RV-2-3DH PRODUCT SPECIFICATIONS
6
The maximum payload of the board is 4 kg. When you convey a board of weight more than 1 kg, you
lower the conveyance speed, and please use it. Let me carry in a board after cooling off enough so that
board surface temperature is as follows 60℃ Celsius after reflowing it. It causes belt damage, the loser
when it cannot cool off enough. (exchange indication 0.5 years)
Marking can not be used with inspection data with Longer-sized selection enabled for Longer-sized and
marking unit combination equipment. Marking can be used only in normal board mode.
RV-2-3DH PRODUCT SPECIFICATIONS
7
5. Inspection Function Specification
Item Specification
Types of boards that can be
inspected
After solder printing, before reflow, after reflow
Parts that can be inspected
Square chips of 0402 or more, cylindrical chips, tantalum capacitors,
aluminum chip capacitors, transistors, SOP/QFPs (0.3 mm or greater
pitch), connectors, leads of discrete parts
* If resolution 5.0 μm / pixel, Square chip 0201 or more, SOP / QFP (0.2
mm or more pitches)
Inspection item
Lack of parts, offset, polarity, front-side back, no solder, bridge, solder
amount, disconnected insertion part, etc
RV-2-3DH PRODUCT SPECIFICATIONS
8
6. Hardware Specification
Item Specification
Image processing system
Color image processing
1200-million-pixel CMOS color camera, high-brightness white LEDs,
coaxial illumination
Resolution Standard: 12.0 μm/pixel, Optional: 5.0 μm/pixel
Image range Standard: 48.0 x 36.0 mm, Optional: 20.0 x 15.0 mm
Transfer conveyor type Single track
Transfer conveyor width
adjustment
Automatic adjustment
Height of transfer
conveyor
900 mm -20 mm to +70 mm Adjustable using the adjuster feet
Processing time 0.20 second/1 screen
Positioning Reference on end face of board
Electric power
3-phase 200 to 230 V ±10%, 2.0 kVA or less (effectively 0.8 kVA)
(Power supply cable: 2.0 mm2 x 4-core cable, less than 3 m)
Air supply pressure 0.49 MPa
Control computer OS Windows 7, 64-bit
Optional Marking unit (Air type)
