LOCK 985 1
17
700601 WASHER M3 PLAIN FORM A ST.ST 2
18
700609 WASHER M3 CRINKLE BE/CU 2
19
700763 PIN 2DIA X 10LG SPR(GROVERLOCK) 1
20
701012 SCREW M3X12 PAN POZI TRI TAP (ST/ZINC/CLR) 2
21
B0059 BEARING DGBB SSL1680ZZ 1
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:1
R PIATEK
SCREEN DEPTH ADJUSTER, ASM
8-Feb-00
157816
157817
SH 1
OF 1
A
0
LATEST
ISSUE
No. DATE DCR INITIAL
03 05-Aug-02 27627 MGS
ADJUST AND LOCK WITH LOCTITE 222E
DEK 113275 (PINK)
1
4
5
9
13
17
18
SCALE 3:4
10
20
SECTION A-A
2
3
6
7
8
16
21
14
15
19
11
12
VIEW WITHOUT GUIDE TUBE, SCALE 3:4
42 Mechanical Drawings
158310 Issue 1 Reset Switch Assembly
REMOVE ALL BURRS & SHARP EDGES
12345
12345
A
B
C
D
A
B
C
D
PROJECTION
C
COPYRIGHT 2000
A
3
DRAWING NUMBER
BOM NUMBER
SCALE
DESCRIPTION
DESIGNER
APPROVED
DATE
DO NOT SCALE
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:1
PH
RESET SWITCH ASSEMBLY
30-Aug-00
158310
158310
SH 1
OF 1
LATEST
ISSUE
No. DATE DCR INITIAL
01 30-Aug-00 .. PH
ITEM PART NO. DESCRIPTION QTY.
1
144199 PNEUMATIC PUSHBUTTON 1
2
158309 BRACKET, RESET SWITCH 1
3
161500 PLATE CLAMP, OPERATOR SWITCH 1
4
700112 SCREW M4X16 CAP HD ST.ST 2
1
1
3
1
4
2
2
1
Mechanical Drawings 43
158313 Issue 1 Cover Assy with FormFlex Indicator & Pushbutton
REMOVE ALL BURRS & SHARP EDGES
12345
12345
A
B
C
D
A
B
C
D
PROJECTION
C
COPYRIGHT 2000
A
3
DRAWING NUMBER
BOM NUMBER
SCALE
DESCRIPTION
DESIGNER
APPROVED
DATE
DO NOT SCALE
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:4
PH
COVER ASSY.WITH FORMFLEX INDICATOR & PUSHBUTTON
07-Sep-00
158313
158313
SH 1
OF 1
LATEST
ISSUE
No. DATE DCR INITIAL
01 07-Sep-00 ... PH
ITEM PART NO. DESCRIPTION QTY.
1
144199 PNEUMATIC PUSHBUTTON 1
2
158312 FASCIA WASHER 1
3
158319 WAIST COVER ,FRONT RIGHT 1
4
158324 PNEUMATIC INDICATOR 1
1
1
2
1
3
1
4
1
